Summary of Contents for BSS Audio Soundweb 9000
- Page 1 Soundweb Soundweb Soundweb 9000 9000 9000 Soundweb Soundweb 9000 9000 Installation Guide...
-
Page 2: Regulatory Information
Any such disconnections are outside the recommended practice of BSS Audio, and will render the EMC or safety certificate void. Do not defeat the safety purpose of the polarised/grounding plug. A polarised plug has 2 blades, one wider than the other. A grounding type plug has 2 blades, and a third grounding prong. - Page 3 Front panel LED functions Network monitoring Network monitoring Network monitoring Network monitoring Network monitoring Each node has 3 LED indicators showing: Network Network Network Network Network Master Master Master Master Master Flashing - The network is initialising. If it does not cease to flash, there is a cabling fault - either a double ring error or a problem with one of the cable connectors.
- Page 4 Rear panel details Mains inlet Mains inlet Mains inlet Mains inlet Mains inlet IEC power connector for removable mains supply. Fuse holder Fuse holder Fuse holder Fuse holder Fuse holder Mains fuse - requires a 20mm T1A type fuse. Aux RS232 Aux RS232 Aux RS232 Aux RS232...
- Page 5 Control Inputs Used to connect switches or potentiometers to the 9000. These eight inputs are internally ‘pulled up’ to +5V DC via a 4.7kOhm resistor, so no external voltage source is needed. Four common (ground) connections are provided (all connected together internally). A 47kOhm log potentiometer connected between one input and common will allow parameters to be controlled linearly.
-
Page 6: Technical Specifications
Technical specifications General General General General General Maximum network cable length 300m/1000ft Power consumption <35VA Mains Voltage 85-270V 50/60Hz Control ports Control ports Control ports Control ports Control ports Logic output voltage 0 or +5V unloaded Logic output impedance 440 Ohm Opto output series impedance 220 Ohms (isolated) Control input voltage 0 to 4.5v Control input impedance 4.7kOhms to +5V...
