<Note>
To saving/loading song data using a CD-RW
drive, the optional Model 8340 SCSI card must
be installed to the VF08.
See page 115 of the main manual for details
about how to install the option.
For the detailed information about the Model
8340 SCSI card, contact your local Fostex dis-
tributor.
VF08 Owner's Manual
<V2.0 Supplement>
The VF08 software has been upgraded to
v2.0, which supports the new "internal mas-
tering function", as well as expands the func-
tion of save/load using a "SCSI" CD-RW drive.
You can now record mastered materials onto
a CD-RW/CD-R disc with the standard au-
dio CD format.
This supplement only handles instructions
for the internal mastering function and
save/load using a CD-RW/CD-R disc.
See "Save/Load of song data" on the main
manual about details for save/load using
SCSI and S/P DIF digital signal.
8588 004 200
(352069)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VF08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fostex VF08

Summary of Contents for Fostex VF08

  • Page 1 Model 8340 SCSI card must be installed to the VF08. See page 115 of the main manual for details about how to install the option. For the detailed information about the Model 8340 SCSI card, contact your local Fostex dis- tributor.

  • Page 3: Table Of Contents

    Table of Contents Internal Mastering Function.......................3 Please read this first before carrying out operations in the internal mastering mode!....4 Rehearsing internal mastering........................5 Performing internal mastering.......................6 About Start and End points......................7 Save/Load using CD-RW/CD-R......................8 Please read this first!..........................8 Caution on CD-RW drive........................8 Care and handling of CD-RW/CD-R discs...................8 About writing and reading speeds....................8 Save/load of song data using a CD-RW drive................9...

  • Page 4: Internal Mastering Function

    Internal Mastering Function The "mastering mode" of the VF08 mixes tracks 1 through 6 down to tracks 7/8, and plays back them with the dedicated mastering effects so that you can record them to an external (analog or digital) master recorder (see figure 1). The “internal mastering function”, a newly added function for the VF08, expands the mastering mode, which allows transferring a mix-down material on tracks 7/8 to another (new) program on the current drive with adding the mastering effects.

  • Page 5: Rehearsing Internal Mastering

    Rehearsing internal mastering Before performing the internal mastering, you can rehearse it as many times as you like, while adjust- ing the track 7/8 level and sound effects. In the following description, we assumes that a bounced material is recorded on tracks 7/8 of the playback program.

  • Page 6: Performing Internal Mastering

    7. Press the [REWIND] key while holding down the <Hint> [STOP] key to locate the beginning of the program. On the mastering screen, you can tailor the The VF08 locates the beginning of the program sound by adjusting EQ settings (HI, MID and immediately and "00m 00s"...

  • Page 7: About Start And End Points

    <About Start and End points> As described earlier, the starting and ending times of internal mastering are automatically regis- tered as "Start point" and "End point" respectively, which can be used for track editing (copy, move and erase) for the newly created program (see the illustrations below). This function is very convenient for making an audio CD from mastered materials, because data between "Start point"...

  • Page 8: Save/Load Using Cd-Rw/Cd-R

    A CD-RW drive to be used for saving/loading VF08 song data or making audio CD from VF08 data must be compatible with the VF08. If you use a drive that is not operation-confirmed by Fostex, you may have a problem. You can check operation-confirmed CD-RW drive by the following ways.

  • Page 9: Save/Load Of Song Data Using A Cd-Rw Drive

    <Note> You can save or load data using a CD-RW drive only with the FDMS-3 (Fostex Digital Management System- 3) format and CD-DA format. Note that, unlike other SCSI devices, you cannot save or load data with the WAV file format.

  • Page 10: Saving Data Using A Cd-Rw Drive (Backup)

    Saving data using a CD-RW drive (Backup) In the following procedure, we assume that a CD-RW 5. While “BkUp” flashing, press the [ENTER/YES] key. drive is connected to the SCSI port of the Model 8340 The display shows the screen for selecting a program to be saved (the program number of the selected program installed in the VF08 and a non-recorded CD-RW/CD- flashes).
  • Page 11 <Hint 1> In the description for saving data above, we as- sume to use a non-recorded CD-RW/CD-R disc. If you use a recorded disc (including a disc on which computer data is recorded), also note the following. By performing step 5 in the save operation proce- When saving data to more than one disc, the first disc dure shown above (“While “BkUp”...

  • Page 12: Loading Backup Data From A Cd-Rw Drive

    <Hint 2> • To eject the disc If you try to save data to a recorded CD-R disc, the Use the [JOG] dial to highlight “Eject” (flashing) and display shows a warning message saying “Not Writ- press the [ENTER/YES] key. able”, followed by a message saying “Insert Disk”...
  • Page 13 flashing By rotating the [JOG] dial, you can select a desired pro- <Display example for loading> gram number/title from among available programs in the VF08 current drive. You can also select “Eject”. <Note> If you select “Eject” and press the [ENTER/YES] key, the disc is ejected.

  • Page 14: Making An Audio Cd

    Making an audio CD The following procedure describes how to record mastered songs (using the internal mastering function) to a CD- RW/CD-R disc to make an audio CD (CD-DA format). The “Save PGM” menu in the Setup mode, which is used for saving song data, is also used for making an audio CD. <Basic information>...
  • Page 15 9. Use the [JOG] dial to select a desired program and press Copy protection setting the [ENTER/YES] key. You can restrict the disc copy (duplication) ca- The selected program is set to the first track. pability of an audio CD you are going to make. “ON”...
  • Page 16 <Notes for selecting more than one program> <Hint> When recording more than one program to a CD-RW/ When a CD-RW disc on which any data is recorded CD-R disc, do not skip any track when assigning pro- is set, if you perform step 7 above (i.e. pressing the grams to tracks.

  • Page 17: Loading From An Audio Cd

    Loading from an audio CD You can load a desired song to the VF08 from an audio CD you created by recording on a CD-RW/CD-R disc. When a desired song is loaded, the VF08 automatically creates a new program on the current drive, and the song are recorded on tracks 1 and 2 of the program.
  • Page 18 <Hint> When loading data using the S/P DIF digital signal, the same message also appears after selecting the load device to “SP DIF” and pressing the [ENTER/YES] key. <Note> To load more than one track, repeat steps 7 through 8 If you do not agree with the warning message con- above.
  • Page 19 Memo...
  • Page 20 FOSTEX CORPORATION 3-2-35 Musashino, Akishima-shi, Tokyo, Japan 196-0021 FOSTEX AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U. S. A. © PRINTED IN JAPAN APR. 2001 8588 004 200 FX 352069...
