Frigidaire FRS26ZTH Factory Parts Catalog

Frigidaire FRS26ZTH Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26ZTH:
Table of Contents

Advertisement

Quick Links

See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRS26ZTHB5
FRS26ZTH
FRS26ZTHD5
FRS26ZTH
FRS26ZTHQ5
FRS26ZTH
FRS26ZTHW5
FRS26ZTH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909401
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
bisque
R134a
white
Publication No.
5995347936
001228
-EN/SERVICE /ECL
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZTH
©2001 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26ZTH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26ZTH

Summary of Contents for Frigidaire FRS26ZTH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZTHB5 FRS26ZTH R134a black FRS26ZTHD5 FRS26ZTH R134a almond FRS26ZTHQ5 FRS26ZTH R134a bisque FRS26ZTHW5 FRS26ZTH R134a white MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909401 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS26ZTH 5995347936 FREEZER DOOR 01/01...
  • Page 3 FRS26ZTH Publication No. 5995347936 FREEZER DOOR A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 215734323 A - - - Gasket-frzr door,black ,magnetic 215734313 - B C D Gasket-frzr door,white ,magnetic 5303288950 A B C D...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZTH 5995347936 REFRIGERATOR DOOR 01/01...
  • Page 5 FRS26ZTH Publication No. 5995347936 REFRIGERATOR DOOR A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 215734324 A - - - Gasket-refr door,black ,magnetic 215734314 - B C D Gasket-refr door,white ,magnetic 215403201 A B C D...
  • Page 6 Publication No. FRS26ZTH 5995347936 CABINET 01/01...
  • Page 7 FRS26ZTH Publication No. 5995347936 CABINET A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 215637602 A B C D Cover-air duct 5303209814 A B C D Nut,"U" type ,8-15A ,fan mtr mtg 215637402 A B C D Cover-evap coil,lower...
  • Page 8 Publication No. FRS26ZTH 5995347936 SHELVES 01/01...
  • Page 9 FRS26ZTH Publication No. 5995347936 SHELVES A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 5303298147 A B C D Trim-basket 218298003 A B C D Shelf-freezer,sliding ,wire 218159700 A B C D Spacer-shelf 5304405879...
  • Page 10 Publication No. FRS26ZTH 5995347936 CONTROLS 01/01...
  • Page 11 FRS26ZTH Publication No. 5995347936 CONTROLS A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 5303307883 A B C D Knob-damper control,white/teal line 5308000010 A B C D Fan Blade,red ,evaporator fan 5308000124 A B C D Ring-fan orifice...
  • Page 12 Publication No. FRS26ZTH 5995347936 SYSTEM 01/01...
  • Page 13 FRS26ZTH Publication No. 5995347936 SYSTEM A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 218787900 A B C D Condenser 5303208866 A B C D Spacer-cond tube,black 5303289026 A B C D Spacer-tube 5304406039...
  • Page 14 Publication No. FRS26ZTH 5995347936 DISPENSER 01/01...
  • Page 15 FRS26ZTH Publication No. 5995347936 DISPENSER A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 218976908 A B C D Tube-water inlet,filter ,to filter valve 5308010366 A B C D Tube-water inlet,0.25 OD x 93"...

  • Page 16: Ice Container

    Publication No. FRS26ZTH 5995347936 ICE CONTAINER 01/01...
  • Page 17 FRS26ZTH Publication No. 5995347936 ICE CONTAINER A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 5304404344 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice,bucket only 5304404346...

  • Page 18: Ice Maker

    Publication No. FRS26ZTH 5995347936 ICE MAKER 01/01...
  • Page 19 FRS26ZTH Publication No. 5995347936 ICE MAKER A = FRS26ZTH (FRS26ZTHB5) B = FRS26ZTH (FRS26ZTHD5) C = FRS26ZTH (FRS26ZTHQ5) D = FRS26ZTH (FRS26ZTHW5) POS. NO PART NO DESCRIPTION 218976908 A B C D Tube-water inlet,filter ,to filter valve 5308010366 A B C D Tube-water inlet,0.25 OD x 93"...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZTH 5995347936 WIRING SCHEMATIC 01/01...

  • Page 21: Wiring Diagram

    FRS26ZTH Publication No. 5995347936 WIRING DIAGRAM # = Fast-moving Parts 01/01 * = Non-Illustrated Parts...
