Frigidaire FRSHB5EH Parts Catalog

Side-by-side refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
N58L00001.eps N58FCCBBC3.eps N58RCCBBB11.eps N58BAAAAB3.eps
N58SKBCBD1.eps N58TCAAAB4.eps N58CAAAAA10.eps N58XBAAAB1.eps
N58YAAAAA4.eps N58I1151.eps W241725001.eps S241725001.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRSHB5EHPB2 FRSHB5EHPW2 FRSHB5EHSB2
Series
R134a
Color
black (smooth) white (smooth)
Volts
115
Wiring Diagram
241725001
Owner's Guide
241856000
Market
North America
Energy Guide
241768173
Service Data Sheet 240389633
Publication No.
5995493268
07/06/20
(EN/SERVICE/KHB)
137
R134a
R134a
stainless
115
115
241725001
241725001
241856000
241856000
North America
North America
241768173
241768174
240389633
240389633
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRSHB5EH
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRSHB5EH

Summary of Contents for Frigidaire FRSHB5EH

  • Page 1 Product No. FRSHB5EHPB2 FRSHB5EHPW2 FRSHB5EHSB2 Series R134a R134a R134a Color black (smooth) white (smooth) stainless Volts Wiring Diagram 241725001 241725001 241725001 Owner's Guide 241856000 241856000 241856000 Market North America North America North America Energy Guide 241768173 241768173 241768174 Service Data Sheet 240389633 240389633 240389633 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995493268 FRSHB5EH FREEZER DOOR 06/07...
  • Page 3 FRSHB5EH Publication No: 5995493268 FREEZER DOOR Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 241674806 A - C Gasket-frzr door, black, magnetic 241674802 - B - Gasket-frzr door, white, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C...

  • Page 4: Refrigerator Door

    Publication No: 5995493268 FRSHB5EH REFRIGERATOR DOOR N58RCCBBB11 06/07...
  • Page 5 FRSHB5EH Publication No: 5995493268 REFRIGERATOR DOOR Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 241674805 A - C Gasket-refr door, black, magnetic 241674801 - B - Gasket-refr door, white, magnetic 240323002 A B C Bin-door, pseudo, bottom 240326203 A B C...
  • Page 6 Publication No: 5995493268 FRSHB5EH CABINET N58BAAAAB3 06/07...
  • Page 7 FRSHB5EH Publication No: 5995493268 CABINET Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 240435912 A B C Cover-air duct 240475911 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 240505801 A B C Switch, light/lamp...
  • Page 8 Publication No: 5995493268 FRSHB5EH SHELVES N58SKBCBD1 06/07...
  • Page 9 FRSHB5EH Publication No: 5995493268 SHELVES Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 241510604 A B C Trim-basket 241657602 A B C Shelf, flip up, wire 241657504 A B C Shelf, fixed, upper, freezer 240324101 A B C Shelf-pizza...
  • Page 10 Publication No: 5995493268 FRSHB5EH CONTROLS N58TCAAAB4 06/07...
  • Page 11 FRSHB5EH Publication No: 5995493268 CONTROLS Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995493268 FRSHB5EH SYSTEM N58CAAAAA10 06/07...
  • Page 13 FRSHB5EH Publication No: 5995493268 SYSTEM Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A B C Harness-wiring, machine compt...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995493268 FRSHB5EH ICE & WATER DISPENSER N58XBAAAB1 06/07...
  • Page 15 FRSHB5EH Publication No: 5995493268 ICE & WATER DISPENSER Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976915 A B C Tube-water inlet, inlet valve, to filter 218976418 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No: 5995493268 FRSHB5EH ICE CONTAINER 37A 34 34 33 N58YAAAAA4 06/07...
  • Page 17 FRSHB5EH Publication No: 5995493268 ICE CONTAINER Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 241716101 A B C Auger-ice 241685201 A B C Cam-drive 241734001 A B C Container-ice, bucket only 241685101 A B C Drum-ice disp 241735301...

  • Page 18: Ice Maker

    Publication No: 5995493268 FRSHB5EH ICE MAKER 06/07...
  • Page 19 FRSHB5EH Publication No: 5995493268 ICE MAKER Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976915 A B C Tube-water inlet, inlet valve, to filter 218976418 A B C Tube-water inlet, inlet valve, to filter 218976419...
  • Page 20 Publication No: 5995493268 FRSHB5EH ICE MAKER 06/07...
  • Page 21 FRSHB5EH Publication No: 5995493268 ICE MAKER Model Index: A FRSHB5EH (FRSHB5EHPB2) B FRSHB5EH (FRSHB5EHPW2) C FRSHB5EH (FRSHB5EHSB2) POS. NO PART NO. DESCRIPTION 240363602 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 A B C Bracket-leveling, ICE MAKER...

  • Page 22: Wiring Schematic

    Publication No: 5995493268 FRSHB5EH WIRING SCHEMATIC AIR FILTER B E T A C O N T R O L FF THERMISTOR FRZ THERMISTOR 06/07...

  • Page 23: Wiring Diagram

    FRSHB5EH Publication No: 5995493268 WIRING DIAGRAM WHITE WHITE GRAY GRAY 06/07 # Functional Parts * Non-Illustrated Parts...
