Frigidaire FRS26W2BS Factory Parts Catalog

Frigidaire FRS26W2BS Factory Parts Catalog

Side by side
Hide thumbs Also See for FRS26W2BS:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS26W2BSB3
FRS26W2BS
MARKET
North America
ENERGY GUIDE - 218791402
OWNER'S GUIDE - 240389310
SERVICE DATA SHEET - 240389608
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stain/blk
Publication No.
5995384657
030127
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26W2BS
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26W2BS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS26W2BS

Summary of Contents for Frigidaire FRS26W2BS

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26W2BSB3 FRS26W2BS R134a stain/blk MARKET North America ENERGY GUIDE - 218791402 OWNER’S GUIDE - 240389310 SERVICE DATA SHEET - 240389608 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC Model No. P.O.

  • Page 2: Freezer Door

    Publication No. FRS26W2BSB3 5995384657 FREEZER DOOR 01/03...
  • Page 3 FRS26W2BSB3 Publication No. 5995384657 FREEZER DOOR POS. NO PART NO DESCRIPTION 240390606 Gasket-frzr door,black ,magnetic 240334201 Bin-door,frzr-upper 240351601 Bin-door 240451896 Door-frzr,stainless steel, complete assy 240537106 Door Stop,black ,frzr 218762703 Handle-door,black 5308016566 Screw,hex washer head, 8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625 240561602 Bearing-hinge,closer...

  • Page 4: Refrigerator Door

    Publication No. FRS26W2BSB3 5995384657 REFRIGERATOR DOOR 01/03...
  • Page 5 FRS26W2BSB3 Publication No. 5995384657 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 240390605 Gasket-refr door, black, magnetic 240323001 Bin-door, pseudo, bottom 240326203 Door-dairy 240537105 Door Stop, black, ref 240451960 Door-refr, stainless steel, complete assy 218762703 Handle-door,black 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile 218781100 Screw,pan head ,8-18 x 0.625 240561601...
  • Page 6 Publication No. FRS26W2BSB3 5995384657 CABINET 01/03...
  • Page 7 FRS26W2BSB3 Publication No. 5995384657 CABINET POS. NO PART NO DESCRIPTION 240435902 Cover-air duct 240475902 Cover-evap coil,lower 5303208309 Plug-hole,factory test 14 # 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501 Bolt-roller adj,hex wshr hd,1/4-20 x 4.020, (2), special 240419103...
  • Page 8 Publication No. FRS26W2BSB3 5995384657 SHELVES 01/03...
  • Page 9 FRS26W2BSB3 Publication No. 5995384657 SHELVES POS. NO PART NO DESCRIPTION 240434604 Trim-basket 240338802 Shelf-freezer,flip-up 240338702 Shelf-freezer,fixed wire 240338704 Shelf-freezer,fixed wire 240373108 Frame-shelf,cantilever 240350702 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240350902 Cover-crisper pan,lower 240351007 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240351207 Pan-crisper,lower 240357706 Trim-shelf,front 240430706 Trim-shelf,11.21" ,front 240430702 Trim-shelf,12.39"...
  • Page 10 Publication No. FRS26W2BSB3 5995384657 CONTROLS 01/03...
  • Page 11 FRS26W2BSB3 Publication No. 5995384657 CONTROLS POS. NO PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 13 # 240315803 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 218906801 Socket-light/lamp 240383302...
  • Page 12 Publication No. FRS26W2BSB3 5995384657 SYSTEM 01/03...
  • Page 13 FRS26W2BSB3 Publication No. 5995384657 SYSTEM POS. NO PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240449601 Harness-wiring 14 # 5303918253 Defrost Heater Kit 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater,aluminum ,(2) 5303918214 Thermostat-defrost,kit 240330003...
  • Page 14 Publication No. FRS26W2BSB3 5995384657 DISPENSER 01/03...
  • Page 15 FRS26W2BSB3 Publication No. 5995384657 DISPENSER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 5304424550 Cover-module,black 5304424549 Module-dispenser 5304421626 Spring-torsion 240323917 Label-module cover,black 5304421619 Screw 240323603 Drip Tray,black 5304422026 Actuator-water,black 5304422025 Actuator-ice,black 5304421628 Door Assy-ice chute 5304421624 Door center 5304421625...

  • Page 16: Ice Container

    Publication No. FRS26W2BSB3 5995384657 ICE CONTAINER 01/03...
  • Page 17 FRS26W2BSB3 Publication No. 5995384657 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 240326904 Motor-auger 5304407107 Wiring Harness,auger motor...

  • Page 18: Ice Maker

    Publication No. FRS26W2BSB3 5995384657 ICE MAKER 01/03...
  • Page 19 FRS26W2BSB3 Publication No. 5995384657 ICE MAKER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 5304420650 Spring,shut-off arm 3206299 Label,ID plate 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 0.250 3206306 Motor-ice maker 3206312 Spacer-hold switch 3206313 3206315...

  • Page 20: Wiring Schematic

    Publication No. FRS26W2BSB3 5995384657 WIRING SCHEMATIC 01/03...

  • Page 21: Wiring Diagram

    FRS26W2BSB3 Publication No. 5995384657 WIRING DIAGRAM # = Fast-moving Parts 01/03 * = Non-Illustrated Parts...
