Frigidaire FRS26LF8C Parts Catalog
Frigidaire FRS26LF8C Parts Catalog

Frigidaire FRS26LF8C Parts Catalog

Side-by-side refrigerator
Hide thumbs Also See for FRS26LF8C:

Advertisement

Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FCCBBC2.eps N58RCCBBC5.eps N58BAAAAB1.eps
N58SLDGBE13.eps N58TAAAAB4.eps N58CAAAAC0.eps N58XEAAAA0.eps
N58YAAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRS26LF8CB2 FRS26LF8CQ2 FRS26LF8CS2 FRS26LF8CW2
R134a
R134a
R134a
black
bisque
stain/blk
115
115
115
241526901
241526901
241526901
240389311
240389311
240389311
North American North American North American North American
241538712
241538712
241538713
240389616
240389616
Publication No.
5995415063
04/08/16
(EN/SERVICE/DCS)
357
R134a
white
115
241526901
240389311
241538712
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26LF8C
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26LF8C and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FRS26LF8C

  • Page 1 Product No. FRS26LF8CB2 FRS26LF8CQ2 FRS26LF8CS2 FRS26LF8CW2 Series R134a R134a R134a R134a Color black bisque stain/blk white Volts Wiring Diagram 241526901 241526901 241526901 241526901 Owner's Guide 240389311 240389311 240389311 240389311 Market North American North American North American North American Energy Guide 241538712 241538712 241538713...
  • Page 2: Freezer Door

    Publication No: 5995415063 FRS26LF8C FREEZER DOOR 08/04...
  • Page 3 FRS26LF8C Publication No: 5995415063 FREEZER DOOR Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 240390606 A - C - Gasket-frzr door, black, magnetic 240390602 - B - D Gasket-frzr door, white, magnetic 240334202 A B C D Bin-door, frzr-upper...
  • Page 4: Refrigerator Door

    Publication No: 5995415063 FRS26LF8C REFRIGERATOR DOOR 08/04...
  • Page 5 FRS26LF8C Publication No: 5995415063 REFRIGERATOR DOOR Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 240390605 A - C - Gasket-refr door, black, magnetic 240390601 - B - D Gasket-refr door, white, magnetic 240323002 A B C D Bin-door, pseudo, bottom...
  • Page 6 Publication No: 5995415063 FRS26LF8C CABINET N58BAAAAB1 08/04...
  • Page 7 FRS26LF8C Publication No: 5995415063 CABINET Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 240435906 A B C D Cover-air duct 240475907 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 14 #...
  • Page 8 Publication No: 5995415063 FRS26LF8C SHELVES 140A N58SLDGBE13 08/04...
  • Page 9 FRS26LF8C Publication No: 5995415063 SHELVES Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 241510604 A B C D Trim-basket 240350668 A B C D Shelf-freezer, glass, lower 240350667 A B C D Shelf-freezer, glass, upper 240324101 A B C D...
  • Page 10 Publication No: 5995415063 FRS26LF8C SHELVES 140A N58SLDGBE13 08/04...
  • Page 11 FRS26LF8C Publication No: 5995415063 SHELVES Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 218867406 A B C D Channel, auger mtg, RH 240424502 A B C D Dispenser-can, clear 240430501 A B C D Channel, wtr tube cover...
  • Page 12 Publication No: 5995415063 FRS26LF8C CONTROLS 08/04...
  • Page 13 FRS26LF8C Publication No: 5995415063 CONTROLS Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 5300157666 A B C D Bushing-motor mtg, (2) 241563601 A B C D Bushing-motor mtg, (2)
  • Page 14 Publication No: 5995415063 FRS26LF8C SYSTEM 08/04...
  • Page 15 FRS26LF8C Publication No: 5995415063 SYSTEM Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 240346402...
  • Page 16: Ice And Water Dispenser

    Publication No: 5995415063 FRS26LF8C ICE & WATER DISPENSER 08/04...
  • Page 17 FRS26LF8C Publication No: 5995415063 ICE & WATER DISPENSER Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976903 A B C D Tube-water inlet, inlet valve, to filter...
  • Page 18: Ice Container

    Publication No: 5995415063 FRS26LF8C ICE CONTAINER 37A 34 34 33 N58YAAAAA1 08/04...
  • Page 19 FRS26LF8C Publication No: 5995415063 ICE CONTAINER Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 5304428402 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice, bucket only 5304404346 A B C D...
  • Page 20: Ice Maker

    Publication No: 5995415063 FRS26LF8C ICE MAKER 08/04...
  • Page 21 FRS26LF8C Publication No: 5995415063 ICE MAKER Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976903 A B C D Tube-water inlet, inlet valve, to filter...
  • Page 22 Publication No: 5995415063 FRS26LF8C ICE MAKER 08/04...
  • Page 23 FRS26LF8C Publication No: 5995415063 ICE MAKER Model Index: A FRS26LF8C (FRS26LF8CB2) B FRS26LF8C (FRS26LF8CQ2) C FRS26LF8C (FRS26LF8CS2) D FRS26LF8C (FRS26LF8CW2) POS. NO PART NO. DESCRIPTION 55 # 240531101 A B C D Valve-water, triple solenoid 218709100 A B C D Screw, hex head, 10-32 x 0.500 240363601 A B C D...
  • Page 24: Wiring Schematic

    Publication No: 5995415063 FRS26LF8C WIRING SCHEMATIC 08/04...
  • Page 25: Wiring Diagram

    FRS26LF8C Publication No: 5995415063 WIRING DIAGRAM 08/04 # Functional Parts * Non-Illustrated Parts...
