Oracle 5.0 Reference Manual page 2616

Mysqlnd replication and load balancing plugin (mysqlnd_ms)
Feature stability
The cache integration is of beta quality.
Suitable MySQL clusters
The feature is targeted for use with MySQL Replication (primary copy).
Currently, no other kinds of MySQL clusters are supported. Users of such
cluster must control PECL/mysqlnd_qc manually if they are interested in client-
side query caching.
Support for MySQL replication clusters (asynchronous primary copy) is the main focus of PECL/
mysqlnd_ms. The slaves of a MySQL replication cluster may or may not reflect the latest updates from
the master. Slaves are asynchronous and can lag behind the master. A read from a slave is eventual
consistent from a cluster-wide perspective.
The same level of consistency is offered by a local cache using time-to-live (TTL) invalidation strategy.
Current data or stale data may be served. Eventually, data searched for in the cache is not available
and the source of the cache needs to be accessed.
Given that both a MySQL Replication slave (asynchronous secondary) and a local TTL-driven cache
deliver the same level of service it is possible to transparently replace a remote database access with a
local cache access to gain better possibility.
As of PECL/mysqlnd_ms 1.3.0-beta the plugin is capable of transparently controlling PECL/
mysqlnd_ms 1.1.0-alpha or newer to cache a read-only query if explicitly allowed by setting an
appropriate quality of service through mysqlnd_ms_set_qos. Please, see the
example. Both plugins must be installed, PECL/mysqlnd_ms must be compiled to support the cache
feature and PHP 5.4.0 or newer has to be used.
Applications have full control of cache usage and can request fresh data at any time, if need be. Thec
ache usage can be enabled and disabled time during the execution of a script. The cache will be used
if
mysqlnd_ms_set_qos
Cache usage is disabled by requesting higher consistency levels, for example, session consistency
(read your writes). Once the quality of service has been relaxed to eventual consistency the cache can
be used again.
If caching is enabled for a read-only statement, PECL/mysqlnd_ms may inject
caching by PECL/mysqlnd_qc. It may modify the SQL statement it got from the application.
Subsequent SQL processors are supposed to ignore the SQL hints. A SQL hint is a SQL comment.
Comments must not be ignored, for example, by the database server.
The TTL of a cache entry is computed on a per statement basis. Applications set an maximum age for
the data they want to retrieve using mysqlnd_ms_set_qos. The age sets an approximate upper limit
of how many seconds the data returned may lag behind the master.
The following logic is used to compute the actual TTL if caching is enabled. The logic takes the
estimated slave lag into account for choosing a TTL. If, for example, there are two slaves lagging 5 and
10 seconds behind and the maximum age allowed is 60 seconds, the TTL is set to 50 seconds. Please
note, the age setting is no more than an estimated guess.
• Check whether the statement is read-only. If not, don't cache.
• If caching is enabled, check the slave lag of all configured slaves. Establish slave connections if
none exist so far and lazy connections are used.
• Send
SHOW SLAVE STATUS
the second slave. Clients often wait long for replies, thus we send out all requests in a burst before
fetching in a second stage.
sets the quality of service to eventual consistency and enables cache usage.
to all slaves. Do not wait for the first slave to reply before sending to
2596
quickstart for a code
SQL hints to control
