Page 1: Table Of Contents
ZMU17MXL English Contents Before using your microwave oven Safety instructions – Utensil safety – Testing suitability of cookware – Food safety – Oven utensils and accessories guide Technical data Getting Started – Unpacking Installation – Connecting to the mains – Electrical connections How to operate your microwave oven –... -
Page 2: Before Using Your Microwave Oven
English Thank you for having chosen a Zanussi product. We are convinced that you will find your new microwave oven very useful and that it will be of great help to you. As with all new kitchen appliances, it will take some time to learn all the new functions and features, but with time, this oven will become indispensable to you. -
Page 3: Testing Suitability Of Cookware
ZMU17MXL English Testing suitability of cookware Food safety Do not heat food in a can in the microwave oven. Place the cookware in the cavity along with a Always remove the food to a suitable container. glass half full of water. Heat on 600 W (100%) for one minute. -
Page 4: Oven Utensils And Accessories Guide
ZMU17MXL English Oven utensils and accessories guide A variety of Utensils and Materials may be used for cooking in your microwave oven. For your safety and to prevent damaging utensils and your oven choose, appropriate utensils and materials for each cooking method. The list below is a general guide. -
Page 5: Getting Started
ZMU17MXL English GETTING STARTED Unpacking Connecting to the mains N.B. When you unpack the oven, check that the The oven is delivered with the power cord and a plug product is free from damage. Damage or any missing for 230V, 50Hz, earthed socket outlet. Earth parts must be reported immediately to the retailer. -
Page 6: How To Operate Your Microwave Oven
ZMU17MXL English How to operate your microwave oven Name and function of parts Turntable Installation 1. Cooking compartment. Wipe the compartment 1. Place the turntable support on the cavity Bottom. clean after using the oven. 2. Place the turntable on top of the turntable support 2. -
Page 7: Control Panel
ZMU17MXL English CONTROL PANEL 1. Timer Set for desired cooking time. Cooking will start. All clockwork timers will operate more accurately if wound past the desired time first, and then back. 2. Power Selector Adjust this knob to select the correct power level for your food. -
Page 8: Microwave Cooking
ZMU17MXL English MICROWAVE COOKING 1. Open the door, place the food on the turntable. When cooking for less than 2 minutes, turn the timer Close the door. for a longer period and than return to the desired 2. Set the Power Selector to the desired power time. -
Page 9: Defrosting Instructions Using 200W
ZMU17MXL English Recommendations for Defrosting (using 200W Some foods such as bread and fruit, can successfully be thawed manually by using the power setting. STANDING FOOD PREPARATION (200W) TIME Bread Place on microwave-proof rack or kitchen paper. Small loaf 8–10 min. 10–15 min. -
Page 10: Microwave Hints
ZMU17MXL English Microwave Hints Microwave Tips Always keep the oven clean – avoid spill-overs Softening Honey and do not forget to clean under the glass tray If you have a jar of honey which has and the inside of the door. crystallised, remove lid and place the jar in the oven, microwave on medium power for 2 Preferably use round or oval casseroles with a lid... -
Page 11: Care And Cleaning
ZMU17MXL English Care and cleaning The oven must always be clean. Residue of food from spillovers or spatters will attract microwave energy causing it to burn on. This could reduce the efficiency of the oven and may cause bad odours. Do not attempt to tamper with or make any adjustments or repairs to any part of the oven. -
Page 12: Service And Spare Parts
Check that the Start button is activated. If the oven still does not work properly after the above checks, contact the local Zanussi After-Sales Service Centre. The address can be found on the following pages of this user guide. -
Page 13: Guarantee Conditions
3. Should guarantee repairs be necessary the purchaser must inform the nearest customer service office (ZANUSSI’s service or authorised agent). ZANUSSI reserves the right to stipulate the place of repair (i.e. the customer’s home, place of installation or ZANUSSI workshop). -
Page 14: Building In Instructions
ZMU17MXL English Building In Instructions Main requirements for the cabinet under which the microwave is to be attached: Thickness of the floor of the cabinet > 16mm. Recommended width of cabinet: 500 - 600 mm Depth of cabinet: min. 350 mm When the cabinet is fully loaded (crockery plus microwave), the floor of the cabinet must not sag by more than 5 mm / m. - Page 15 ZMU17MXL English Building In Instructions The earthed socket must be easily accessible. Ideally it should be located underneath the cabinet to which the microwave is to be attached. The mains cable must not touch the back of the appliance. If the socket is not accessible, a device must be fitted when the appliance is installed allowing all pins of the plug to be disconnected from the mains with a contact gap of at least 3 mm.
- Page 16 ZMU17MXL English Building In Instructions 1. Remove the contents of the cabinet and adjacent cabinets. 2. Mount the cabinet on the wall, check that it is solid and measure it. Check the location of mains sockets. 3. The holes may be bored from inside the cabinet or from the underside of the cabinet.
- Page 17 ZMU17MXL English Building In Instructions Drilling on the underside of the cabinet Using the drilling template, choose the position of the microwave on the underside of the cabinet. (Position the front edge of the microwave door so that it is aligned with the front of the cabinet.) Secure the drilling template with the help of adhesive tape.
