Refrigeration smart 2 door dual temp refrigerator (50 ft3)

Advertisement

Quick Links

SMART 2 Door Dual Temp
Refrigerator (50 FT
Refrigeration
SMART 2 Door Dual Temp
Refrigerator (50 FT
726484 (RH14DD2FU) 50 ft
3
2 door 115 V/1p/60Hz

Short Form Specification

Item No. ___________________________________
The Electrolux HD-Line offers one of the most comprehensive
choices of refrigerated storage cabinets available. Manufac-
tured internally and externally in 304 AISI stainless steel,
operating over refrigeration or freezer temperature ranges,
with solid doors, and in a choice of either 23 ft
capacity.
Covered by Electrolux Platinum Star
year parts and one-year labor warranty, installation start-up
and performance check-up after one year from installation.
Approval: ___________________________________________
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
Refrigeration
3
)
3
)
Full Size Dual Temp Refrigerator
3
3
or 50 ft
®
Service Program two-
5-15P
Electrolux Professional, Inc.
www.electroluxusa.com/professional
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________

Main features

EASY TO INSTALL

• Mounted on adjustable stainless steel feet, with castors as an option.
• Choice of doors to suit varying kitchen requirements.
• Refrigeration operating temperatures that can be adjusted from 28 °F to 50
°F (-2.22 to 10 °C).
• Suitable for ambient temperatures up to 110 °F (43 °C).

EASY TO CLEAN

• Constructed from the highest quality AISI 304 stainless steel with radiused
corners to the interior base which is pressed from a single sheet.
• Sides and back are formed from just 2 sheets of stainless steel with a single
joint to avoid dirt traps.
• Evaporator unit is inset into the top of the refrigerated chamber to provide
an obstruction free interior.

EASY TO USE

• Forced air circulation for rapid cool down and even temperature uniformity.
• Accommodates GN 2/1 containers or shelves on anti-tilt runners.
• External digital temperature display.
• Interior light and lockable door.
• Refrigerators feature automatic defrost and are fitted with a defrost outlet
pipe.

EASY TO MAINTAIN

• Heavy-duty construction that avoids use of any plastic parts.
• Single refrigeration unit (compressor, condenser and evaporator) that can
be removed in a single piece from either the top or back.
• Evaporator cover is easily removable for maintenance.

EASY ON THE ENVIRONMENT

• 20% reduction in energy consumption compared to previous models.
• Cabinet fitted with up to 3" (75 mm) thickness of cyclopentane insulation
for best insulating performance with 100% environmental.
• Refrigerant type: R134a.
• All models comply with the standards required by the main international
approval bodies and are ETL marked.

Accessories

• Pair of stainless Steel runners for
23 and 50 ft
3
SMART refrigerators
®
• Rilsan
coated full-size sheet grid

Optional Accessories

• Basic HACCP Printer
• 4 wheels (2 with brake)
• Pair of stainless steel runners for
3
23 and 50 ft
SMART refrigerators
®
• Rilsan
coated full-size sheet grid
3
• Pedal opening for 50 ft
SMART refrigerators
8
8
(PNC 880048)
(PNC 880121)
(PNC 880175)
(PNC 880176)
(PNC 881459)
