Frigidaire FRS26ZTH Factory Parts Catalog

Frigidaire FRS26ZTH Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26ZTH:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRS26ZTHB3
FRS26ZTH
FRS26ZTHD3
FRS26ZTH
FRS26ZTHW3
FRS26ZTH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a Gallery
black
R134a Gallery
almond
R134a Gallery
white
Publication No.
5995338034
000517
-EN/SERVICE/KHB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZTH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26ZTH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26ZTH

Summary of Contents for Frigidaire FRS26ZTH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZTHB3 FRS26ZTH R134a Gallery black FRS26ZTHD3 FRS26ZTH R134a Gallery almond FRS26ZTHW3 FRS26ZTH R134a Gallery white MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS26ZTH 5995338034 FREEZER DOOR 05/00...
  • Page 3 FRS26ZTH Publication No. 5995338034 FREEZER DOOR A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734313 - B C Gasket-frzr door,white ,magnetic 5303288950 A B C Support-door rack,RH/LH 5303323484 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZTH 5995338034 REFRIGERATOR DOOR 05/00...
  • Page 5 FRS26ZTH Publication No. 5995338034 REFRIGERATOR DOOR A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734314 - B C Gasket-refr door,white ,magnetic 215403201 A B C Panel-inner door,refr 5303304563 A B C...
  • Page 6 Publication No. FRS26ZTH 5995338034 CABINET 05/00...
  • Page 7 FRS26ZTH Publication No. 5995338034 CABINET A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 215637401 A B C Cover-evap coil,lower 5303208309 A B C Plug-hole,factory test 215230400 A B C Plug-harness hole...
  • Page 8 Publication No. FRS26ZTH 5995338034 SHELVES 05/00...
  • Page 9 FRS26ZTH Publication No. 5995338034 SHELVES A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire 5304405879 A B C Shelf-freezer,fixed wire 240324101 A B C Shelf-pizza 215029009...
  • Page 10 Publication No. FRS26ZTH 5995338034 CONTROLS 05/00...
  • Page 11 FRS26ZTH Publication No. 5995338034 CONTROLS A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS26ZTH 5995338034 SYSTEM 05/00...
  • Page 13 FRS26ZTH Publication No. 5995338034 SYSTEM A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 218787900 A B C Condenser 5303289026 A B C Spacer-tube 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg 5303289029 A B C Clip-cond mtg,(4)
  • Page 14 Publication No. FRS26ZTH 5995338034 DISPENSER 05/00...
  • Page 15 FRS26ZTH Publication No. 5995338034 DISPENSER A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet,0.25 OD x 93" ,plastic 218832301 A B C Tube-water inlet,inlet valve, to filter 218859901 A B C Tube-water inlet,inlet valve, to filter...

  • Page 16: Ice Container

    Publication No. FRS26ZTH 5995338034 ICE CONTAINER 05/00...
  • Page 17 FRS26ZTH Publication No. 5995338034 ICE CONTAINER A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS26ZTH 5995338034 ICE MAKER 05/00...
  • Page 19 FRS26ZTH Publication No. 5995338034 ICE MAKER A = FRS26ZTH (FRS26ZTHB3) B = FRS26ZTH (FRS26ZTHD3) C = FRS26ZTH (FRS26ZTHW3) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet,0.25 OD x 93", plastic 218832301 A B C Tube-water inlet,inlet valve, to filter 218859901 A B C Tube-water inlet,inlet valve, to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZTH 5995338034 WIRING SCHEMATIC 05/00...

  • Page 21: Wiring Diagram

    FRS26ZTH Publication No. 5995338034 WIRING DIAGRAM # = Fast-moving Parts 05/00 * = Non-Illustrated Parts...
