Frigidaire FRT18S6A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18S6A
  6. Factory parts catalog
Frigidaire FRT18S6A Factory Parts Catalog

Frigidaire FRT18S6A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18S6A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
N05L00002.eps N05DCDBCA1.eps N05BBAABA22.eps N05SAAAFI14.eps
N05CABBAB5.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Product No.
FRT18S6AWJ
Series
R134a
Color
white
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America
Energy Guide
218791400
Service Data Sheet
240379015
Installation Instructions 240568300
Publication No.
5995433090
05/04/04
(EN/SERVICE/RF)
390
Copyright
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18S6A
©
2005 Home Pr
oducts, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18S6A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18S6A

Summary of Contents for Frigidaire FRT18S6A

  • Page 1 Product No. FRT18S6AWJ Series R134a Color white Volts Wiring Diagram 240398801 Owner's Guide 240400112 Market North America Energy Guide 218791400 Service Data Sheet 240379015 Installation Instructions 240568300 TOP-MOUNT N05L00002.eps N05DCDBCA1.eps N05BBAABA22.eps N05SAAAFI14.eps REFRIGERATOR N05CABBAB5.eps 240398801.eps 240398601.eps Model No. ELECTROLUX HOME PRODUCTS, INC. FRT18S6A P.O.
  • Page 2 Publication No: 5995433090 FRT18S6AWJ DOOR N05DCDBCA1 04/05...
  • Page 3 FRT18S6AWJ Publication No: 5995433090 DOOR POS. NO PART NO. DESCRIPTION 240542103 Gasket-frzr door, white, magnetic 240542106 Gasket-refr door, white, magnetic 240337703 Door-dairy, w/o graphics, clear 240381301 Plug-button, white, hinge brg hole, (2) 240409901 Panel-frzr door, white, complete assy 240416301 Label-nameplate, white 240312403 Door Stop, white, ref 240312404...
  • Page 4 Publication No: 5995433090 FRT18S6AWJ CABINET N05BBAABA22 04/05...
  • Page 5 FRT18S6AWJ Publication No: 5995433090 CABINET POS. NO PART NO. DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240462010 Cover-evap coil 240568601 Seal-coil cover 241520701 Harness-wiring, freezer 5303208309...
  • Page 6 Publication No: 5995433090 FRT18S6AWJ SHELVES 04/05...
  • Page 7 FRT18S6AWJ Publication No: 5995433090 SHELVES POS. NO PART NO. DESCRIPTION 215667501 Tray, ice cube, plastic 240358005 Shelf, freezer, full-width, wire 5303299664 Spacer, shelf 241542001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241559801 Socket-light 240352701...
  • Page 8 Publication No: 5995433090 FRT18S6AWJ SYSTEM N05CABBAB5 04/05...
  • Page 9 FRT18S6AWJ Publication No: 5995433090 SYSTEM POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 240581701 Harness-wiring, machine compt 240581801 Harness-wiring, compressor 241520701 Harness-wiring, freezer 6* # 240388701 Wiring Harness, control box 14 # 5303918208 Defrost Heater Kit 15 # 5303918274 Evaporator Kit...

  • Page 10: Wiring Schematic

    Publication No: 5995433090 FRT18S6AWJ WIRING SCHEMATIC 04/05...

  • Page 11: Wiring Diagram

    FRT18S6AWJ Publication No: 5995433090 WIRING DIAGRAM 04/05 # Functional Parts * Non-Illustrated Parts...
