- Page 1 Montage- und Gebrauchsanweisung , Installatie- en gebruiksaanwijzing Notice d’utilisation et d’installation, Operating and Installation Instructions EFT 630 - EFT 635 EFT 530 - EFT 535...
-
Page 2: Table Of Contents
Contents Safety warnings... 32 For the installer ... 32 For the user ... 32 Description of the Appliance ... 33 Extractor version ... 33 Recirculation Version ... 33 Control Panel ... 34 Correct ventilation ... 34 Maintenance and Care ... 35 Cleaning the hood ... -
Page 3: Safety Warnings
Safety warnings For the installer • When used as an extractor unit, the hood must be fitted with a 125mm diameter hose. Attention: The hose is not supplied and must be purchased separately. • When installing the hood, make sure you respect the following minimum distance from the top edge of the cooking hob/ring surfaces:... -
Page 4: Description Of The Appliance
• The hood is supplied as an extractor unit and can also be used with a filtering function by fitting one charcoal filter. • You will need an original Electrolux charcoal filter for this function (Available from your local Electrolux Service Force Centre). -
Page 5: Control Panel
Control Panel • Best results are obtained by using a low speed for normal conditions and a high speed when odours are more concentrated. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. -
Page 6: Maintenance And Care
Maintenance and Care • The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning the hood • Clean the outside of the hood using a damp cloth and a mild detergent. • Never use corrosive, abrasive or flammable cleaning products. -
Page 7: Paper Grease Filter
• The charcoal filter should only be used if you want to use the hood in the recirculation function. • To do this you will need an original Electrolux charcoal filter (available from your local Service Force Centre). • The charcoal filter cannot be washed nor regenerated. -
Page 8: Something Not Working
Something Not Working If your appliance fails to work properly please carry out the following checks. Symptom The cooker hood will not start. The cooker hood is not working The cooker hood has switched off during operation. If after all these checks, the problem persists, contact your local Service Force Centre, quoting the model and serial number. -
Page 9: Service And Spare Parts
* This information can be found on the rating plate, which can be seen when the grease filters are removed. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 10: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 11: Technical Specifications
Technical Specifications Model Dimensions (in cm): Height (cm) Width (cm) Depth (cm) Maximum absorbed power: 160W Motor absorption: Lighting: Length of the cable: Electrical connection: Subject to change without notice. Installation Unpacking Check that the cooker hood has no damages. Transportation damages should immediately be reported to the company responsible for the transportation. -
Page 12: Mounting Accessories Included
