P08F0092.eps P08D0584.eps P08C1149.eps P08S0472.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
GLRH1779GW2
Series
Gallery
Color
white
Volts
115
Wiring Diagram 297005300
Owner's Guide 297208700
Market
North America
Energy Guide
297226503
Publication No.
5995526224
08/10/14
(EN/SERVICE/MLR)
365
Copyright
REFRIGERATOR
Model No.
GLRH1779GW
©
2008 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire Gallery GLRH1779GW
Summary of Contents for Frigidaire Gallery GLRH1779GW
- Page 1 Product No. GLRH1779GW2 Series Gallery Color white Volts Wiring Diagram 297005300 Owner's Guide 297208700 Market North America Energy Guide 297226503 REFRIGERATOR P08F0092.eps P08D0584.eps P08C1149.eps P08S0472.eps Model No. Electrolux Major Appliances GLRH1779GW North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 Publication No.
- Page 2 Publication No: 5995526224 GLRH1779GW2 DOOR P08D0584 10/08...
- Page 3 GLRH1779GW2 Publication No: 5995526224 DOOR POS. NO PART NO. DESCRIPTION 216522309 Gasket-door, white 240338313 Door, dairy, clear 216953601 Panel-inner door, refr 297245219 Panel-outer door, white 241808701 Nameplate 297254100 Door Stop, RH 240536809 Handle-door, white 240537301 Nut-anchor, door hdl screw 297048000 Screw, anchor, #8, white 297197500 Screw, door stop mtg, FH38-16X.750, P Twin...
- Page 4 Publication No: 5995526224 GLRH1779GW2 CABINET 148B 148A P08C1149 10/08...
- Page 5 GLRH1779GW2 Publication No: 5995526224 CABINET POS. NO PART NO. DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 297200600 Breaker Kit w/corners, no lock slot 297200100 Breaker Kit w/corners, 32", top and bottom 13 # 216934100 Motor, fan, 115 V 216998000 Switch, light/lamp, ramp 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V 297048600...
- Page 6 Publication No: 5995526224 GLRH1779GW2 CABINET 148B 148A P08C1149 10/08...
- Page 7 GLRH1779GW2 Publication No: 5995526224 CABINET POS. NO PART NO. DESCRIPTION 297130200 Channel-shelf mtg, side, (2) 5304460601 Screw, 6-20AB x 3/8 148A 297092502 Frame-crisper cover, lower 148B 297092503 Frame-deli cover 297053000 Wire, jumper 5303313703 Clip, (2) 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2) 297092700 Bracket, crisper cover, RH 297092701...
- Page 8 Publication No: 5995526224 GLRH1779GW2 SYSTEM 10/08...
- Page 9 GLRH1779GW2 Publication No: 5995526224 SYSTEM POS. NO PART NO. DESCRIPTION 297152200 Condenser, dynamic 5308000110 Strap-evap/heater, aluminum, (2) 216938600 Drier-filter 297171800 Harness-main 240555002 Screw-#8-32 X 3/8 216730700 Heater-defrost 15 # 216997300 Evaporator 297231800 Heat Exchanger 297078700 Insulator-evap, styrofoam 297078800 Insulator-evap, styrofoam 216731001 Thermostat, defrost 23 #...
