N58L00001.eps N58FCFEFA2.eps N58RCFAAB0.eps N58BAAAAB2.eps
N58SKDJBD1.eps N58TCAAAB0.eps N58CAAAAA8.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241660401.eps S241660401.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6B6EEB5 FRS6B6EEB7 FRS6B6EEW7
Series
R134a
Color
black
Volts
115
Wiring Diagram
241660401
Owner's Guide
241660600
Market
North America North America North America
Energy Guide
241615413
Service Data Sheet 240389623
Publication No.
5995447686
05/09/09
(EN/SERVICE/WC)
357
R134a
R134a
black
white
115
115
241660401
241660401
241660600
241660600
241615413
241615413
240389623
240389623
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6B6EE
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS6B6EE
Summary of Contents for Frigidaire FRS6B6EE
- Page 1 Product No. FRS6B6EEB5 FRS6B6EEB7 FRS6B6EEW7 Series R134a R134a R134a Color black black white Volts Wiring Diagram 241660401 241660401 241660401 Owner's Guide 241660600 241660600 241660600 Market North America North America North America Energy Guide 241615413 241615413 241615413 Service Data Sheet 240389623 240389623 240389623 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995447686 FRS6B6EE FREEZER DOOR N58FCFEFA2 09/05... - Page 3 FRS6B6EE Publication No: 5995447686 FREEZER DOOR Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 241569806 A B - Gasket-frzr door, black, magnetic 241569802 - - C Gasket-frzr door, white, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995447686 FRS6B6EE REFRIGERATOR DOOR N58RCFAAB0 09/05... - Page 5 FRS6B6EE Publication No: 5995447686 REFRIGERATOR DOOR Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 241569805 A B - Gasket-refr door, black, magnetic 241569801 - - C Gasket-refr door, white, magnetic 240323002 A B C Bin-door, pseudo, bottom 240326203 A B C...
- Page 6 Publication No: 5995447686 FRS6B6EE CABINET N58BAAAAB2 09/05...
- Page 7 FRS6B6EE Publication No: 5995447686 CABINET Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 240435908 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 240505801 A B C Switch, light/lamp...
- Page 8 Publication No: 5995447686 FRS6B6EE SHELVES 140A N58SKDJBD1 09/05...
- Page 9 FRS6B6EE Publication No: 5995447686 SHELVES Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 241510604 A B C Trim-basket 240350668 A B C Shelf-freezer, glass, lower 240350667 A B C Shelf-freezer, glass, upper 240324101 A B C Shelf-pizza...
- Page 10 Publication No: 5995447686 FRS6B6EE CONTROLS N58TCAAAB0 09/05...
- Page 11 FRS6B6EE Publication No: 5995447686 CONTROLS Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
- Page 12 Publication No: 5995447686 FRS6B6EE SYSTEM 09/05...
- Page 13 FRS6B6EE Publication No: 5995447686 SYSTEM Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A B C Harness-wiring, machine compt...
-
Page 14: Ice And Water Dispenser
Publication No: 5995447686 FRS6B6EE ICE & WATER DISPENSER 09/05... - Page 15 FRS6B6EE Publication No: 5995447686 ICE & WATER DISPENSER Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995447686 FRS6B6EE ICE CONTAINER 37A 34 34 33 N58YDAAAC0 09/05... - Page 17 FRS6B6EE Publication No: 5995447686 ICE CONTAINER Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 241561301 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241561401...
-
Page 18: Ice Maker
Publication No: 5995447686 FRS6B6EE ICE MAKER INSTALLATION PARTS N58I115T 09/05... - Page 19 FRS6B6EE Publication No: 5995447686 ICE MAKER Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976907 A B C...
- Page 20 Publication No: 5995447686 FRS6B6EE ICE MAKER INSTALLATION PARTS N58I115T 09/05...
- Page 21 FRS6B6EE Publication No: 5995447686 ICE MAKER Model Index: A FRS6B6EE (FRS6B6EEB5) B FRS6B6EE (FRS6B6EEB7) C FRS6B6EE (FRS6B6EEW7) POS. NO PART NO. DESCRIPTION 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line...
-
Page 22: Wiring Schematic
Publication No: 5995447686 FRS6B6EE WIRING SCHEMATIC 09/05... -
Page 23: Wiring Diagram
FRS6B6EE Publication No: 5995447686 WIRING DIAGRAM 09/05 # Functional Parts * Non-Illustrated Parts...
