SPECIFICATIONS
GENERAL
Fine quality sink bowl seamlessly formed of #18 gauge, type
304 nickel bearing stainless steel. Self-rimming.
DESIGN FEATURES
Bowl Depth: 8-1/4".
Coved Corners: 3" vertical and 2-1/4" horizontal radius.
Bowl and Faucet Deck Recess: 3/8" below outside edge of sink.
Finish: Exposed surfaces are polished to a non-directional soft
satin finish.
Underside: Sound absorbing pads applied to dampen sound.
OTHER
Drain Opening: 3-1/2".
NOTE: Unless otherwise specified, sink is furnished with 4
faucet holes as shown.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKRB1520 or LKERBSS.
Cutting Boards: CB1516 or CB1713.
This sink complies with ANSI Standard A112.19.3M.
SINK DIMENSIONS (INCHES)*
Overall
Inside Bowl
Model
Number
L
W
L
EG2522
25
22
21 15
*Length is left to right. Width is front to back.
4"
4"
4"
5"
3" R
21"
25"
2-1/4" R
Model EG25224 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
Cutout in
No. of
Countertop
1
1
/
" Dia.
1
(1
/
" Radius
2
2
Faucet
Corners)
Holes
W
D
L
W
4" Center
3
1
3
3
/
8
/
24
/
21
/
1, 2, MR2, 3, 4 or 5
4
4
8
8
22"
15-3/4"
8-1/4"
2222 Camden Court
Oak Brook, IL 60523
elumina
TM
by Elkay Single Bowl Sink
Model EG25224
HOLE DRILLING CONFIGURATIONS
Minimum
Ship.
Cabinet
Wt.
Size
Lbs.
1
30
16
/
2
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Model EG2522
1
4"
2
4"
MR2
4"
4"
3
4"
4"
4"
4
4"
4"
4"
4"
5
Printed in U.S.A.
©2004 Elkay
1-198
(4/04)
