Quick Links
N05L00003.eps N05DCDBBA11.eps N05BBAABA17.eps N05SAAAFI21.eps
N05CAABAD4.eps
W241582401.eps S241582801.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRT18HS7JS0
Series
R134a
Color
stainless
Volts
115
Wiring Diagram
241582401
Owner's Guide
241857201
Market
North America
Energy Guide
241935580
Service Data Sheet
241588203
Installation Instructions 240568303
Publication No.
5995533121
09/02/11
(EN/SERVICE/DCS)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18HS7J
©
Copyright
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18HS7J
Summary of Contents for Frigidaire FRT18HS7J
- Page 1 Product No. FRT18HS7JS0 Series R134a Color stainless Volts Wiring Diagram 241582401 Owner's Guide 241857201 Market North America Energy Guide 241935580 Service Data Sheet 241588203 Installation Instructions 240568303 TOP-MOUNT N05L00003.eps N05DCDBBA11.eps N05BBAABA17.eps N05SAAAFI21.eps REFRIGERATOR N05CAABAD4.eps W241582401.eps S241582801.eps P.O. BOX 212378 Model No. AUGUSTA, GA 30917 FRT18HS7J Publication No.
- Page 2 Publication No: 5995533121 FRT18HS7JS0 DOOR 21 14B N05DCDBBA11 02/09...
- Page 3 FRT18HS7JS0 Publication No: 5995533121 DOOR POS. NO PART NO. DESCRIPTION 241872509 Gasket-frzr door, black, magnetic 241872512 Gasket-refr door, black, magnetic 240338313 Door, dairy, clear 241623305 Door, frzr, stainless, RH, complete assy 241808601 Label-nameplate 240312405 Door Stop, black, refr 240312406 Door Stop, black, frzr 240383603 Plug-button, black, door handle 241623405...
- Page 4 Publication No: 5995533121 FRT18HS7JS0 CABINET 02/09...
- Page 5 FRT18HS7JS0 Publication No: 5995533121 CABINET POS. NO PART NO. DESCRIPTION 241652301 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 241652214 Cover-evap coil 240568601 Seal-coil cover 5303208309 Plug-hole, factory test 241557601...
- Page 6 Publication No: 5995533121 FRT18HS7JS0 SHELVES N05SAAAFI21 02/09...
- Page 7 FRT18HS7JS0 Publication No: 5995533121 SHELVES POS. NO PART NO. DESCRIPTION 240358005 Shelf, freezer, full-width, wire 241542001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 241555401 Light Bulb 241559801 Socket-light 240352702 Control Box 240568607 Seal 17*# 240388701 Wiring Harness, control box 240360801 Knob, temp control 21 #...
- Page 8 Publication No: 5995533121 FRT18HS7JS0 SYSTEM 24 25 N05CAABAD4 02/09...
- Page 9 FRT18HS7JS0 Publication No: 5995533121 SYSTEM POS. NO PART NO. DESCRIPTION 241873404 Condenser 218944002 Drier-filter, R134a System 241607001 Harness-wiring, machine compt 240388701 Wiring Harness, control box 14 # 240356221 Heater-defrost 15 # 5303918274 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2) 241801301 Trough-drain 241551902 Insulation Block 21 #...
-
Page 10: Wiring Schematic
Publication No: 5995533121 FRT18HS7JS0 WIRING SCHEMATIC 02/09... -
Page 11: Wiring Diagram
FRT18HS7JS0 Publication No: 5995533121 WIRING DIAGRAM 02/09 # Functional Parts * Non-Illustrated Parts...
