EM316SW-XY
Fast Ethernet Multi-Function
Media Converters

User Guide

PN 1288003-001
Revision D2
December 12, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fiber Driver EM316SW-XY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MRV Communications Fiber Driver EM316SW-XY

Summary of Contents for MRV Communications Fiber Driver EM316SW-XY

  • Page 1: User Guide

    EM316SW-XY Fast Ethernet Multi-Function Media Converters User Guide PN 1288003-001 Revision D2 December 12, 2008...

  • Page 2: Table Of Contents

    ® Fiber Driver EM316SW-XY Table of Contents 1 Preliminary Considerations ......................iv 1.1 Trademarks and Copyright ...........................iv 1.2 Customer Support............................iv 1.3 Specific Document Information ........................iv 1.4 Latest Revision and Related Documents......................iv 1.5 MRV Regulatory Compliance........................v 1.6 General Safety ..............................vi 1.7 Electrical Safety ............................vi 1.8 Laser Safety ..............................vii 1.9 Passive Laser Equipment Safety.........................vii 2 Module Introduction ..........................1...
  • Page 3 ® Fiber Driver EM316SW-XY 4.3.3.6 “show groups”......................31 4.3.3.7 “show users” ......................31 4.3.3.8 “show running-config”...................32 4.3.3.9 “show startup-config”...................33 4.3.3.10 Displaying and Saving System Parameters..............34 4.3.4 Configuration Context.......................... 35 4.3.4.1 Restoring Default Parameters..................35 4.3.4.2 Configuring System Parameters ...................36 4.3.5 Chassis Context ..........................37 4.3.5.1 “show”...
  • Page 4 ® Fiber Driver EM316SW-XY Table of Figures Figure 1 -- Loopback on FO1 while FO2 is in normal operation ................2 Figure 2 -- Dual Repeater Mode ........................... 5 Figure 3 -- Dual Converter Mode .......................... 6 Figure 4 -- Redundant Link Mode ......................... 7 Figure 5 -- Switching Mode ...........................

  • Page 5: Preliminary Considerations

    1.1 Trademarks and Copyright All trademarks are the property of their respective holders. MRV Communications reserves the right to make changes to technical specifications and documentation without notice in order to improve reliability, function, or design. The user assumes sole responsibility for applying the information supplied herin.

  • Page 6: Mrv Regulatory Compliance

    ® Fiber Driver EM316SW-XY 1.5 MRV Regulatory Compliance Contact your sales representative for more regulatory compliance information regarding specific MRV products or product families. Fiber Driver Chassis Compliance: FCC Part 15 (Class A); IC (Class A); EMC Directive: Emission (Class A) and Immunity;...

  • Page 7: General Safety

    ® Fiber Driver EM316SW-XY 1.6 General Safety WARNING: Two people must lift large cabinet chassis. Lift with your legs and a straight back to prevent injury. Lift with both hands, grasping underneath the lower edge. To prevent damage to the chassis and components, do not lift the chassis with the handles on the power supplies and interface processors, or by the plastic panels on the front of the chassis.

  • Page 8: Laser Safety

    ® Fiber Driver EM316SW-XY 1.8 Laser Safety WARNING: Do not open laser devices for service. Removing the cover may cause exposure to harmful laser beams. Return defective laser devices to the vendor for service. WARNING: Un-terminated connectors or fiber cable ends may emit invisible laser radiation. Do not view them directly with optical instruments such as eye loupes, magnifiers, or microscopes.

  • Page 9: Module Introduction

    ® Fiber Driver EM316SW-XY 2 Module Introduction The Fiber Driver EM316SW-XY is a highly configurable multi-function module that can perform the functions of hundreds of less sophisticated devices. The SW-XY can operate in four modes. Each of these applications is described later in this section. •...

  • Page 10: Loopback

    ® Fiber Driver EM316SW-XY 2.1.1 Loopback Loopback tests and verifies the link integrity. It is available on the fiber optic ports (P2 and P3) only, and it operates in all four operational modes. Loopback directs received data on a port to the transmitter to test the fiber optic link end-to-end from the remote converter.

  • Page 11: Link Integrity Notification (Lin)

    ® Fiber Driver EM316SW-XY 2.1.2 Link Integrity Notification (LIN) LIN is not available in switch mode. A single DIP switch (LIN EN) activates LIN for the entire module except in switch mode. If this switch is OFF, then LIN cannot be activated even through software management. In the other operational modes, ports on the EM316SW-XY are paired as converters or repeaters.

  • Page 12: Modes Of Operation

    ® Fiber Driver EM316SW-XY 2.2 Modes of Operation The EM316SW-XY supports four different operational modes. 1. Dual Repeater (Fiber and Copper) 2. Dual Converter 3. Redundant Link 4. Switch (4-Port, mixed-media) This section describes these modes and required DIP switch settings. Select the operational mode with the DIP switches labeled MODE1 and MODE0, switches 5 and 6 on switch block 1 nearest the front panel of the module.

  • Page 13: Dual Repeater (Fiber And Copper)

    ® Fiber Driver EM316SW-XY 2.2.1 Dual Repeater (Fiber and Copper) MODE1 MODE0 Figure 2 -- Dual Repeater Mode In Dual Repeater mode, the module acts as a pair of repeaters. Fiber Optic repeater between 100Base-FX ports SFP-based interfaces Copper repeater between 10/100 Base-TX ports RJ-45 copper interfaces The copper repeater can be used as a distance extender in a copper infrastructure to extend a link beyond the 300 foot (100m) limit.

  • Page 14: Dual Converter

    ® Fiber Driver EM316SW-XY 2.2.2 Dual Converter MODE1 MODE0 Figure 3 -- Dual Converter Mode In Dual Converter mode, the module incorporates two independent “copper 10/100 to Fiber Fast Ethernet converters” for the price of a single converter. This combination doubles the density of a central office chassis, allowing up to 30 converters in a managed 16-slot chassis.

  • Page 15: Redundant Link

    ® Fiber Driver EM316SW-XY 2.2.3 Redundant Link MODE1 MODE0 Figure 4 -- Redundant Link Mode In Redundant Link mode, the module acts as a copper to redundant fiber (100Base-FX) converter. This configuration requires optical SFPs installed in ports P2 and P3 to support a pair of redundant fiber optic paths.

  • Page 16: Mixed-Media Switch (4-Port)

    ® Fiber Driver EM316SW-XY 2.2.4 Mixed-Media Switch (4-Port) MODE1 MODE0 Figure 5 -- Switching Mode In Switch mode, the module acts a mixed-media Ethernet Switch with two 10/100Base-TX copper interfaces and two fiber-optic SFP-based 100 Base-FX interfaces. The mixed-media switch allows copper Ethernet traffic access to a linear fiber-optic Ethernet network.

  • Page 17: Preparation And Installation

    ® Fiber Driver EM316SW-XY 3 Preparation and Installation 3.1 Unpacking the Fiber Driver Module Step 1. Open the cardboard box. Step 2. Remove the static bag containing the module. Step 3. Check for additional or loose accessories in the box. Parts may move under the module packing tray during shipment.

  • Page 18: Front Panel Description

    ® Fiber Driver EM316SW-XY 3.2 Front Panel Description Figure 7 -- EM316SW-XY front panel The EM316SW-XY module is equipped with the following interfaces. Port 1 (1): 10/100 Base-T UTP RJ-45 Port 2 (2): 100 Base-FX, SFP- Port Port 3 (3): 100 Base-FX, SFP Port Port 4 (4): 10/100 Base-T UTP RJ-45 3.2.1 Distances Maximum distance for SFP ports is SFP dependent.

  • Page 19: Led Display Information

    ® Fiber Driver EM316SW-XY 3.2.4 LED Display Information Figure 8 -- EM316SW-XY front panel Color Solid or Blink Explanation PWR/NMS No power to unit green solid Power OK green blink At least one port in loopback P1 UTP LNK/ACT No link detected amber solid 10 Mbps link...

  • Page 20: Dip Switches

    ® Fiber Driver EM316SW-XY 3.3 DIP Switches The default configuration is established by the firmware preloaded onto the module. The EM316SW-XY is configured at the factory to work “out of the box” in “Dual Converter” mode with management enabled. Use the module in pairs to operate the EM316SW-XY in unmanaged mode. Select the functional modes with DIP switches MODE1 and MODE0 on switch block 1 (nearest the front panel).

  • Page 21: Switch Functions And Default Settings

    ® Fiber Driver EM316SW-XY 3.3.2 Switch Functions and Default Settings The switch block number is not sequential on the module. Carefully verify the switch block number and placement before changing switch settings. Switch Block 1* DIP Switch DIP Switch Name Setting Description ON (up)
  • Page 22 ® Fiber Driver EM316SW-XY Switch Block 2* (SW2) Setting DIP Switch DIP Switch Name Description Bold = Defaults ON (up) P1 Forced 100Base-T if ANEG is off FAST OFF (down) P1 Forced 10Base-TX if ANEG is off ON (up) P1 Forced Full-Duplex if ANEG is off or failed FULL OFF (down) P1 Forced Half-Duplex if ANEG is off or failed...
  • Page 23 ® Fiber Driver EM316SW-XY Switch Block 3* (SW3) DIP Switch DIP Switch Name Setting Description ON (up) P2 Far End fault Indication is used in LIN FEFI OFF (down) Far End Fault Indication is not used in LIN ON (up) P3 Far End fault Indication is used in LIN FEFI2 OFF (down)

  • Page 24: Module Installation

    ® Fiber Driver EM316SW-XY Module Installation Fiber Driver modules are hot-swappable and may be inserted into or removed from a supporting chassis at any time. Install the module into a powered Fiber Driver chassis with a cooling fan. Align the edge of the card with the rail of the chassis, slide it into the chassis until firmly seated against the backplane and hand-tighten the thumb screw.

  • Page 25: Figure 11 -- Module Installation (Not All Chassis Are Shown)

    ® Fiber Driver EM316SW-XY Step 2. Install the module inside a Fiber Driver chassis by aligning the edge of the card with the rail of the chassis. Tighten the thumbscrew by hand. Figure 11 -- Module installation (not all chassis are shown) Figure 12 -- Correctly inserted Fiber Driver module in a powered chassis Handle the module by the edges to avoid damaging any components.

  • Page 26: Cleaning Fibers

    ® Fiber Driver EM316SW-XY Cleaning Fibers Fiber optic components and cables are very sensitive to dirt, dust, and mishandling. Especially in high-speed networks such as gigabit Ethernet and OC48, dirty or mistreated fiber may cause errors and signal degradation. Prior to installation, follow the procedure below to clean fiber optic cable and transceivers. Equipment Requirements •...

  • Page 27: Working With Sfps

    ® Fiber Driver EM316SW-XY 3.3.3 Working with SFPs The pluggable optics modules used in the EM316xx products are extremely portable, and consequently may be easily mistreated. If SFPs are not protected against dust, remove the dust caps and clean them with 1.25 millimeter cleaners. Figure 15 -- SFP cleaners 3.3.3.1 Cleaning SFPs 3.3.3.1.1 Requirements...

  • Page 28: Mylar Tab Sfp Modules

    ® Fiber Driver EM316SW-XY 3.3.3.2 Mylar Tab SFP Modules The Mylar tab or nail latch on the module has a tab that you must pull in order to remove the module from a switching module port. Figure 16 -- Mylar Tab on SFP Module 3.3.3.2.1 Inserting a Mylar Tab SFP Module To insert the Mylar tab SFP module into a switching module port, line up the SFP module with the port, and slide it into place...

  • Page 29: Actuator/Button Sfp Modules

    ® Fiber Driver EM316SW-XY 3.3.3.3 Actuator/Button SFP Modules The actuator/button SFP module has a button that you must push in order to remove the SFP module from a switching module port. Figure 19 – Actuator/Button SFP Module 3.3.3.4 Inserting an Actuator/Button SFP Module To insert the actuator/button SFP module into a switching module port, line up the SFP module with the port and slide it in until the actuator/button clicks into place.

  • Page 30: Bale Clasp Sfp Module

    ® Fiber Driver EM316SW-XY 3.3.3.5 Bale Clasp SFP Module The bale clasp SFP module has a bale clasp that you use to secure the SFP\XFP module in a switching module port. Figure 22 -- Bale Clasp SFP Module 3.3.3.5.1 Inserting a Bale Clasp SFP/XFP Module into a Switching Module Port Step 1 Close the bale clasp in the upward direction before inserting the SFP module.

  • Page 31: Module Management

    ® Fiber Driver EM316SW-XY 4 Module Management Most Fiber Driver modules, including the EM316SW-XY, may be managed by a Fiber Driver network management (NM) module installed in the same chassis. The EM316SW-XY module may be managed by the EM316LNXNM-OT Network Management (NM) module.

  • Page 32: Serial Console Interface

    ® Fiber Driver EM316SW-XY 4.1 Serial Console Interface After the network management (NM) module is installed, power up the chassis and attach the serial RS-232 cable to the PC or terminal device. Configuring terminal emulation software on the PC is beyond the scope of this document. The components below may be ordered from MRV. •...

  • Page 33: Em316Lnxnm-Ot Command Line Interface (Cli)

    ® Fiber Driver EM316SW-XY 4.3 EM316LNXNM-OT Command Line Interface (CLI) The EM316LNXNM-OT provides command line interface (CLI), SNMP, and graphical administration options for a Fiber Driver chassis system. This section introduces the CLI for the Linux-based network management (EM316LNXNM-OT) module. EM316LNXNM-OT management commands are specific to each module.

  • Page 34: Em316Lnxnm-Ot Boot And Cli Login

    ® Fiber Driver EM316SW-XY 4.3.1 EM316LNXNM-OT Boot and CLI Login The box below shows the NM boot and login to the built-in admin user account. The “banner” information that displays after the login may also be displayed from the CLI prompt with the show version command.

  • Page 35: Cli Navigation

    ® Fiber Driver EM316SW-XY 4.3.2 CLI Navigation The CLI uses five operational contexts: login, configuration, chassis, slot, and port. Only the login context is not considered a configuration mode. The system prompt includes a string to indicate the current operational context, as illustrated in the example below. The “#” character ends the prompt string, and a space separates the command from the prompt.

  • Page 36: Login Context Commands And Examples

    ® Fiber Driver EM316SW-XY 4.3.3 Login Context Commands and Examples The login context refers to the only CLI state not considered a configuration context. Commands in this context are generally for system status monitoring. Use the “?” and “list” commands at the fiberdriver # prompt to display the list of command line options.

  • Page 37: Show Chassis

    ® Fiber Driver EM316SW-XY 4.3.3.2 “show chassis” The following box displays the configuration of the chassis. fiberdriver# show chassis Chassis Model Name Number Of Slots Temp(C) ======= ========== ========= =============== ======= NC316BU-16 NC316BU-1 fiberdriver# 4.3.3.3 “show slots” The following box displays information about the slots in the chassis. fiberdriver# show slots Slot Model...

  • Page 38: Show Version

    ® Fiber Driver EM316SW-XY 4.3.3.4 “show version” The show version command displays revision levels for the management system components. fiberdriver# show version EM316LNXNM-OT v4.0 fdr 58 (Jul 25 2007 - 09:34:25). U-Boot 1.0.1 (Jan 25 2005 - 11:08:25). Linux kernel v2.4.26 (#1 Wed Dec 13 10:36:44 PST 2006). EM316LNXNM (firmware 5c.13) (00:20:1a:02:48:28).

  • Page 39: Show Groups

    ® Fiber Driver EM316SW-XY 4.3.3.6 “show groups” Management access is controlled through group and user permissions. Display the current system groups and users with the commands shown below. fiberdriver# show groups System user/group configuration: username admin password encrypted $1$kQ2rIq/$Ob8wFa2EW135XC4TnN7wJ/ class super username admin group all username boss password encrypted $1$8kwjpD/$rtxpBG0AYfC7z7WxdjBuG.

  • Page 40: Show Running-Config

    ® Fiber Driver EM316SW-XY 4.3.3.8 “show running-config” fiberdriver# show running-config Building configuration... Current configuration: ! Configuration saved on 2005/01/02 00:28:18 ! Configuration written by admin! ! EM316LNXNM-OT v4.0 fdr 58 (Jul 25 2007 - 09:34:25). ! U-Boot 1.0.1 (Jan 25 2005 - 11:08:25). ! Linux kernel v2.4.26 (#1 Wed Dec 13 10:36:44 PST 2006).

  • Page 41: Show Startup-Config

    ® Fiber Driver EM316SW-XY 4.3.3.9 “show startup-config” The show startup-config command displays the contents of the startup-config file that are applied when the system boots. Default values are applied to any parameters not specified in this file. fiberdriver# show startup-config ! Configuration saved on 2005/01/01 18:59:21 ! Configuration written by admin! ! EM316LNXNM-OT v4.0 fdr 54 (Jun...

  • Page 42: Displaying And Saving System Parameters

    ® Fiber Driver EM316SW-XY 4.3.3.10 Displaying and Saving System Parameters Use the write terminal command to display the current operating parameters. fiberdriver# write terminal Building configuration... Current configuration: ! Configuration saved on 2005/01/02 00:29:12 ! Configuration written by admin! ! EM316LNXNM-OT v4.0 fdr 58 (Jul 25 2007 - 09:34:25). ! U-Boot 1.0.1 (Jan 25 2005 - 11:08:25).

  • Page 43: Configuration Context

    ® Fiber Driver EM316SW-XY 4.3.4 Configuration Context Enter "configuration" context, as shown below, to configure the system parameters. fiberdriver# configu re terminal fiberdriver(config)# The commands in this section are entered at the configuration context prompt. They are applied with the <CR> or <Enter> key, which is not printable. 4.3.4.1 Restoring Default Parameters Use the default command to discard changes applied to the module configuration.

  • Page 44: Configuring System Parameters

    ® Fiber Driver EM316SW-XY 4.3.4.2 Configuring System Parameters Once the mode is changed, the prompt also changes. Change the SUPER user password using the "username" command. fiberdriver(config)# username admin password <new password> Set the IP configuration using the "ip" command group. Set IP address and IP mask information using the following command.

  • Page 45: Chassis Context

    ® Fiber Driver EM316SW-XY 4.3.5 Chassis Context Command examples in this section are applied in the chassis-level context. The box below shows the command to navigate to the chassis context from the login context. fiberdriver# configure terminal fiberdriver(config)# fiberdriver(config)# chassis 1 fiberdriver(chassis/1)# 4.3.5.1 “show”...

  • Page 46: Other Commands

    ® Fiber Driver EM316SW-XY 4.3.5.2 Other Commands The commands available at the chassis level are consistent in Fiber Driver environments. These general system features are beyond the scope of this document. A list of available commands in the chassis context is displayed by typing “?” or “list” at the prompt. fiberdriver(chassis/1)# ? chassis Configure a chassis...

  • Page 47: Slot Context Commands And Examples

    ® Fiber Driver EM316SW-XY 4.3.6 Slot Context Commands and Examples The slot-level command context interacts with specific modules mounted in the managed chassis. Command examples in this section are applied to the module in the slot designated in the prompt. The box below shows the command to navigate to the slot context from the login context.
  • Page 48 ® Fiber Driver EM316SW-XY 4.3.6.1 “?” The “?” is a special help character in the EM316LNXNM-OT command line. In previous releases, the “?” character did not echo to the display when typed. Beginning in version 4.0, the “?” displays as other commands do. Results of the help request are displayed immediately to the monitor.

  • Page 49: List

    ® Fiber Driver EM316SW-XY 4.3.6.2 “list” The list command displays all the full command options (including applicable command line arguments) available in the current context. fiberdriver(slot/1.1)# list clear-type default all default description default me description .LINE echo echo .LINE exit list logout next...

  • Page 50: Show

    ® Fiber Driver EM316SW-XY 4.3.6.3 “show” The “show” command displays management and system information related to the EM316LNXNM-OT management module, the hosting chassis, other modules in the chassis, and ports available within the managed system. The arguments (parameters) following the show command and the operational context displayed by the system prompt control the many functions available through this command.
  • Page 51 ® Fiber Driver EM316SW-XY Display Digital Diagnostic statistics for the SFP ports with the command shown below. fiberdriver(slot/1.5)# show digital-diagnostics Port DDiags Temp(C) Supply(V) TxPower(dBm) RxPower(dBm) Bias(mA) ===== ====== ======= ========= ============ ============ ======== 1.5.2 Alarm 3.308 -6.144 -23.553 4.248 1.5.3 Alarm 3.282...
  • Page 52 ® Fiber Driver EM316SW-XY Each module may be given a descriptive name with the command below. The show command follows with the new name line in bold font. Each new slot name may also be displayed with individual show commands in each slot context. fiberdriver(slot/1.3)# description MY-SW-XY fiberdriver(slot/1.3)# up fiberdriver(chassis/1)# show...

  • Page 53: Port Context Commands And Examples

    ® Fiber Driver EM316SW-XY 4.3.7 Port Context Commands and Examples Command examples in this section are applied in the port-level context. The box below shows the command to navigate to a specific port context from the login context. fiberdriver# configure terminal fiberdriver(config)# port 1.3.1 fiberdriver(port/1.3.1)# 4.3.7.1 “?”...
  • Page 54 ® Fiber Driver EM316SW-XY The box below shows the output of the “?” typed alone on the command line in the port-level configuration context. The box below is specific to the RJ-45 copper ports (P1 and P4) of the EM316SW-XY modules. fiberdriver(port/1.3.1)# ? auto-neg-adv Adjust auto-negotiation advertisement...
  • Page 55 ® Fiber Driver EM316SW-XY The box below is specific to the SFP ports (P2 and P3) of the EM316SW-XY modules in NON-REDUNDANT operational modes including the DEFAULT configuration. Notice the differences in the command list that reflect the capabilities of the target port. fiberdriver(port/1.3.2)# ? default Restore parameter(s) to defaults...
  • Page 56 ® Fiber Driver EM316SW-XY The box below is specific to the SFP ports (P2 and P3) of the EM316SW-XY modules in REDUNDANT mode. Notice the differences in the command list from the same port in a non-redundant mode. • shutdown is no longer available •...

  • Page 57: List

    ® Fiber Driver EM316SW-XY 4.3.7.2 “list” The list command displays all the full command options (including applicable command line arguments) available in the current context. 4.3.7.3 “show” The show command displays management and system information related to the EM316LNXNM-OT management module, the hosting chassis, other modules in the chassis, and ports available within the managed system.
  • Page 58 ® Fiber Driver EM316SW-XY The box below illustrates the show command with no arguments in the port context of an SFP port with an optical transceiver in an EM316SW-XY module. fiberdriver(port/1.3.2)# show Port: 1.3.2 Name: SFP at 1.3.2 Part #/Rev: SFP-DGD-SX/A Protocol: Ethernet Rate: 100Base-Tx 100 Mbps Enable: enable...

  • Page 59: Description

    ® Fiber Driver EM316SW-XY 4.3.7.4 “description” As with a module at the slot level, a descriptive name may be applied to each port. An example of the description command at the port level is shown below. fiberdriver(port/1.3.1)# description SWXY-port1 fiberdriver(port/1.3.1)# show Port: 1.3.1 Name: SWXY-port1 Protocol: Ethernet...

  • Page 60: Show Defaults

    ® Fiber Driver EM316SW-XY 4.3.7.5 “show defaults” Default settings are listed in the show defaults command output. These parameters reflect the module boot configuration which is determined by DIP switches and firmware programming. All lines in this display begin with “!” to indicate that they are comments for information only.

  • Page 61: Show Config

    ® Fiber Driver EM316SW-XY 4.3.7.6 “show config” The show config command displays the active environment settings currently in the operational context. The lines beginning with “!” are comments added for clarity in the CLI display only. The comment lines ending with “:” are headings that describe the settings listed in this display.

  • Page 62: Lin

    ® Fiber Driver EM316SW-XY 4.3.7.8 “lin” The lin commands enable and disable the Lin Integrity Notification function on the target port. fiberdriver(port/1.3.1)# lin fdrd[60]|CORE| warn|Jan 01 19:25:50 1.3.4: Auto-adjusted PortLIN -> enable Ok fdrd[60]|TRAP| warn|Jan 01 19:25:52 Port 1.3.1 LIN On, Chassis Name: NC316BU-16 Slot Name: EM316SW-XY at 1.3 Port Name: RJ-45 at 1.3.1 fdrd[60]|TRAP| warn|Jan 01 19:25:52 Port 1.3.4 LIN On, Chassis Name: NC316BU-16...

  • Page 63: Port Commands

    ® Fiber Driver EM316SW-XY 4.3.8 RJ-45 Port Commands The commands in this section are specific to the RJ-45 Ethernet (copper) ports P1 and P4 on the EM316SW-XY module. 4.3.8.1 “auto-neg-adv” This command sets the data rates displayed as options in auto-negotiation. fiberdriver(port/1.3.1)# auto-neg-adv? auto-neg-adv Adjust auto-negotiation advertisement...

  • Page 64: Mdi-Pinout

    ® Fiber Driver EM316SW-XY 4.3.8.3 “mdi-pinout” This command sets the mdi/mdix pinout for the target port. fiberdriver(port/1.3.1)# mdi-pinout? mdi-pinout Adjust MDI/MDI-X auto-sense fiberdriver(port/1.3.1)# mdi-pinout ? auto-sense Autodetect MDI/MDI-X mdix MDI-X fiberdriver(port/1.3.1)# mdi-pinout auto-sense fdrd[60]|CORE| warn|Jan 01 21:55:54 1.3.1: Auto-adjusted PortAutoNegotiation -> off Ok fdrd[60]|CORE| warn|Jan 01 21:55:54 1.3.1: Auto-adjusted PortDuplex ->...

  • Page 65: Sfp Port Commands

    ® Fiber Driver EM316SW-XY 4.3.9 SFP Port Commands The following commands are specific to the SFP ports on the EM316SW-XY module. 4.3.9.1 “loopback” This command activates the loopback function on the target port. fiberdriver(port/1.3.2)# loopback fiberdriver(port/1.3.2)# fdrd[60]|TRAP| warn|Jan 01 21:30:07 Port 1.3.2 Loopback On, Chassis Name: NC316BU-16 Slot Name: EM316SW-XY at 1.3 Port Name: SFP at 1.3.2 fiberdriver(port/1.3.2)#...

  • Page 66: Select-Link

    ® Fiber Driver EM316SW-XY 4.3.9.3 “select-link” In Redundant Link mode, the “select link” command attempts to activate the target redundant port, P2 or P3. If the selected port does not have an available link, then the other redundant port is tried. The module selects the first established SFP interface link, port P2 or P3, as the primary link.

  • Page 67: Configuration Examples

    ® Fiber Driver EM316SW-XY 4.4 Configuration Examples Each operational mode is represented below with the “show” command. 4.4.1 Repeater Mode MODE1 MODE0 In this mode, the module acts as a pair of repeaters. • Fiber Optic Repeater between the two 100Base-FX SFP based interfaces •...
  • Page 68 ® Fiber Driver EM316SW-XY fiberdriver# show 1.3.1 Port: 1.3.1 Name: RJ-45 at 1.3.1 Protocol: Ethernet Rate: 10Base-T 10 Mbps Enable: enable LIN: disable Link: no Signal Speed: 10 Mbps MDI Pinout: mdi Duplex: half MDI Pinout desired: auto Sense Auto Neg: on Adv 10Base-T: on Adv 100Base-Tx: on Connector: RJ45...

  • Page 69: Converter Mode

    ® Fiber Driver EM316SW-XY 4.4.2 Converter Mode MODE1 MODE0 In Converter mode, ports P1 and P2 are paired and ports P3 and P4 are paired. Each pair links a copper port to an SFP port, which will generally have an optical SFP transceiver installed to convert between media.
  • Page 70 ® Fiber Driver EM316SW-XY fiberdriver# show 1.3.1 Port: 1.3.1 Name: RJ-45 at 1.3.1 Protocol: Ethernet Rate: 10Base-T 10 Mbps Enable: enable LIN: disable Link: no Signal Speed: 10 Mbps MDI Pinout: mdi Duplex: half MDI Pinout desired: auto Sense Auto Neg: on Adv 10Base-T: on Adv 100Base-Tx: on Connector: RJ45...
  • Page 71 ® Fiber Driver EM316SW-XY fiberdriver# show 1.3.3 Port: 1.3.3 Name: SFP at 1.3.3 Part #/Rev: SFP-GDCWXD-59/B Protocol: Ethernet Rate: 100Base-Tx 100 Mbps Enable: enable LIN: disable Link: no Signal Speed: 100 Mbps Nom. BR: 1300 Duplex: full Revertive: no Loopback: off Serial Number: 48OAC7353S Vendor Info: MRV COMM, INC.

  • Page 72: Redundant Mode

    ® Fiber Driver EM316SW-XY 4.4.3 Redundant Mode MODE1 MODE0 iberdriver# show 1.3 Slot: 1.3 Model: EM316SW-XY Name: EM316SW-XY at 1.3 Hardware Revision: 1, FPGA 0x68 Sw Configurable: yes Operation Type: redundant Redundancy: enabled Number Of Ports: 4 Port Enable Link Speed DDiags WL(nm)

  • Page 73: Switching Mode

    ® Fiber Driver EM316SW-XY 4.4.4 Switching Mode MODE1 MODE0 fiberdriver# show 1.3 Slot: 1.3 Model: EM316SW-XY Name: EM316SW-XY at 1.3 Hardware Revision: 1, FPGA 0x68 Sw Configurable: yes Operation Type: switch Number Of Ports: 4 Port Enable Link Speed DDiags WL(nm) Name =====...
  • Page 74 ® Fiber Driver EM316SW-XY Ports P2 & P3 (SFP) fiberdriver# show 1.3.2 Port: 1.3.2 Name: SFP at 1.3.2 Part #/Rev: SFP1250ZXCWDM/1.1 Protocol: Ethernet Rate: 100Base-Tx 100 Mbps Enable: enable Link: no Signal Speed: 100 Mbps Nom. BR: 1300 Duplex: full Revertive: no Loopback: off Serial Number: 33BE125099...

  • Page 75: Appendix

    This section provides basic troubleshooting to rectify the most common issues with the EM316SW- XY. If the information provided in this section and in this manual do not resolve the issue, please do not hesitate to contact MRV Communications Customer Support or your local MRV sales representative.
