- Page 1 D2203D Disp Menu Audio Video Exit BND/ BND/ MUTE D2203D...
-
Page 3: Table Of Contents
Thank you for buying this product, please read through these operating instructions, so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference . CONTENTS PRECAUTIONS FRONT PANEL... -
Page 4: Precautions
PRECAUTIONS 1. Be sure to connect the color coded leads according to the diagram. Incorrect connec- tions may cause the unit to malfunction or damage the vehicles electrical system. 2. Be sure to connect the speaker (-) leads to the speaker (-) terminal. Never connect the left and right channel speaker cables each other or to the vehicle body. - Page 5 PRECAUTIONS This unit can play the following discs only: Recorded material Size of disc Type of disc Label on the disc Sound and moving 12cm pictures V I D E O Sound and moving 12cm pictures Sound only 12cm 12cm Sound only NOTE: The unit is compatible with VCD1.0/2.0/3.0 version and DVCD disc.
-
Page 6: Front Panel
FRONT PANEL BAND/ BAND/ MUTE MUTE... - Page 7 FRONT PANEL 1.AUX IN Connect the audio cable to the unit then you can enjoy the music. 2. PWR/MUTE Press the button to turn on the unit and press and hold the button to turn off the unit. In power on, press to shut off the sound output and press it again to resume previous sound. 3.
-
Page 8: Touching Control Operation
MENU SYSTEM The users can perform operation by touching screen directly. Radio Operation Page1 1. HALF LIGHT MODE Turn on /off the backlight. (The function can be used to change the screen brightness while traveling at night) 2. SOURCE To display the SOURCE screen 3.Station preset button To display the preset station list (touch one of the station preset button to recall the radio which stored on the position;... - Page 9 RDS Operation EON:OFF REG:OFF 87.50MHz PTY:NONE PTY: Seek- Seek+ Page2 1.TA To turn on /off TA function 2.AF To turn on /off AF function 3.PTY To switch RDS program type 4.Page2 To switch to radio operation page. 5.SEEK-/SEEK+ To seek a station automatically. To seek a station manually(long touch).
-
Page 10: Bluetooth Operation
1.PLAY To start the playback. 2.PAUSE To pause the playback. 3.STOP To stop playing, touch twice to stop completely. 4.MENU To display the DVD SETUP screen. 5.PREV/NEXT To select previous/next chapter or track. NOTE:T ouching the left middle position twice to display the TITLE MENU selection screen, touching the right middle position twice to display the ROOT MENU selection screen, touching the right top position to display the number keyboard. - Page 11 The phone book screen To display a telephone number list of the received calls To display a telephone number list of the dialed calls To display a telephone number list of the received but you missed 4. >> To change the list page The Bluetooth Setup screen 1.
-
Page 12: Setup Operation
Setup Operation TOUCH ON THE TOP LEFT POSITION TO ENTER SOURCE INTERFACE. The unit will return to the previous mode if no operation is performed in 5 seconds. Disp Menu Audio Video Exit 1.Menu To display the source selection screen. Disp Menu Audio... - Page 13 TOUCHING CONTROL OPERATION 3.Audio Touch on the AUDIO button and the screen will display as following: Volume L-front R-front Menu Disp Audio Video Exit In this menu, there are items of Volume, L-front,R-fornt, L-rear, R-rear , Subwoof, Bass, Middle and Treble can be adjusted. Touch on the button to adjust each item and touch on button to turn pages and select the item listed above.
-
Page 14: System Setup Operation
SYSTEM SETUP OPERATION Clock Sys Switch page button Key Beep Local Area Disp Audio Video Exit Menu Clock Sys Set the time display mode(12H/24H) Key Beep Turn on/off the sound guide function ON:activate the sound guide mode OFF:deactivate the sound guide mode. The sound guide beep will not be produced when a button on the unit is pressed. - Page 15 Subwoof freq BassQ factor MidQ factor Menu Audio Video Exit Disp Touch the provided option to change the sub woof ,the bass and middle quality factor. Back Bright Back light Menu Audio Video Exit Disp Back Bright(dimmer) The function to adjust the brightness of the backlighting for easier viewing. (Normal status's 20%,40%,60%,80% ) Back light The function to set the backlighting duration.(normal status's off,15s,30s,60s)
- Page 16 Clock Adjust Touch Adjust Menu Audio Video Exit Disp Clock Adjust Adjust the time by touch To select the desired item then set up (hour, minute, second) To change the display number Touch Adjust When the display position on the screen and the touch position on the touch panel do not match, or using the product at first time, the adjustment becomes necessary.
-
Page 17: Remote Control
REMOTE CONTROL 1.PWR/ 2. EQ/ 3. ANGLE/AMS 4. SUB-T/LOC 5. PROG/A-B 6. OSD/ 7. GOTO/ 8. MENU ][ / / / ]/ENTER 10. RPT /PTY 12. ZOOM/AF SRC/IR-SW 14. VOL-/SEL/VOL+ 16. LOUD/ 17. 0-9 Number button 18. CLEAR 20. TITLE 22. -
Page 18: Installing The Battery
REMOTE CONTROL Installing the battery Slide the tray out on the back of the remote control and insert the battery with the plus (+)and minus(-)poles pointing in the proper direction. Use and care of the remote control oint the remote control in the direction of the front panel to operate to use it. Notes: Using batteries improperly can cause them to explode. - Page 19 REMOTE CONTROL 1. POWER/ Press the button to turn on the unit; Press and hold for 1 second or longer to turn off the unit. In power on, p ress to mute the device. Press it again to resume previous sound level. 2.
- Page 20 /PTY In radio mode, press this button to switch to RDS program type. In DVD/VCD mode, press to play slowly. 12. ZOOM/AF In radio mode, press this button to function AF on/off. In DVD/VCD mode, press to increase or decrease the picture in size. 13.
-
Page 21: Basic Operation
BASIC OPERATION ¼ ò µ ¥ ¹ Ê Õ Ï Å Å ³ ý Ö ¸ Ä Ï 1.Reset the Unit Operating the unit for the first time or after replacing the car battery, you must reset the unit.Press RESET button on the head unit with a pointed object, (such as a ballpoint pen) to set the unit to initial status. -
Page 22: Radio Operation
RADIO OPERATION Selecting the radio mode, the TFT display as the follows: Display the current status Page1 1.Band Selector In radio mode, repeatedly press BAND button on the remote control to select a band in the following order: *Pressing BAND on the touchable screen or on the panel also performs the same operation. 2.Manual/Automatic Tuning (1).Automatic Tuning: Press button on the remote control to search for a station in... - Page 23 (2).It is switched to DX mode when Loc: OFF is pressed again. Both strong and weak stations can be received. Note: The initial mode is DX mode. .MO/ST Selector In FM of radio mode, you can press ST button on the remote control to select Mono mode or Stereo mode.
- Page 24 PTY(Programme Type)Tuning The PTY function allows you to search for stations with a particular Program Type. Touching Page1 button on the radio display screen to switch to the RDS screen EON:OFF REG:OFF 87.50MHz PTY:NONE PTY: Page2 Seek- Seek+ 1.Press PTY button on touchable screen or on the remote control to select a programme type.
-
Page 25: Bluetooth Operation
*Due to some special mobile phone, you may not be able to use a hands-free phone. CONNECTING selecting B T mode Press PAIR button on touchable screen to turn on the par function Searching for device(EONON) by using mobile phone Selecting bluetooth device (EONON) by using mobile phone Input a pass code:1234 The connection is made The screen displays CONNECTED. - Page 26 Dialling a call Input the number required by pressing number button on the remote control or on the screen then press button on the screen to dial up. The telephone number you dial ed is appeared on the screen 2.Placing a call by history: Press button to switch to PHONE BOOK screen.
- Page 27 BLUETOOTH AUDIO FUNCTION Audio information of a bluetooth compatible mobile phone, portable player, etc., is by wireless controllable/playable from the unit. Refer to CONNECT to connect bluetooth audio devices. Refer to bluetooth setup(PAGE6) for operation *video playback is not supported. *using remote control also perform same operation The key of the remote control assigned in Bluetooth audio function Play/pause...
-
Page 28: Tv Operation
DVB-T OPERATION This equipment will serve you with the available received channels supplied by the mobile signals. Press SRC button on the panel or on the remote control or touch on the left top of the screen then select TV mode. Touch at random area to start the operation. -
Page 29: Dvd/Vcd/Cd Operation
/VCD/CD OPERATIONS Loading a disc 1.Press button to open the front panel. 2. Insert a disc into the Disc slot the unit switch to the DVD mode automatically * You can eject a disc by pressing button on the unit. Quick track selection fast forward/fast reward playback During playback mode, press button to select next/previous chapter or track. - Page 30 Normal Play 1 16 This function is operated by using the remote control. Increase or decrease the size of the picture During DVD/VCD playback, press ZOOM button to increase or decrease the picture size. There are 6 sizes, and press the button repeatedly to change the size in following order. *This function is operated by using the remote control.
- Page 31 Selecting different title (DVD mode) For DVD disc, you can press TITLE on the remote control to return the top menu of the disc, and you can select different chapter or title upward or downward by using *Touching the screen also perform the same function(refer to page 7 Multi-player operation for detail).
-
Page 32: System Setup
SYSTEM SETUP When you press SETUP button on the remote control, or press SETUP button on the screen, the setup menu will be displayed. It includes General Setting, Audio Setup, Preference ,Password Setup and Exit Setup menu. 1.Within the setup menu, you can use buttons on the remote control to move the cursor, and then press the ENTER button to make your selection.Press can return to the previous menu. - Page 33 User can select digital audio setup or dolby digital setup. AUDIO SETUP PAGE DIGITAL AUDIO DOLBY DIGITAL SETUP GO TO AUDIO SETUP PAGE 2.1 DIGITAL OUTPUT SETUP DIGITAL AUDIO PAGE SPDIF OFF DIGITAL OUTPUT 48KHz SPDIF RAW LPCM OUTPUT SPDIF PCM SETUP SPDIF - SPDIF OFF: An analog surround sound format is output through the back-panel connections for L,R,LS,RS and centre speakers, and the subwoofer simulation.
- Page 34 PREFERENCE PAGE AUDIO ENGLISH FRENCH SUBTITLE SPANISH DISC MENU PORTUGUES PARENTAL JAPANESE DEFAULT KOREAN RUSSIAN THAI PREFERRED AUDIO LANGUAGE 3.2 SUBTITLE SUBTITLE: Sets the preferred subtitle language as the default when playing DVD.(if DVD support these languages). PREFERENCE PAGE AUDIO ENGLISH FRENCH SUBTITLE...
- Page 35 PREFERENCE PAGE AUDIO SUBTITLE DISC MENU PARENTAL DEFAULT RESET LOAD FACTORY SETTING 4. PASSWORD SETUP PAGE 4.1 PASSWORD MODE PASSWORD MODE: Sets the function operation to locking the parental function. ON: Using the parental control must input the password. OFF: You can not input the password to change the parental control. * The initial password is 136900.
- Page 36 SETTING THE TV SCREEN SIZE Multi-aspect ratios suit to different TV screen size. TV Screen Size Picture format 16:9 on Disc Pan Scan Letter-box Wide Screen 16:9 Function supported by DVD discs There are many functions available on DVD discs and the functions vary per player and per manufacturer.
-
Page 37: Mp3 Operation
MP3 OPERATION Playing a disc, an SD/MMC card or a USB device containing files Connect a USB device or press button to open the front panel, insert a disc into the disc slot or SD/MMC card into the card slot. The unit will automatically switch on when a disc, card or USB device is inserted. - Page 38 Stop playing When playing MP3 files, press button on the remote control to stop playback. Pause playback Press the button on the remote control or press PAUSE button on the touchable screen while playing, press it again or press PLAY button on the touchable screen to return to normal playback.
-
Page 39: Installation
INSTALLATION Notes Before finally installing the unit, connect the wiring temporarily, making sure it is all connected up properly, and the unit and the system work properly. Use only the parts included with unit to ensure proper installation. The use of unauthorized parts can cause malfunctions. - Page 40 INSTALLATION Install the unit After inserting the holder into the dash-board,select the appropriate tabs according to the thickness of the dash-board material and bend them.(Install as firmly as possible using the top and bottom tabs. To secure, bend the tabs 90 degrees.) Insert the keys supplied to the unit at both sides of the unit (shown as illustrated)until they click.
-
Page 41: Trouble Shooting
TROUBLE SHOOTING Common problems Symptom Remedy Cause Power doesn't switch ON . Leads and connectors are Confirm once more that all connections The unit doesn't operate. incorrectly connected. are correct. A fuse has blown. Fix the problem causing the blown fuse and replace the old fuse with a new one of the same capacity. - Page 42 Problem during DVD playback Symptom Remedy Cause Playback is not possible The loaded disc has a different Replace the disc with one featuring the region number from this unit same region number as this unit Dialog language (and The DVD playing does not You cannot switch among multiple subtitle language) can not feature multiple language...
-
Page 43: Cable Connection
CABLE CONNECTION DVB-T ACCESSORIES Mounting Bracket (Half Sleeve) -------------------------------------------------------X1 Removable Trim Ring equipped on the unit ----------------------------------------X1 Mounting Screw M5 --------------------------------------------------------------------- X1 Washer ------------------------------------------------------------------------------------- X1 Rubber ------------------------------------------------------------------------------------- X1 Remote Control --------------------------------------------------------------------------- X1 ount strap -------------------------------------------------------------------------------- X1 Release key ------------------------------------------------------------------------------- X2 User manual ----------------------------------------------------------------------------- X1... -
Page 44: Specification
SPECIFICATON GENERAL power requirement ---------------------------------------------- 12VDC(10.8~16V) grounding system ------------ -------------------------------- ----------- negative type max: current consumption ------- -------------------------------------------- ---- 15 A max: power output -------- ----------------------------------------------- ------- 65Wx4 load impedance --------------- ------------------------------------ ------- dimensions-------------------------------------------- 180(L) 160(W) 100(H) weight--------------------------------------------------------------------------------3.3KG DVD PLAYER S/N ratio ------ -------------------------------------------------- more than 62dB(1kHz)
