Product No.
FRT21BW8DB1 FRT21BW8DB3
Series
Water-tru-door
Color
black
Volts
115
Wiring Diagram
241582401
Owner's Guide
241567602
Market
North America
Energy Guide
241538775
Service Data Sheet
241588200
Installation Instructions 241567800
W241582401.eps S241582801.eps
Publication No.
5995433892
05/04/12
(EN/SERVICE/WC)
390
Water-tru-door
black
115
241582401
241567602
North America
241538775
241588200
241567800
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21BW8D
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21BW8D
Summary of Contents for Frigidaire FRT21BW8D
- Page 1 Product No. FRT21BW8DB1 FRT21BW8DB3 Series Water-tru-door Water-tru-door Color black black Volts Wiring Diagram 241582401 241582401 Owner's Guide 241567602 241567602 Market North America North America Energy Guide 241538775 241538775 Service Data Sheet 241588200 241588200 Installation Instructions 241567800 241567800 TOP-MOUNT Branded WTD.eps N05DCDBBA12.eps N05BAAAAC9.eps N05SACAFC15.eps REFRIGERATOR WITH N05CAAAAC3.eps 115-2.eps W241582401.eps S241582801.eps...
- Page 2 Publication No: 5995433892 FRT21BW8D DOOR 21 14B 50 44 N05DCDBBA12 04/05...
- Page 3 FRT21BW8D Publication No: 5995433892 DOOR Model Index: A FRT21BW8D (FRT21BW8DB1) B FRT21BW8D (FRT21BW8DB3) POS. NO PART NO. DESCRIPTION 240514611 Gasket, seal, black, frzr door, magnetic 240514612 Gasket, seal, black, refr door, magnetic 240338303 Door, dairy, clear 240450350 Door, frzr, black, complete assy 240572601 Label-nameplate 240312405...
- Page 4 Publication No: 5995433892 FRT21BW8D CABINET N05BAAAAC9 04/05...
- Page 5 FRT21BW8D Publication No: 5995433892 CABINET Model Index: A FRT21BW8D (FRT21BW8DB1) B FRT21BW8D (FRT21BW8DB3) POS. NO PART NO. DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240313609 Cover-evap coil, w/light...
- Page 6 Publication No: 5995433892 FRT21BW8D SHELVES N05SACAFC15 04/05...
- Page 7 FRT21BW8D Publication No: 5995433892 SHELVES Model Index: A FRT21BW8D (FRT21BW8DB1) B FRT21BW8D (FRT21BW8DB3) POS. NO PART NO. DESCRIPTION 240358003 Shelf, freezer, full-width, wire 5303299664 Spacer, shelf 240545901 Diffuser-air, top 240362601 Diffuser, air, bottom 241554901 Switch-light/lamp 241555401 Light Bulb 241552802 Light Bulb 241513901 Socket-light 241507803...
- Page 8 Publication No: 5995433892 FRT21BW8D SYSTEM N05CAAAAC3 04/05...
- Page 9 FRT21BW8D Publication No: 5995433892 SYSTEM Model Index: A FRT21BW8D (FRT21BW8DB1) B FRT21BW8D (FRT21BW8DB3) POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 241572201 Harness-wiring, machine compt 241566801 Harness-wiring, c/box M/Level 6* # 241537701 Wiring Harness, freezer section, with light 14 # 5303918247 Defrost Heater Kit...
-
Page 10: Ice Maker
Publication No: 5995433892 FRT21BW8D ICE MAKER 04/05... - Page 11 FRT21BW8D Publication No: 5995433892 ICE MAKER Model Index: A FRT21BW8D (FRT21BW8DB1) B FRT21BW8D (FRT21BW8DB3) POS. NO PART NO. DESCRIPTION 218976901 Tube-water inlet, inlet valve, to ice maker 240561701 Seal-water inlet, inlet valve, to ice maker 241566501 Tube-water inlet, valve to I.M. 241566502 Tube-water inlet, valve to tank 241566503...
-
Page 12: Wiring Schematic
Publication No: 5995433892 FRT21BW8D WIRING SCHEMATIC 04/05... -
Page 13: Wiring Diagram
FRT21BW8D Publication No: 5995433892 WIRING DIAGRAM 04/05 # Functional Parts * Non-Illustrated Parts...
