Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PC DISPLAY
PICTURE IN PICTURE (PIP)
TELETEXT
This device is a Class B digital apparatus.
Register your product at www.samsung.com/global/register
LCD TV
LA26R7
LA32R7
LA40R7

Advertisement

Table of Contents
loading

Summary of Contents for Samsung LA26R7

  • Page 1 LCD TV LA26R7 LA32R7 Contact SAMSUNG WORLD-WIDE LA40R7 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Samsung Electronics Australia 7 Parkview Drive, Homebush Bay NSW 2127 1300 362 603 www.samsung.com/au Owner’s Instructions...
  • Page 2 • Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention. This image retention is also known as "screen burn". To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image. •...
  • Page 3: Table Of Contents

    Contents CONNECTING AND PREPARING YOUR TV SETTING THE OTHERS List of Parts ................2 Using Game Mode............19 Installing the Stand ..............2 Setting the Blue Screen Mode / Installing the Wall Mount Kit ........... 2 Selecting the Melody ............. 19 Viewing the Control Panel............3 Using the Energy Saving Feature ........
  • Page 4: List Of Parts

    Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
  • Page 5: Viewing The Control Panel

    Viewing the Control Panel The product colour and shape may vary depending on the model. SOURCE Toggles between all the available input sources (TV, AV1, Press to change channels. AV2, S-Video, Component1, Component2, PC, HDMI, In the on-screen menu, use the buttons DTV).
  • Page 6: Viewing The Connection Panel

    Viewing the Connection Panel [Side Panel Jacks] [Rear Panel Jacks] (26 inch model does not (32 inch/40 inch) have the side panel jacks.) Power Input [Rear Panel Jacks] (26 inch) Whenever you connect an external device to your TV, make sure that power on the unit is turned off. When connecting an external device, match the colour of the connection terminal to the cable.
  • Page 7 Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial / A cable television network / A satellite network Connecting HDMI/DVI - Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers and digital TVs).
  • Page 8: Viewing The Remote Control

    Viewing the Remote Control Selects a target device to be Exit the OSD controlled by the Samsung remote control Control the cursor in the menu (TV, DVD, STB, CABLE, VCR) Use to see information on the Television Standby button current broadcast...
  • Page 9: Switching On And Off

    Switching On and Off The mains lead is attached to the rear of your set. Plug the mains lead into an appropriate socket. The standby indicator lights up on the front of the set. Press the button on the front of the set. You also can press the POWER button or the TV/DTV button on the remote control to turn the TV on.
  • Page 10: Storing Channels Automatically

    If you want to reset this feature... 1. Press the MENU button to display the menu. Press the button to select “Setup”, then press the ENTER button. 2. Press the ENTER button again, to select “Plug & Play”. 3. The message to “Start Plug & Play” is displayed. - Storing Channels Automatically - Storing Channels Manually Storing Channels Automatically...
  • Page 11: Setting The Channel Manager

    Press the button to select “Colour System”, then press the ENTER button. Select the colour standard required by pressing the button then, press the ENTER button. Press the button to select “Sound System”, then press the ENTER button. Select the sound standard required by pressing the button, then press the ENTER button.
  • Page 12: Activating The Child Lock

    Activating the Child Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by muting out video and audio. Child Lock can- not be released using the buttons on the side. Only the remote control can release the Child Lock setting, so keep the remote control away from children.
  • Page 13: Assigning Channels Names

    Assigning Channels Names Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names. Press the MENU button to display the menu. Press the button to select “Channel”, then press the ENTER button.
  • Page 14: Lna (Low Noise Amplifier)

    LNA (Low Noise Amplifier) If the TV is operating in a weak-signal area, the LNA function can improve the reception (a low-noise preamplifier boosts the incoming signal). 1. Press the MENU button to display the menu. Press the button to select "Channel", then press the ENTER button.
  • Page 15: Changing The Colour Tone

    Changing the Colour Tone You can select the most comfortable colour tone to your eyes. To select the desired picture effect, follow the “Changing the Picture Standard” instructions number 1 to 4 on page 12. Press the button to select “Colour Tone”, then press the ENTER button.
  • Page 16: Digital Noise Reduction

    4. Press the EXIT button to exit. DNIe Demo (Digital Natural Image engine) Samsung’s new technology brings you more detailed images with contrast and white enhancement. A new image compensation algorithm gives viewers brighter and clearer images. DNIe technology will match every signal to your eyes.
  • Page 17: Changing The Sound Standard

    8. Press the button to select “Programme” and then press the ENTER but- ton. You can select the channel that you want to view through sub picture by pressing button. Press the ENTER button. The “Programme” can be active when the sub picture is set to TV. 9.
  • Page 18: Connecting Headphones

    Connecting Headphones You can connect a set of headphones to your set if you wish to watch a TV programme without disturbing the other people in the room. When you insert the head set jack into the corresponding port, you can operate only "Internal Mute" and "Sound Select" (in PIP mode) in Sound menu. Prolonged use of headphones at a high volume may damage your hearing.
  • Page 19: Listening To The Sound Of The Sub Picture

    Listening to the Sound of the Sub Picture During the PIP features activation, you can listen to the sound of the sub picture. 1. Press the MENU button to display the menu. Press the button to select “Sound”, then press the ENTER button.
  • Page 20: Setting The Sleep Timer

    Setting the Sleep Timer You can select a time period of between 30 and 180 minutes after which the televi- sion automatically switches to standby mode. 1. Press the MENU button to display the menu. Press the button to select “Setup”, then press the ENTER button.
  • Page 21: Using Game Mode

    Using Game Mode When connecting to a game console such as PlayStation or Xbox you can enjoy a more realistic gaming experience by selecting game menu. 1. Press the MENU button to display the menu. Press the button to select “Setup”, then press the ENTER button.
  • Page 22: Using The Energy Saving Feature

    Using the Energy Saving Feature This function adjusts the brightness of the TV so as to reduce power consumption. When you watching TV at night, set the "Energy Saving " mode option to "High" so as to reduce the dazzling of your eyes as well as the power consumption. Press the MENU button to display the on-screen menu.
  • Page 23: Previewing The Dtv Menu System

    Previewing the DTV Menu System To help you navigate around the on-screen menu system and adjust the various settings available, refer to the following illustration. Available in the Digital TV mode. Press the D.MENU button. Guide Now & Next Guide Full Guide Scheduled List Default Guide...
  • Page 24: Updating The Channel List Manually

    Updating the Channel List Manually You can specify the channel or frequency for a fast channel search. Press the D.MENU button to display the DTV menu. Press the button to select "Channel", then press the ENTER button. Press the button to select "Manual Store", then press the ENTER button.
  • Page 25: Selecting Channel Manager

    Move Press the D.MENU button to display the DTV menu. Press the button to select "Channel", then press the ENTER button. Press the button to select "Edit Favourite Channels", then press the ENTER button. Select the required channel using the button.
  • Page 26: Displaying Programme Information

    Displaying Programme Information While viewing a channel, additional information about the current programme may be displayed. While viewing a programme, press the INFO ( ) button. The programme information is displayed. To exit from banner information, press the INFO ( ) button.
  • Page 27: Using The Scheduled List

    Using the Scheduled List If you make a scheduled viewing list of programs you may like to see, the channel will be automatically switched to the scheduled program at the scheduled time even if you are watching another program. Press the D.MENU button to display the DTV menu. Press the ENTER button, to select "Guide".
  • Page 28: Viewing All Channels And Favourite Channels

    Viewing All Channels and Favourite Channels In the EPG menu, you can display all channels or favourite channels. Press the D.MENU button to display the DTV menu. Press the ENTER button again, to select "Guide". Select the your required guide ("Now & Next Guide" or "Full Guide") by pressing the button.
  • Page 29: Setting Up The Parental Lock

    Setting up the Parental Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by a 4-digit PIN (Personal Identification Number) code that is defined by the user. The on-screen menu will instruct you to assign a PIN code (you can change it later, if necessary).
  • Page 30: Selecting The Preferred Language (Subtitle Or Audio)

    Press the EXIT button to exit. Viewing Product Information You can view your product information. For service or repair, please contact a Samsung approved dealer. Press the D.MENU button to display the DTV menu. Press the button to select "System", then press the ENTER button.
  • Page 31: Checking The Signal Information

    Checking the Signal Information You can get information about the signal status. Press the D.MENU button to display the DTV menu. Press the button to select "System", then press the ENTER button. Press the button to select "Signal Information", then press the ENTER button.
  • Page 32: Selecting The Time Zone

    Selecting the Time Zone Select the time zone where locate Press the D.MENU button. Press the button to select System. Press the button to select Time Zone. Select the time zone where you locate by pressing the button. Press the ENTER button.
  • Page 33: Teletext Decoder

    Teletext Decoder Most set channels carry “ teletext ”, pages of written information that provide information such as: Television programme times. News bulletins and Weather forecasts. Sports results. Subtitles for the hard of hearing. The teletext pages are organized according to six categories: Part Contents Selected page number.
  • Page 34: Selecting A Specific Teletext Page

    Selecting a Specific Teletext Page Press the number buttons on the remote control to enter the page number directly: 1. Enter the three-digit page number listed in the contents by pressing the correspond- ing numeric buttons. 2. If the selected page is linked with several secondary pages, the secondary pages are displayed in sequence.
  • Page 35: Setting The Pc

    Setting the PC Coarse and Fine Tuning of the Image (Image Lock): The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (coarse) and Fine-tune again. After the noise has been reduced, re-adjust the picture so that it is aligned on the center of screen.
  • Page 36: Setting Up Your Pc Software (Based On Windows Xp)

    Windows and your particular video card. Even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manu- facturer or Samsung Dealer.) 1. First, click on “Control Panel” on the Windows start menu.
  • Page 37: Using The Anti-Theft Kensington Lock

    Using the Anti-Theft Kensington Lock The Kensington lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer.
  • Page 38: Technical And Environmental Specifications

    Technical and Environmental Specifications Model Name LA26R7 LA32R7 LA40R7 26 inch 32 inch 40 inch Screen Size (Diagonal) AC 220-240 V 50 Hz AC 220-240 V 50 Hz AC 220-240 V 50 Hz Power Supply 120 W 152 W 190 W Power Consumption 1360 x 768 @ 60 Hz 1360 x 768 @ 60 Hz...
