PRODUCT NO.
FRT18HS6AQ6
FRT18HS6AW6
MARKET
North America
ENERGY GUIDE - 240465032
OWNER'S GUIDE - 240400107
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FRT18HS6A
R134a
FRT18HS6A
R134a
Publication No.
5995383162
-EN/SERVICE /DCS
COLOR
bisque
white
021219
390
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18HS6A
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18HS6A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18HS6A

Summary of Contents for Frigidaire FRT18HS6A

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT18HS6AQ6 FRT18HS6A FRT18HS6AW6 FRT18HS6A MARKET North America ENERGY GUIDE - 240465032 OWNER’S GUIDE - 240400107 SERVICE DATA SHEET - 240379010 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a bisque R134a...
  • Page 2 Publication No. FRT18HS6A 5995383162 DOOR 12/02...
  • Page 3 A = FRT18HS6A (FRT18HS6AQ6) B = FRT18HS6A (FRT18HS6AW6) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18HS6A DOOR PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2)
  • Page 4 Publication No. FRT18HS6A 5995383162 CABINET 12/02...
  • Page 5 A = FRT18HS6A (FRT18HS6AQ6) B = FRT18HS6A (FRT18HS6AW6) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18HS6A CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
  • Page 6 Publication No. FRT18HS6A 5995383162 SHELVES 12/02...
  • Page 7 A = FRT18HS6A (FRT18HS6AQ6) B = FRT18HS6A (FRT18HS6AW6) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18HS6A SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top...
  • Page 8 Publication No. FRT18HS6A 5995383162 SYSTEM 12/02...
  • Page 9 A = FRT18HS6A (FRT18HS6AQ6) B = FRT18HS6A (FRT18HS6AW6) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18HS6A SYSTEM...

  • Page 10: Wiring Schematic

    Publication No. FRT18HS6A 5995383162 WIRING SCHEMATIC 12/02...

  • Page 11: Wiring Diagram

    FRT18HS6A Publication No. 5995383162 WIRING DIAGRAM # = Fast-moving Parts 12/02 * = Non-Illustrated Parts...
