Frigidaire FRT21S6A Factory Parts Catalog

Frigidaire FRT21S6A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT21S6A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
N05L00003.eps N05DCDBCA1.eps N05BBAABA17.eps N05SACAFI17.eps
N05CAAAAA27.eps
W241582401.eps S241582801.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRT21S6AMH
Series
R134a
Color
silver mist
Volts
115
Wiring Diagram
241582401
Owner's Guide
241857200
Market
North America
Service Data Sheet
241588203
Installation Instructions 240568303
Publication No.
5995500955
07/09/28
(EN/SERVICE/KHB)
137
Copyright
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21S6A
©
2007 Home Pr
oducts, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21S6A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21S6A

Summary of Contents for Frigidaire FRT21S6A

  • Page 1 Product No. FRT21S6AMH Series R134a Color silver mist Volts Wiring Diagram 241582401 Owner's Guide 241857200 Market North America Service Data Sheet 241588203 Installation Instructions 240568303 TOP-MOUNT N05L00003.eps N05DCDBCA1.eps N05BBAABA17.eps N05SACAFI17.eps REFRIGERATOR N05CAAAAA27.eps W241582401.eps S241582801.eps x Major Appliances Model No. North & Latin America FRT21S6A P.O.
  • Page 2 Publication No: 5995500955 FRT21S6AMH DOOR N05DCDBCA1 09/07...
  • Page 3 FRT21S6AMH Publication No: 5995500955 DOOR POS. NO PART NO. DESCRIPTION 241872511 Gasket-frzr door, black, magnetic 241872512 Gasket-refr door, black, magnetic 240337703 Door-dairy, w/o graphics, clear 240381306 Plug-button, silver mist, hinge brg hole 241798428 Door-frzr, silver mist, complete assy 241808601 Label-nameplate 240312405 Door Stop, black, refr 240312406...
  • Page 4 Publication No: 5995500955 FRT21S6AMH CABINET 09/07...
  • Page 5 FRT21S6AMH Publication No: 5995500955 CABINET POS. NO PART NO. DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303212803 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240313612 Cover-evap coil, w/o light 240568606 Seal-coil cover 10*# 240524701 Wiring Harness, freezer section...
  • Page 6 Publication No: 5995500955 FRT21S6AMH SHELVES N05SACAFI17 09/07...
  • Page 7 FRT21S6AMH Publication No: 5995500955 SHELVES POS. NO PART NO. DESCRIPTION 240358006 Shelf, freezer, full-width, wire 240545901 Diffuser-air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 241555401 Light Bulb 241559801 Socket-light 240368102 Control Box 17*# 240388701 Wiring Harness, control box 240360801 Knob, temp control 5304445058...
  • Page 8 Publication No: 5995500955 FRT21S6AMH SYSTEM N05CAAAAA27 09/07...
  • Page 9 FRT21S6AMH Publication No: 5995500955 SYSTEM POS. NO PART NO. DESCRIPTION 241682903 Condenser, dynamic 218944001 Drier-filter, R134a System 241607001 Harness-wiring, machine compt 6* # 240388701 Wiring Harness, control box 6* # 240524701 Wiring Harness, freezer section 14 # 240356217 Heater-defrost 15 # 5303918274 Evaporator Kit 5308000110...

  • Page 10: Wiring Schematic

    Publication No: 5995500955 FRT21S6AMH WIRING SCHEMATIC 09/07...

  • Page 11: Wiring Diagram

    FRT21S6AMH Publication No: 5995500955 WIRING DIAGRAM 09/07 # Functional Parts * Non-Illustrated Parts...
