Elkay Avado EFU471810DB Specifications

SPECIFICATIONS

GENERAL
Highest quality sink fabricated of #16 gauge, type 304 (18-8)
nickel bearing stainless steel. Reversible design allows the sink
to be rotated so the work area may be on the left.
DESIGN FEATURES
Bowl Depth: 10".
Coved Corners: Zero radius.
Finish: Exposed surfaces are polished to a bright satin finish.
Underside: Fully protected by heavy duty Sound Guard
coating to dampen sound and prevent condensation.
OTHER
Drain Opening: 3-1/2".
NOTE: All Elkay undermount sinks are designed to attach
to the underside of any solid surface countertop.
This sink complies with ASME A112.19.3.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKWRB1116SS (small bowl), LKWRB1316SS
(large bowl), LKWERBSS (large bowl).
Utensil Caddy for Rinsing Basket: LKWUCSS.
Bottom Grid: LKWBG1116SS (small bowl).
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W
1 1
EFU471810DB 47 / 18 /
4 2
*
Length is left to right. Width is front to back
**
Template and countertop mounting clips are packed with every sink.
16"
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
elkayusa.com
®
Inside Large Bowl Inside Small Bowl
L W D L W D
1
16 16 10 11 / 16 10
2
.
47-1/4"
11-1/2" 16"
1-1/2"
2222 Camden Court
Oak Brook, IL 60523
Undermount Double Bowl Sink with Work Area
® under-
Work Area
Cutout in
L W D Countertop
See
1 1
16 16 / to 1 /
2 2
Template**
18-1/2"
16"
MOUNTING
BRACKET
1/8" Countertop
Overhang
(EFU Models)
1/2"
10"
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Avado
Model EFU471810DB
Model EFU471810DB
Minimum
Cabinet
Size
51
Installation Profile of EFU Models
The template provided with each
EFU sink provides the only type of
installation recommended by Elkay.
FASTENER
(NOT FURNISHED)
1-3/8" + 1/4"
_
™ Collection
COUNTERTOP
SILICONE CAULK
(NOT FURNISHED)
SINK
1/8 (APPROX.)
OVERHANG
Printed in U.S.A.
©2007 Elkay
1-238
(3/07)
