PRODUCT NO.
FDB345LFR2
FDB345LFS2
MARKET
North America
SERVICE DATA SHEET # - 154400501
OWNER'S GUIDE # - 154395301
INSTALLATION INSTRUCTIONS # - 154329601
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDB345LF
Built-in 24"
FDB345LF
Built-in 24"
Publication No.
5995352597
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
black
white
010418
©2001 White Consolidated Industries, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
FDB345LF
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FDB345LF
Summary of Contents for Frigidaire FDB345LF
- Page 1 FACTORY PARTS CATALOG DISHWASHER PRODUCT NO. BASE MODEL NO. SERIES COLOR FDB345LFR2 FDB345LF Built-in 24" black FDB345LFS2 FDB345LF Built-in 24" white MARKET North America SERVICE DATA SHEET # - 154400501 OWNER’S GUIDE # - 154395301 INSTALLATION INSTRUCTIONS # - 154329601 24"...
-
Page 2: Control Panel
Publication No. FDB345LF 5995352597 CONTROL PANEL 04/01... - Page 3 FDB345LF Publication No. 5995352597 CONTROL PANEL A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154368301 Panel-control,white 154368303 Panel-control,black 154333801 Insert-control pnl,white 154333803 Insert-control pnl,black 154295701 Timer 154131203 Shield-timer 154095701 Screw-timer,thread rolling ,(2) 154334101 Switch 154242201 Shield-switch 5303318719 Screw,mtg.
- Page 4 Publication No. FDB345LF 5995352597 DOOR 04/01...
- Page 5 FDB345LF Publication No. 5995352597 DOOR A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154345902 Spring-door,(2) 154325201 Spring linkage,(2) 154093301 Screw-arm assy,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH 154211501 Pin-arm 154079601 Nut-arm assy,(4) 154299002 Door-inner assy 154226601 Liner grate 154230101...
- Page 6 Publication No. FDB345LF 5995352597 04/01...
- Page 7 FDB345LF Publication No. 5995352597 A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154211601 Strike-door 154211801 Gasket-tub 154200602 Screw,10-16 x 3/8 ,hex 154333901 Roller-tub 5303943103 Screw w/washer,(8) 154239801 Tubing-water inlet 5303318539 Clamp-tubing,(2) 24 # 154225602 Hose-drain...
-
Page 8: Motor & Pump
Publication No. FDB345LF 5995352597 MOTOR & PUMP 04/01... - Page 9 FDB345LF Publication No. 5995352597 MOTOR & PUMP A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154247601 Heater 154106201 Nut-heater,(2) 154289801 Shield-heater terminal 154359701 Bracket-heater,(2) 154245501 Cover-volute 154246801 Gasket-sump 154365902 Housing-sump 154246502 Retainer,sump 154250801 Spray arm-lower 154313601 Spray arm-center 24A*...
- Page 10 Publication No. FDB345LF 5995352597 FRAME 04/01...
- Page 11 FDB345LF Publication No. 5995352597 FRAME A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154359801 Valve-water 154208701 Brace-front 154322903 Toeplate-adjustable,black 154397203 Kickplate Assy,black ,w/ foam 5300808658 Screw,#8A x .375" ,black 154320101 Screw,serr ,#8-18 x 3/8 154200601 Screw-#10-16 x 3/8 154210901 Screw-leveling...
- Page 12 Publication No. FDB345LF 5995352597 RACKS 04/01...
- Page 13 FDB345LF Publication No. 5995352597 RACKS A = FDB345LF (FDB345LFS2) B = FDB345LF (FDB345LFR2) POS. NO PART NO DESCRIPTION 154320904 Rack assy-lower 154210401 Basket-Silverware,white 154321107 Rack assy-upper 5304407064 Wheel & bushing assy,upper rack 5300809927 Cap-slide,(4) 154232701 Slide-rack,(2) 154174501 Wheel & bracket assy,lower rack 154304001 Base-funnel 154251801...
