Page 1: Battery Charger
PN 50888:B0 ECN 01-155 Battery Charger CHG-120F Installation & Operating Manual Document 50888 03/21/2001 Rev:... -
Page 2: Fire Alarm System Limitations
While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of smoke Heat detectors do not sense particles of combustion and detectors, heat detectors, manual pull stations, audible warn- alarm only when heat on their sensors increases at a prede- ing devices, and a fire alarm control with remote notification termined rate or reaches a predetermined level. -
Page 3: Installation Precautions
Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be con- Like all solid state electronic devices, this system may nected to the fire alarm control panel. Disconnect all sources operate erratically or can be damaged when subjected to light- of power before servicing. - Page 4 This Page Intentionally Left Blank CHG-120F Instruction 03/21/01 PN 50888:B0...
-
Page 5: Table Of Contents
Table of Contents 1. Introduction to the Charger ................... 7 Overview........................7 Figure 1: Charger Features .................. 7 Specifications ......................8 Compliance with NFPA Codes and UL Standards ........... 8 Charger Maintenance ....................8 Table 1: Charger Specifications ................. 8 2. - Page 6 Installing Optional Meters ..................22 Installing an AM-1....................22 Table 6: Optional Meters ................... 22 Figure 16: Mounting an AM-1 or VM-1 to a BB-55F Battery Box ....22 Installing a VM-1 - ..................... 23 Installing an MPM-3................... 23 Figure 17: Mounting an MPM-3 ............... 23 3.
-
Page 7: Introduction To The Charger
1. Introduction to the Charger Overview The CHG-120F battery charger is designed to charge lead-acid batteries that provide emergency standby power for a Fire Alarm Control Panel (FACP). Two 12-volt batteries are always used in series to supply 24 VDC nominal. The following list gives answers to some common questions about the charger: •... -
Page 8: Specifications
Introduction to the Charger Specifications The charger also provides the following features: • AM-1 ammeter (0-10A) ordered separately • VM-1 voltmeter (0-50 V) ordered separately • Disable local ground fault detection • Selectable reporting delay for loss of AC (8 or 16 hours) Specifications Table 1 contains electrical specifications for the charger: Primary AC power in (TB1) -
Page 9: Installing The Charger
2. Installing the Charger Overview This section contains instructions and illustrations for installing the charger, divided into the following topics: Section Topic(s) Covered Page Installation Precautions and Precautions to take when installing the charger and Standards recommended installation standards. Charger Connections, Location and references to connections, jumpers, and Jumpers, and Switches switches used to configure, maintain, and operate the... -
Page 10: Installation Standards
Installing the Charger Charger Connections, Jumpers, and Switches Installation Standards An installer should be familiar with the following standards: • NEC Article 300 Wiring Methods. • NEC Article 760 Fire Protective Signaling Systems. • Applicable Local and State Building Codes. •... -
Page 11: Connecting Ac Power To The Charger
Installing the Charger Connecting AC Power to the Charger Connecting AC Power to the Charger Caution: Before connecting AC power to the charger—make sure to set the Voltage Select Switch (SW1) on the charger (Figure 2) to match your AC power source (120 VAC or 240 VAC). -
Page 12: Connecting Batteries To The Charger
Installing the Charger Connecting Batteries to the Charger Connecting Batteries to the Charger Overview - 25 AH –120 AH batteries can be connected to the charger. This section provides illustrations and instructions for connecting two batteries or for connecting four batteries. -
Page 13: Figure 6: Connecting Four Batteries To A Charger
Installing the Charger Connecting Batteries to the Charger Connecting Four Batteries - Figure 6 illustrates how to connect four 55 AH batteries to the charger: Warning: Do not connect the Battery Interconnect Cable at this time. Refer to “Starting the Charger”... -
Page 14: Mounting The Charger
Installing the Charger Mounting the Charger Mounting the Charger Mounting the Charger into a CAB-A3F or CAB-B3F A charger can be mounted into the bottom row of a CAB-A3F or CAB-B3F Cabinet, as long as the charger is within 20 feet of the load. -
Page 15: Mounting The Charger In A Bb-55F Battery Box
Installing the Charger Mounting the Charger Mounting the Charger in a BB-55F Battery Box A charger can be mounted in a BB-55F battery box, provided the BB-55F is within 20 feet of the load. Note that a charger takes up half the space in the BB-55F. This means there will be space remaining for only two 25 AH batteries in the BB-55F. -
Page 16: Connecting The Charger To A Load
Installing the Charger Connecting the Charger to a Load Connecting the Charger to a Load This section provides four applications for connecting a charger to a load. While connecting a charger to a load, observe the following precautions: • Make sure all power has been removed from the charger and the load. •... -
Page 17: Connecting The Charger To An Ms-9200
Installing the Charger Connecting the Charger to a Load Connecting the Charger to an MS-9200 - A charger can be connected to an MS-9200 (requires MS-9200 circuit board #71741, or later) by disabling the local charger by cutting jumper JP1 as illustrated in Figure 10. CHG-120F MS-9200 Cut JP1... -
Page 18: Connecting The Charger To An Ms-9600
Installing the Charger Connecting the Charger to a Load Connecting the Charger to an MS-9600 - A charger can be connected to an MS-9600 as illustrated in Figure 11. To A uxilia ry A C P o w e r In E q uipm en t Cut JP3 –... -
Page 19: Adding The Charger For Additional Current
Installing the Charger Connecting the Charger to a Load Adding the Charger for Additional Current Due to internal fuses, the maximum alarm current that can be drawn from the batteries and passed through the charger’s two output circuits is limited to 10 amps maximum (each circuit). The PS-12600 batteries, however, are capable of supplying up to 45 amps of current in alarm. -
Page 20: Configuring The Charger
Installing the Charger Configuring the Charger Configuring the Charger The charger can be configured to do the following: • Receive 120 VAC or 240 VAC input power (see Figure 3 on page 11). • Delay AC loss reporting (for Central Station applications); and •... -
Page 21: Trouble And Form-C Relay Connections (Optional)
Installing the Charger Trouble and Form-C Relay Connections (Optional) Trouble and Form-C Relay Connections (Optional) Table 5 contains descriptions of optional connectors on the charger: Function Connector Use open collector input and output to daisy JP5 Open Collector Trouble In chain a trouble signal through the charger JP4 Open Collector Trouble Out without affecting charger operation. -
Page 22: Installing Optional Meters
Installing the Charger Installing Optional Meters Installing Optional Meters You can also order and install a ammeter (AM-1), voltmeter (VM-1), or both (MPM-3) for use with the charger. If mounting an AM-1 or a VM-1, mount the meter to a BB-55F as shown in Figure 16. -
Page 23: Installing A Vm-1
Installing the Charger Installing Optional Meters Installing a VM-1 - A VM-1 can be connected across a charger output circuit. For example, to install a VM-1 to measure voltage from charger output circuit 1, follow these steps: Mount the VM-1 into a mounting slot on the front of the BB-55F battery box. Connect the positive lead to TB2 Out 1 (+). - Page 24 Installing the Charger Installing Optional Meters Notes CHG-120F Instruction 03/21/01 PN 50888:B0...
-
Page 25: Operating The Charger
3. Operating the Charger Overview This section contains information on starting the charger, interpreting the LED Status Indicators on the charger, and normal operation of the charger. Starting the Charger Warning: Before starting the charger, do the following: Follow the installation instructions in Section 2, “Installing the Charger.” Verify proper polarity on all connections between the charger and the batteries, load, and optional meters. -
Page 26: Normal Operation
Operating the Charger Normal Operation Table 7 shows the conditions that cause the charger LEDs to come on: AC On Trouble Ground Fault ✩ ✩ ✩ ✩ ✩ HI Charge ✩ ✩ ✩ ✩ LO Charge (Loss of AC) ✩ ✩... -
Page 27: Limited Warranty
Limited Warranty The manufacturer warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date-stamped at time of manufacture. The sole and exclusive obligation of the manufacturer is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service. - Page 28 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.firelite.com...
