PRODUCT NO.
BASE MODEL NO.
FRT21TSGD2
FRT21TSG
FRT21TSGW2
FRT21TSG
MARKET
North America
WIRING DIAGRAM - 193832
OWNER'S GUIDE - 218613700
SERVICE DATA SHEET - 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995316444
981230
-EN/SERVICE /ECL
357
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT21TSG
©1998 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT21TSG
Summary of Contents for Frigidaire FRT21TSG
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21TSGD2 FRT21TSG R134a System almond FRT21TSGW2 FRT21TSG R134a System white MARKET North America WIRING DIAGRAM - 193832 OWNER’S GUIDE - 218613700 SERVICE DATA SHEET - 218755000 REFRIGERATOR 101 Masters Blvd. Model No.
- Page 2 Publication No. FRT21TSG 5995316444 DOOR 12/98...
- Page 3 FRT21TSG Publication No. 5995316444 DOOR A = FRT21TSG (FRT21TSGD2) B = FRT21TSG (FRT21TSGW2) POS. NO PART NO DESCRIPTION 215608903 Gasket-frzr door,almond ,magnetic 215608913 Gasket-frzr door,white ,magnetic 218730610 Gasket-refr door,almond ,magnetic 218730609 Gasket-refr door,white ,magnetic 218658901 Panel-inner door,refr 215139854 Rack-door,4 5303007295 Support-door rack,RH 5303007297 Support-door rack,LH...
- Page 4 Publication No. FRT21TSG 5995316444 CABINET 12/98...
- Page 5 FRT21TSG Publication No. 5995316444 CABINET A = FRT21TSG (FRT21TSGD2) B = FRT21TSG (FRT21TSGW2) POS. NO PART NO DESCRIPTION 5304402655 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5303001388 Plug-button,white 5300157666 Bushing-motor mtg,(2) 218754500 Screw,hex hd ser wshr ,#8-18 x 3/8 5303205118 Bracket-motor mtg,front 218802800...
- Page 6 Publication No. FRT21TSG 5995316444 SHELVES 12/98...
- Page 7 FRT21TSG Publication No. 5995316444 SHELVES A = FRT21TSG (FRT21TSGD2) B = FRT21TSG (FRT21TSGW2) POS. NO PART NO DESCRIPTION 218651901 Mullion,almond 218651900 Mullion,white 218781002 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218866101 Top Panel-refr 5303001380 Screw,truss head ,8-10 x 1.750 218866000 Divider,styrofoam 8* # 218878600 Harness-wiring,control/divider...
- Page 8 Publication No. FRT21TSG 5995316444 SYSTEM P05C0101 12/98...
- Page 9 FRT21TSG Publication No. 5995316444 SYSTEM A = FRT21TSG (FRT21TSGD2) B = FRT21TSG (FRT21TSGW2) POS. NO PART NO DESCRIPTION 218657100 Condenser 5303017691 Spacer-tube 5304406039 Spacer-tube,5/8 OD x 3" lg 5304406040 Spacer-tube,5/8 OD x 12" lg 5304406721 Spacer-tube,5/8 OD x .81"lg 5304406722 Spacer-tube,5/8 OD x 2"...
-
Page 10: Ice Maker
Publication No. FRT21TSG 5995316444 ICE MAKER 12/98... - Page 11 FRT21TSG Publication No. 5995316444 ICE MAKER A = FRT21TSG (FRT21TSGD2) B = FRT21TSG (FRT21TSGW2) POS. NO PART NO DESCRIPTION 5308010366 Tube-water inlet,93" ,plastic ,cut-to-length 3206348 Spring,shut-off arm 3206299 Plate-I.D. 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 1/4 3206306 Motor-ice maker 3206312 Spacer-holding sw 3206313...
-
Page 12: Wiring Schematic
Publication No. FRT21TSG 5995316444 WIRING SCHEMATIC 12/98... -
Page 13: Wiring Diagram
FRT21TSG Publication No. 5995316444 WIRING DIAGRAM # = Fast-moving Parts 12/98 * = Non-Illustrated Parts...
