PRODUCT NO.
BASE MODEL NO.
FRS20WRHD1
FRS20WRH
FRS20WRHW1
FRS20WRH
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218915900
SERVICE DATA SHEET - # 218905000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
almond
R134a
white
Publication No.
5995324000
990601
-EN/SERVICE /ECL
357
SIDE BY SIDE
REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20WRH
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS20WRH
Summary of Contents for Frigidaire FRS20WRH
-
Page 1: Side By Side
FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS20WRHD1 FRS20WRH R134a almond FRS20WRHW1 FRS20WRH R134a white MARKET North America WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218915900 SERVICE DATA SHEET - # 218905000 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd. -
Page 2: Freezer Door
Publication No. FRS20WRH 5995324000 FREEZER DOOR 06/99... - Page 3 FRS20WRH Publication No. 5995324000 FREEZER DOOR A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 215734311 Gasket-frzr door,white ,magnetic 215734301 Gasket-frzr door,almond ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807003 Rack-door,w/end caps 215474048 Rack-door 218748601...
-
Page 4: Refrigerator Door
Publication No. FRS20WRH 5995324000 REFRIGERATOR DOOR 06/99... - Page 5 FRS20WRH Publication No. 5995324000 REFRIGERATOR DOOR A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 215734312 Gasket-refr door,white ,magnetic 215734302 Gasket-refr door,almond ,magnetic 218749301 Panel-inner door,refr 218807001 Rack-door,refr 5303288950 Support-door rack,RH/LH 5303304569 Door-dairy 5303289522 Door Stop 5303917893 Panel-refr door,white ,w/foam insulatn 5303917894...
- Page 6 Publication No. FRS20WRH 5995324000 CABINET 06/99...
- Page 7 FRS20WRH Publication No. 5995324000 CABINET A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 218748901 Cover-air duct 5308009617 Washer,ext tooth lock ,#10 ,grounding 218751301 Cover-evap coil,lower 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55" long 5303289044 Support-air duct cvr,1.83"...
- Page 8 Publication No. FRS20WRH 5995324000 SHELVES 06/99...
- Page 9 FRS20WRH Publication No. 5995324000 SHELVES A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 5303300707 Trim-basket 218298005 Shelf-freezer,sliding ,wire 5304405989 Shelf-freezer 215919136 Frame-refr shelf,cantilever ,(3) 215339900 Clip-shelf 218015301 Trim-storage pan cvr,snap-on ,front 218015401 Trim-storage pan cvr,snap-on ,rear 5303288971 Pan-storage,upper 5303288968...
- Page 10 Publication No. FRS20WRH 5995324000 CONTROLS 06/99...
- Page 11 FRS20WRH Publication No. 5995324000 CONTROLS A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 215809600 Diffuser-air 13 # 215426200 Motor-evap fan 215474201 Washer,"slinger"...
- Page 12 Publication No. FRS20WRH 5995324000 SYSTEM 06/99...
- Page 13 FRS20WRH Publication No. 5995324000 SYSTEM A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 218787700 Condenser 5303208866 Spacer-cond tube,black 5303289026 Spacer-tube 5303289029 Clip-cond mtg,(4) 218679603 Block-evap coil,styrofoam ,(2) 218541000 Drier-filter,R134a System 218646100 Harness-wiring,main 215005200 Harness-wiring,refr controls 218815101 Harness-wiring,frzr controls 218897101...
- Page 14 Publication No. FRS20WRH 5995324000 DISPENSER 06/99...
- Page 15 FRS20WRH Publication No. 5995324000 DISPENSER A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 215294101 Tube-water inlet,formed ,plastic ,dispenser 218505301 Deflector-ice disp,white 218505302 Deflector-ice disp,almond 215484300 Heater-door housing 218852401 Housing-dispenser,white 218852402 Housing-dispenser,almond 218284800 Switch-actuator,micro...
-
Page 16: Ice Container
Publication No. FRS20WRH 5995324000 ICE CONTAINER 06/99... - Page 17 FRS20WRH Publication No. 5995324000 ICE CONTAINER A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 16 # 5303289050 Socket-light/lamp 5304404345...
-
Page 18: Ice Maker
Publication No. FRS20WRH 5995324000 ICE MAKER 06/99... - Page 19 FRS20WRH Publication No. 5995324000 ICE MAKER A = FRS20WRH (FRS20WRHW1) B = FRS20WRH (FRS20WRHD1) POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 215294101 Tube-water inlet,formed ,plastic ,dispenser 3206348 Spring,shut-off arm 3206299 Plate-I.D. 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire,8-32 x 1/4 3206306 Motor-ice maker 3206312...
-
Page 20: Wiring Schematic
Publication No. FRS20WRH 5995324000 WIRING SCHEMATIC 06/99... -
Page 21: Wiring Diagram
FRS20WRH Publication No. 5995324000 WIRING DIAGRAM # = Fast-moving Parts 06/99 * = Non-Illustrated Parts...
