INSTALLATION MANUAL
VEHICLE SECURITY SYSTEM
CE-SS200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CE-SS200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fusion CE-SS200

Summary of Contents for Fusion CE-SS200

  • Page 1 INSTALLATION MANUAL VEHICLE SECURITY SYSTEM CE-SS200...

  • Page 2: Table Of Contents

    From our product, to our demo cars, to our events, FUSION is about • ADJUSTING THE SENSITIVITY LEVEL ......pg 8 making some noise.

  • Page 3: Programming Remotes

    PROGRAMMING REMOTES ALARM FEATURES PROGRAMMING: ALARM FEATURE “I” PROGRAMMING: 1. Turn the ignition switch ‘OFF/ON’ 3 times (within 15 seconds) and leave in the ON position. 1. Turn the ignition ‘switch ‘ON/OFF’ 3 times (within 15 seconds) and leave in the OFF position on the 3rd time. 2.
  • Page 4 ALARM FEATURE “II” PROGRAMMING: ALARM FEATURE “III” PROGRAMMING: 1. Turn the Ignition ‘switch ‘ON/OFF’ 3 times (within 15 seconds), 1. Turn the ignition ‘switch ‘ON/OFF’ 3 times (within 15 seconds), and leave in the OFF position. and leave in the OFF position. 2.

  • Page 5: Adjusting The Sensitivity Level

    ADJUSTING THE SENSITIVITY LEVEL OF THE SHOCK SENSOR WIRING DIAGRAM 1. Turn the ignition ‘switch ‘ON/OFF’ 3 times (within 15 seconds) and leave in the OFF position. 2. Push the valet switch 6 times and hold on the 6th push until three short chirps and one long chirp is heard, and then release the valet 6 Pin switch.

  • Page 6: Central Locking Diagrams

    A: CENTRAL LOCKING DIAGRAMS B: 6 PIN MINI CONNECTOR WIRE HARNESS: (After market Door Motors) INSTALLING DOOR LOCK MOTORS (2 WIRE) Green/ white Blue/ white 1. Violet Wire: Positive Door Pin Switch Input Blue/ red 2. Blue Wire: Instant Trigger Ground Input Green/ red 3.
  • Page 7 POSITIVE TRIGGER DOOR LOCK SYSTEM 2 STEP DOOR UNLOCK WIRE CONNECTIONS FOR 5 WIRE ALTERNATING DOOR LOCKS + 12V Green / white M aster + 12V OEM Door Master Lock Locking Blue / white Switch Red / White +12V Unlock Door Lock Door unlock Lock...

  • Page 8: Specifications

    Note: Remote control range is dependant on weather conditions and Lock Relay alarm installation. OEM Driver's Door Lock Motor THE FUSION CE-SS200 SECURITY SYSTEM COMPLIES WITH: To All Other Door Lock Cut Existing Unlock Motors FCC: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
  • Page 9 • • Specifications and design are subject to change without notice • •...
