Factory Parts Catalog
PRODUCT NO.
FDB836GFB4
FDB836GFS4
MARKET
North America
SERVICE DATA SHEET # - 154320701
OWNER'S GUIDE # - 154314302
WIRING DIAGRAM # - 154320701
101 Masters Blvd.
Anderson, SC 29624
This Publication Supercedes
Publication Number 5995306981
BASE MODEL NO.
COLOR
FDB836GF
black
FDB836GF
white
Publication No.
5995327383
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
990902
©1999 White Consolidated Industries, Inc.
821
All rights reserved
DISHWASHER
18" PORTABLE
DISHWASHER
Model No.
FDB836GF
Advertisement
Related Manuals for Frigidaire FDB836GF
Summary of Contents for Frigidaire FDB836GF
- Page 1 FACTORY PARTS CATALOG DISHWASHER PRODUCT NO. BASE MODEL NO. COLOR FDB836GFB4 FDB836GF black FDB836GFS4 FDB836GF white MARKET North America SERVICE DATA SHEET # - 154320701 OWNER’S GUIDE # - 154314302 WIRING DIAGRAM # - 154320701 18" PORTABLE DISHWASHER Model No. 101 Masters Blvd.
-
Page 2: Control Panel
Publication No. FDB836GF 5995327383 CONTROL PANEL 9/99... - Page 3 FDB836GF Publication No. 5995327383 CONTROL PANEL A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154253103 Panel-control,black 154253101 Panel-control,white 154236903 Insert-control pnl,black 154236901 Insert-control pnl,white 154227703 Control 154200401 Screw,6-10 x 3/8 ,pan plask 154287901 Cover-control 154301301 Cover-pc protector 154228301 Duct-dynamic...
- Page 4 Publication No. FDB836GF 5995327383 DOOR 9/99...
- Page 5 FDB836GF Publication No. 5995327383 DOOR A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154226002 Spring-door,(2) 154093301 Screw-arm assy,(4) 154225902 Arm Assy,LH 154225901 Arm Assy,RH 154211501 Pin-arm 154298101 Washer,arm 154079601 Nut-arm assy,(4) 154299002 Door-inner assy 154226601 Liner grate 154230101 Dispenser-det/rinse aid...
- Page 6 Publication No. FDB836GF 5995327383 9/99...
- Page 7 FDB836GF Publication No. 5995327383 A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154211601 Strike-door 154211801 Gasket-tub 154200602 Screw,10-16 x 3/8 ,hex 154080001 Roller-tub 5303943103 Screw w/washer,(8) 154239801 Tubing-water inlet 5303318539 Clamp-tubing,(2) 24 # 154225602 Hose-drain...
-
Page 8: Motor & Pump
Publication No. FDB836GF 5995327383 MOTOR & PUMP 9/99... - Page 9 FDB836GF Publication No. 5995327383 MOTOR & PUMP A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154247601 Heater 154106201 Nut-heater,(2) 154289801 Shield-heater terminal 154211001 Bracket-heater 154245901 Macerator 154245501 Cover-volute 5303316032 Screw,truss ss ,8 .625 154245801 Impeller 154282701 Screw,ss impeller 154246801...
- Page 10 Publication No. FDB836GF 5995327383 FRAME 9/99...
- Page 11 FDB836GF Publication No. 5995327383 FRAME A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154219601 Valve-water 154208701 Brace-front 154322903 Toeplate-adjustable 154323003 Kickplate/Baffle Assy,black 154249301 Insulation,kickplate 5300808658 Screw,#8A x .375" 154294701 Screw,#7 plas .375 ,(6) ,disp. assy. 154210901 Screw-leveling 154209601...
- Page 12 Publication No. FDB836GF 5995327383 RACKS 9/99...
- Page 13 FDB836GF Publication No. 5995327383 RACKS A = FDB836GF (FDB836GFB4) B = FDB836GF (FDB836GFS4) POS. NO PART NO DESCRIPTION 154320904 Rack assy-lower 154295201 Basket-Silverware 154321104 Rack assy-upper 5300809974 Wheel & bracket assy,upper rack 5300809927 Cap-slide,(4) 154232701 Slide-rack,(2) 154174501 Wheel & bracket assy,lower rack 154304001 Base-funnel 154251801...
