Fostex CR500 Supplement Owner's Manual

CR500 Owner's Manual (V1.10 Supplement)
With the software upgrade of the CR500, the track increment function has been newly added.
This function is useful when recording to a CD-DA disc (the track increment function does not
work when recording a BWF file).
The track increment function automatically creates a new audio track during CD-DA recording by
pressing the [RECORD] key while the [SHIFT] mode is active. Therefore, using this function, you
can create a track for each song during live recording.
When a track is incremented by the track increment function, an approximately 100 ms gap (silent
space) is inserted between tracks. That is, when you burn an audio CD using this function and play
it back using any CD player other than the CR500, it is played back with a silent space between
tracks (though it is played back with no silent space between tracks when you use the CR500).
Therefore, it is recommended not to execute this function in the middle of a song. Execute this
function at a point between songs, etc.
<Note>: Pressing the [RECORD] key while the SHIFT mode is active during recording turns
off the shift mode. To divide the track again, do not forget to press the [SHIFT] key to turn on
the shift mode before pressing the [RECORD] key.
<Recording without using the track increment function>
When you stop recording, an audio track is created on a disc. The following shows the screen example when
you disable the record ready mode after you stop recording.
Rec Start
By using the track increment function, you can create more than one audio track in a single recording
process. If you execute the track increment function three times during live recording as in the figure below,
four audio tracks are created. The following shows the screen example when you disable the record ready
mode after you stop recording.
Rec Start
Track 01
<Important!>
MEMORY
MEMORY SET
DISPLAY
1 2
space ABC
CONTRAST
FILE SEL
4 5
GHI JKL
DIR SEL
REC RDY
7 8
PQRS TUV
REC END
ABS 0
RECORD
STOP/HOME
[RECORD] key
Track 01
<Recording using the track increment function>
Track 02 Track 03 Track 04
CR500 Owner's Manual (V1.10 Supplement)
[SHIFT] key
LOCATE SHIFT EXIT/NO
3
DEF PUSH
EDIT TIME
MENU/ENTER/YES
CLEAR
6 +10
MNO
SKIP/CURSOR
9 0
WXYZ symbol
PLAY REWIND F FWD
Rec End
Rec End
© PRINTED IN CHINA JANUARY 2007 8588097000 (457649)
