E23CS75DSS0.eps N58FKGBGA0.eps N58RKGCHB0.eps N58BABAAD4.eps
N58SDDLEH12.eps N58TBBAAB5.eps N58CACBAA3.eps N58XEBAAA2.eps
N58YDAAAC4.eps N58I115TServo.eps W241638600.eps S241638600.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FGTC2349KS1
Series
counter depth
Color
stainless
Volts
115
Wiring Diagram
241638600
Owner's Guide
241857500
Market
North America
Energy Guide
241935573
Service Data Sheet 241639000
Publication No.
5995536389
09/03/25
(EN/SERVICE/DCS)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FGTC2349K
©
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FGTC2349K
Summary of Contents for Frigidaire FGTC2349K
- Page 1 Product No. FGTC2349KS1 Series counter depth Color stainless Volts Wiring Diagram 241638600 Owner's Guide 241857500 Market North America Energy Guide 241935573 Service Data Sheet 241639000 SIDE-BY-SIDE E23CS75DSS0.eps N58FKGBGA0.eps N58RKGCHB0.eps N58BABAAD4.eps REFRIGERATOR N58SDDLEH12.eps N58TBBAAB5.eps N58CACBAA3.eps N58XEBAAA2.eps N58YDAAAC4.eps N58I115TServo.eps W241638600.eps S241638600.eps P.O. BOX 212378 Model No.
-
Page 2: Freezer Door
Publication No: 5995536389 FGTC2349KS1 FREEZER DOOR N58FKGBGA0 03/09... - Page 3 FGTC2349KS1 Publication No: 5995536389 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241808225 Bin-door, pseudo, frzr 241545001 Bin-tilt out, tilt-out 241615189 Door-frzr, black, complete assy 240581906 Door Stop, black, frzr 241533607 Handle-frzr door, aluminum 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 241543202...
-
Page 4: Refrigerator Door
Publication No: 5995536389 FGTC2349KS1 REFRIGERATOR DOOR N58RKGCHB0 03/09... - Page 5 FGTC2349KS1 Publication No: 5995536389 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241516102 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 240581905 Door Stop, black, ref 241534515 Door-refr, black, complete assy 241533608 Handle-refr door, aluminum 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 241543202...
- Page 6 Publication No: 5995536389 FGTC2349KS1 CABINET N58BABAAD4 03/09...
- Page 7 FGTC2349KS1 Publication No: 5995536389 CABINET POS. NO PART NO. DESCRIPTION 241509804 Cover-air duct 241719711 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special 241603703...
- Page 8 Publication No: 5995536389 FGTC2349KS1 SHELVES N58SDDLEH12 03/09...
- Page 9 FGTC2349KS1 Publication No: 5995536389 SHELVES POS. NO PART NO. DESCRIPTION 241510608 Trim-basket 240443357 Shelf-freezer, glass, lower 240443358 Shelf-freezer, glass, upper 241552801 Light Bulb 241622802 Socket-light, frz light 241513101 Harness-wiring 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625 240350137 Shelf-"Spill-Safe", cantilver, sliding 240424615 Shelf-"Spill-Safe", "Aspect", complete 240599302...
- Page 10 Publication No: 5995536389 FGTC2349KS1 CONTROLS N58TBBAAB5 03/09...
- Page 11 FGTC2349KS1 Publication No: 5995536389 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509402 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor 241552801 Light Bulb 241622802 Socket-light, frz light 241516201...
- Page 12 Publication No: 5995536389 FGTC2349KS1 SYSTEM N58CACBAA3 03/09...
- Page 13 FGTC2349KS1 Publication No: 5995536389 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241516901 Cord-service 6* # 241510802 Harness-wiring, frz light 6* # 241519902 Harness-wiring 6* # 241527202 Harness-wiring, filter fan 6* # 241636203 Harness-wiring, machine compt 14 #...
-
Page 14: Ice And Water Dispenser
Publication No: 5995536389 FGTC2349KS1 ICE & WATER DISPENSER N58XEBAAA2 03/09... - Page 15 FGTC2349KS1 Publication No: 5995536389 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976418 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 241678905 Cover-module, silver metallic 240363402...
-
Page 16: Ice Container
Publication No: 5995536389 FGTC2349KS1 ICE CONTAINER 37A 34 34 33 N58YDAAAC4 03/09... - Page 17 FGTC2349KS1 Publication No: 5995536389 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241684701 Auger-ice 241685201 Cam-drive 241515202 Container-ice, bucket only 241685101 Drum-ice disp 241515302 Front-ice container 241726501 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501 Drive Blade 18 # 241676201 Motor-auger 241522901 Harness-wiring, icmkr/container...
-
Page 18: Ice Maker
Publication No: 5995536389 FGTC2349KS1 ICE MAKER INSTALLATION PARTS N58I115TServo 03/09... - Page 19 FGTC2349KS1 Publication No: 5995536389 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976418 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ice maker 5304458380...
-
Page 20: Wiring Schematic
Publication No: 5995536389 FGTC2349KS1 WIRING SCHEMATIC 03/09... -
Page 21: Wiring Diagram
FGTC2349KS1 Publication No: 5995536389 WIRING DIAGRAM DISPENSER ASSY WIRING GRN/YEL BLU/WHT LT. BLU RED/BLK ORG/WHT BARE NATURAL WHT/YEL BRN/YEL BLK/YEL RED/YEL YEL/PNK ORG/WHT YEL/GRY GRN/YEL LT. BLU DIODE SPLICE TAN/YEL SPLICE SPLICE DIODE DIODES MUST BE POLARIZED IN SAME DIRECTION SUPPLY LIGHTS 2416386...
