Frigidaire FGC36S5A Factory Parts Catalog

Gas cooktop

Download this manual

PRODUCT NO.

BASE MODEL NO.

FGC36S5ABB

FGC36S5A

FGC36S5AWB

FGC36S5A

WIRING DIAGRAM - # 318047105

OWNER'S GUIDE - # 318200657

INSTALLATION INSTRUCTIONS - # 318201450

ELECTROLUX HOME PRODUCTS, INC.

P.O. BOX 212378, Augusta, GA 30917

FACTORY PARTS CATALOG

FACTORY NO.

COLOR

3775441351062

black

3775441351012

black/white

Publication No.

5995366472

020220

-EN/SERVICE /ECL

377

RANGE

MARKET

North America

GAS

COOKTOP

Model No.

FGC36S5A

Page 1 FACTORY PARTS CATALOG RANGE PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET FGC36S5ABB FGC36S5A 3775441351062 black North America FGC36S5AWB FGC36S5A 3775441351012 black/white North America WIRING DIAGRAM - # 318047105 OWNER’S GUIDE - # 318200657 INSTALLATION INSTRUCTIONS - # 318201450 COOKTOP Model No.
Page 2 Publication No. FGC36S5A 5995366472 COOK TOP 02/02...
Page 3 FGC36S5A Publication No. 5995366472 COOK TOP A = FGC36S5A (FGC36S5AWB) B = FGC36S5A (FGC36S5ABB) POS. NO PART NO DESCRIPTION 318065901 Main Top,white 318065903 Main Top,black 318168014 Pan,burner ,medium ,black 318168024 Pan,burner ,large ,black 318168004 Pan,burner ,small ,black 318120005 Grate,black 318076410 Cap,burner ,black ,medium LF &...
Page 4 Publication No. FGC36S5A 5995366472 BURNER 02/02...
Page 5 FGC36S5A Publication No. 5995366472 BURNER A = FGC36S5A (FGC36S5AWB) B = FGC36S5A (FGC36S5ABB) POS. NO PART NO DESCRIPTION 318177100 Manifold Pipe 5303935042 Valve,top burner ,2-position ,9100 BTU 2A # 318087001 Valve,top burner ,5000 BTU 2B # 318087040 Valve,top burner ,13000 BTU 316032002 Switch,ignitor 318167711...
Page 6: Wiring Diagram
Publication No. FGC36S5A 5995366472 WIRING DIAGRAM 02/02...
