Eclipse CD3000 Installation Manual page 9

2) CD3000 + CH3083 + 21010 + Power Amplifer
TO SIGNAL INPUT
OF EXTERNAL
POWER
AMPLIFIER
21010
(sold
separately)
NO CONNECTION
(Do not remove cap)
13P
2P
TO GROUND
INTERCONNECTING WIRES
(supplied with CH3083)
TO TURN-ON WIRE OF EXTERNAL EQUIPMENT (Supply)
NO CONNECTION (Do not remove cap)
NO CONNECTION (Do not remove cap)
Yellow
TO BATTERY+12V
(Permanent Supply)
CH3083
(sold separately)
TO ACC (Power Supply)
TO POWER ANTENNA RELAY (Supply)
TO HEAD LIGHT SWITCH (Illumination (+) )
TO GROUND
2
- 9 -
NON-FADER
1 MAIN UNIT
ANTENNA PLUG
13P
16P
White
White/Black
Yellow
Gray
Gray/Black
Green
Red
Green/Black
Blue
Purple
Orange/White
Purple/Black
Blue/White
Brown
TO STEERING REMOTE CONTROL
Brown/Black
Black
INTERCONNECTING WIRES
(Power and speaker connector)
INSULATE EACH WIRE WITH NONE
CONDUCTING TAPE SUCH AS
PLASTIC TAPE OR ANOTHER
INSULATING METHOD
INSULATE EACH WIRE WITH NONE
CONDUCTING TAPE SUCH AS
PLASTIC TAPE OR ANOTHER
INSULATING METHOD
