PRODUCT NO.
BASE MODEL NO.
FRS23KF5CB0
FRS23KF5C
FRS23KF5CQ0
FRS23KF5C
FRS23KF5CW0
FRS23KF5C
MARKET
North America
WIRING DIAGRAM - 240389610
OWNER'S GUIDE - 240581300
SERVICE DATA SHEET - 240389610
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995388526
030407
-EN/SERVICE /ECL
357
PARTS CATALO
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23KF5C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS23KF5C

Summary of Contents for Frigidaire FRS23KF5C

  • Page 1 PRODUCT NO. BASE MODEL NO. FRS23KF5CB0 FRS23KF5C FRS23KF5CQ0 FRS23KF5C FRS23KF5CW0 FRS23KF5C MARKET North America WIRING DIAGRAM - 240389610 OWNER’S GUIDE - 240581300 SERVICE DATA SHEET - 240389610 ELECTROLUX HOME PRODUCTS, INC P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a...

  • Page 2: Freezer Door

    Publication No. FRS23KF5C 5995388526 FREEZER DOOR 04/03...
  • Page 3 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C FREEZER DOOR PART NO DESCRIPTION 240390608 A - - Gasket-frzr door,black ,magnetic 240390604 - B C Gasket-frzr door,white...

  • Page 4: Refrigerator Door

    Publication No. FRS23KF5C 5995388526 REFRIGERATOR DOOR 04/03...
  • Page 5 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C REFRIGERATOR DOOR PART NO DESCRIPTION 240390607 A - - Gasket-refr door,black ,magnetic 240390603 - B C Gasket-refr door,white ,magnetic...
  • Page 6 Publication No. FRS23KF5C 5995388526 CABINET 04/03...
  • Page 7 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C CABINET PART NO DESCRIPTION 240435901 A B C Cover-air duct 240475901 A B C...
  • Page 8 Publication No. FRS23KF5C 5995388526 SHELVES 04/03...
  • Page 9 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C SHELVES PART NO DESCRIPTION 240434603 A B C Trim-basket 240338801 A B C Shelf-freezer,flip-up 240338701 A B C...
  • Page 10 Publication No. FRS23KF5C 5995388526 CONTROLS 04/03...
  • Page 11 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 13 # 16 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C CONTROLS PART NO DESCRIPTION 5308000010 A B C Fan Blade,red ,evaporator fan...
  • Page 12 Publication No. FRS23KF5C 5995388526 SYSTEM 04/03...
  • Page 13 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C SYSTEM PART NO...
  • Page 14 Publication No. FRS23KF5C 5995388526 DISPENSER 04/03...
  • Page 15 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 38A# 38A* 38C* # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C DISPENSER PART NO DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet,inlet valve ,to ice maker...

  • Page 16: Ice Container

    Publication No. FRS23KF5C 5995388526 ICE CONTAINER 04/03...
  • Page 17 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C ICE CONTAINER PART NO DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C...

  • Page 18: Ice Maker

    Publication No. FRS23KF5C 5995388526 ICE MAKER 04/03...
  • Page 19 A = FRS23KF5C (FRS23KF5CB0) B = FRS23KF5C (FRS23KF5CQ0) C = FRS23KF5C (FRS23KF5CW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRS23KF5C ICE MAKER PART NO DESCRIPTION...

  • Page 20: Wiring Schematic

    Publication No. FRS23KF5C 5995388526 WIRING SCHEMATIC 04/03...

  • Page 21: Wiring Diagram

    FRS23KF5C Publication No. 5995388526 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
