Frigidaire FRS23KF5D Factory Parts Catalog
Side-by-side
refrigerator
Hide thumbs
Also See for FRS23KF5D:
- Factory parts catalog (24 pages) ,
- Factory parts catalog (24 pages) ,
- Use & care manual (24 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Use and Care Manual
N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
n58sjckbc12.eps N58TAAAAB4.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YDAAAC0.eps N58I115T.eps W241526901A.eps S241526901A.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS23KF5DB7 FRS23KF5DQ7 FRS23KF5DW7
Series
R134a
Color
black
Volts
115
Wiring Diagram
241526901
Owner's Guide
241661500
Market
North America North America
Energy Guide
241585910
Service Data Sheet 240389621
Publication No.
5995446456
05/08/30
(EN/SERVICE/WC)
357
R134a
R134a
bisque
white
115
115
241526901
241526901
241661500
241661500
North America
241585910
241585910
240389621
240389621
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23KF5D
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS23KF5D
Summary of Contents for Frigidaire FRS23KF5D
- Page 1 Product No. FRS23KF5DB7 FRS23KF5DQ7 FRS23KF5DW7 Series R134a R134a R134a Color black bisque white Volts Wiring Diagram 241526901 241526901 241526901 Owner's Guide 241661500 241661500 241661500 Market North America North America North America Energy Guide 241585910 241585910 241585910 Service Data Sheet 240389621 240389621 240389621 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995446456 FRS23KF5D FREEZER DOOR N58FCCBBB2 08/05... - Page 3 FRS23KF5D Publication No: 5995446456 FREEZER DOOR Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 241569808 A - - Gasket-frzr door, black, magnetic 241569804 - B C Gasket-frzr door, white, magnetic 240367301 A B C Bin-door, frzr-upper 240359001 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995446456 FRS23KF5D REFRIGERATOR DOOR N58RCCBBB5 08/05... - Page 5 FRS23KF5D Publication No: 5995446456 REFRIGERATOR DOOR Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 241569807 A - - Gasket, refr door seal, black, magnetic 241569803 - B C Gasket-refr door, white, magnetic 240363701 A B C Bin-door, 2-liter...
- Page 6 Publication No: 5995446456 FRS23KF5D CABINET 08/05...
- Page 7 FRS23KF5D Publication No: 5995446456 CABINET Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 240435907 A B C Cover-air duct 240475906 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 14 # 240505801 A B C...
- Page 8 Publication No: 5995446456 FRS23KF5D SHELVES N58SJCKBC12 08/05...
- Page 9 FRS23KF5D Publication No: 5995446456 SHELVES Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 241657601 A B C Shelf, flip up, wire 241657501 A B C Shelf, fixed, freezer 241657503 A B C Shelf, fixed upper, freezer 240355211 A B C...
- Page 10 Publication No: 5995446456 FRS23KF5D CONTROLS 08/05...
- Page 11 FRS23KF5D Publication No: 5995446456 CONTROLS Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
- Page 12 Publication No: 5995446456 FRS23KF5D SYSTEM N58CAAAAA4 08/05...
- Page 13 FRS23KF5D Publication No: 5995446456 SYSTEM Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 240333602 A B C Condenser 218679606 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A B C Harness-wiring, machine compt...
-
Page 14: Ice And Water Dispenser
Publication No: 5995446456 FRS23KF5D ICE & WATER DISPENSER 08/05... - Page 15 FRS23KF5D Publication No: 5995446456 ICE & WATER DISPENSER Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995446456 FRS23KF5D ICE CONTAINER 37A 34 34 33 N58YDAAAC0 08/05... - Page 17 FRS23KF5D Publication No: 5995446456 ICE CONTAINER Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 241561301 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241561401...
-
Page 18: Ice Maker
Publication No: 5995446456 FRS23KF5D ICE MAKER INSTALLATION PARTS N58I115T 08/05... - Page 19 FRS23KF5D Publication No: 5995446456 ICE MAKER Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976907 A B C...
- Page 20 Publication No: 5995446456 FRS23KF5D ICE MAKER INSTALLATION PARTS N58I115T 08/05...
- Page 21 FRS23KF5D Publication No: 5995446456 ICE MAKER Model Index: A FRS23KF5D (FRS23KF5DB7) B FRS23KF5D (FRS23KF5DQ7) C FRS23KF5D (FRS23KF5DW7) POS. NO PART NO. DESCRIPTION 240542901 A B C Cap-water valve 5303001343 A B C Screw, hex washer head, 8-15A x 0.500 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line 5304436611...
-
Page 22: Wiring Schematic
Publication No: 5995446456 FRS23KF5D WIRING SCHEMATIC 08/05... -
Page 23: Wiring Diagram
FRS23KF5D Publication No: 5995446456 WIRING DIAGRAM 08/05 # Functional Parts * Non-Illustrated Parts...
