Frigidaire FRS23R4C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS23R4C
  6. Factory parts catalog
Frigidaire FRS23R4C Factory Parts Catalog

Frigidaire FRS23R4C Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS23R4C:
Table of Contents

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FACBBB4.eps N58RACBBB6.eps N58BAAAAA0.eps
N58SJCAAB1.eps N58TAAAAA6.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRS23R4CB6 FRS23R4CB7 FRS23R4CQ6 FRS23R4CQ7 FRS23R4CW6 FRS23R4CW7
R134a
R134a
R134a
black
black
bisque
115
115
115
241526901
241526901
241526901
240581300
240581300
240581300
North America North America North America North America North America North America
240572128
240572128
240572128
240389616
240389616
Publication No.
5995416335
04/09/14
(EN/SERVICE/KHB)
357
R134a
R134a
R134a
bisque
white
white
115
115
115
241526901
241526901
241526901
240581300
240581300
240581300
240572128
240572128
240572128
240389616
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23R4C
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS23R4C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS23R4C

Summary of Contents for Frigidaire FRS23R4C

  • Page 1 Product No. FRS23R4CB6 FRS23R4CB7 FRS23R4CQ6 FRS23R4CQ7 FRS23R4CW6 FRS23R4CW7 Series R134a R134a R134a R134a R134a R134a Color black black bisque bisque white white Volts Wiring Diagram 241526901 241526901 241526901 241526901 241526901 241526901 Owner's Guide 240581300 240581300 240581300 240581300 240581300 240581300 Market North America North America North America North America North America North America Energy Guide 240572128...

  • Page 2: Freezer Door

    Publication No: 5995416335 FRS23R4C FREEZER DOOR 09/04...
  • Page 3 FRS23R4C Publication No: 5995416335 FREEZER DOOR Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 240390608 A B - - - - Gasket-frzr door, black, magnetic 240390604 - - C D E F Gasket-frzr door, white...

  • Page 4: Refrigerator Door

    Publication No: 5995416335 FRS23R4C REFRIGERATOR DOOR 09/04...
  • Page 5 FRS23R4C Publication No: 5995416335 REFRIGERATOR DOOR Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 240390607 A B - - - - Gasket-refr door, black, magnetic 240390603 - - C D E F Gasket-refr door, white, magnetic...
  • Page 6 Publication No: 5995416335 FRS23R4C CABINET 09/04...
  • Page 7 FRS23R4C Publication No: 5995416335 CABINET Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 240435905 A B C D E F Cover-air duct 240475906 A B C D E F Cover-evap coil, lower 5303208309...
  • Page 8 Publication No: 5995416335 FRS23R4C SHELVES 09/04...
  • Page 9 FRS23R4C Publication No: 5995416335 SHELVES Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 240338801 A B C D E F Shelf-freezer, flip-up 240338701 A B C D E F Shelf-freezer, fixed wire 240338703...
  • Page 10 Publication No: 5995416335 FRS23R4C CONTROLS N58TAAAAA6 09/04...
  • Page 11 FRS23R4C Publication No: 5995416335 CONTROLS Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E F Fan Blade, red, evaporator fan 241563601 A B C D E F Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995416335 FRS23R4C SYSTEM N58CAAAAA4 09/04...
  • Page 13 FRS23R4C Publication No: 5995416335 SYSTEM Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 240333602 A B C D E F Condenser 218679606 A B C D E F Block-evap coil, styrofoam, (2) 218944001 A B C D E F...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995416335 FRS23R4C ICE & WATER DISPENSER 09/04...
  • Page 15 FRS23R4C Publication No: 5995416335 ICE & WATER DISPENSER Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube-water-DOOR 218976901 A B C D E F...

  • Page 16: Ice Container

    Publication No: 5995416335 FRS23R4C ICE CONTAINER 37A 34 34 33 N58YBAAAA1 09/04...
  • Page 17 FRS23R4C Publication No: 5995416335 ICE CONTAINER Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 5304428402 A B C D E F Auger-ice 5304404343 A B C D E F Cam-drive 218815300...

  • Page 18: Ice Maker

    Publication No: 5995416335 FRS23R4C ICE MAKER 09/04...
  • Page 19 FRS23R4C Publication No: 5995416335 ICE MAKER Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube-water-DOOR 218976901 A B C D E F Tube-water inlet, inlet valve, to ice maker 218976904...
  • Page 20 Publication No: 5995416335 FRS23R4C ICE MAKER 09/04...
  • Page 21 FRS23R4C Publication No: 5995416335 ICE MAKER Model Index: A FRS23R4C (FRS23R4CB6) B FRS23R4C (FRS23R4CB7) C FRS23R4C (FRS23R4CQ6) D FRS23R4C (FRS23R4CQ7) E FRS23R4C (FRS23R4CW6) F FRS23R4C (FRS23R4CW7) POS. NO PART NO. DESCRIPTION 5308000133 A B C D E F Clamp, nylon, .625 ID 240387101 A B C D E F Tube-water, ice mold fill, extension...

  • Page 22: Wiring Schematic

    Publication No: 5995416335 FRS23R4C WIRING SCHEMATIC 09/04...

  • Page 23: Wiring Diagram

    FRS23R4C Publication No: 5995416335 WIRING DIAGRAM 09/04 # Functional Parts * Non-Illustrated Parts...
