- Page 1 S 75408 KG3 Refrigerator freezer combination Instruction book A/AE/9. (06.) PERFEKT IN FORM UND FUNKTION 200370793...
- Page 2 Dear customer, Before switching on your new appliance please read these operating instruc- tions carefully. They contain important information for safe use, for installa- tion and for care of the appliance. Please keep these operating instructions for future reference. Pass them on to possible new owners of the appliance. These operating instructions are for use with several technically comparable models with varying accessories.
-
Page 3: Table Of Contents
Operating and indicator panel Fridge...14 Temperature setting buttons...14 Temperature display ...14 Starting Up - Setting the Temperature ...15 COOLMATIC ...15 Holiday function ...15 How to use the refrigerator ...16 Interior Accessories ...16 Storage Shelves ...16 Air filter ...17 Drawer...17 Storing in the refrigerator...18 Chiller Zone ...18... - Page 4 How to change the bulb ...28 Electrical connection...28 Electrical Requirements ...29 Storage time chart (1) ...30 Time and method of storage of fresh foods in the refrigerator...30 Storage time chart (2)...31 Storage time of deep-frozen and products...31 Service and Spare Parts...32 Customer Care Department ...32...
-
Page 5: Important Safety Information
Important safety information General safety precautions Keep these instructions and they should remain at the appliance when moving away or changing owner. This appliance is designed for storing food, domestic use according to these instructions only. Specialised companies that are qualified to do so by the manufacturer must carry out service and repairs including repairing and changing the power cord. -
Page 6: Precautions For Child Safety
Do not put hot pot to the plastic parts. Do not store flammable gas and liquid in the appliance, because they may explode. Do not store carbonated drinks, bottled drinks and bottled fruits in the frozen food compartment. Check and clean the outlet of melting water coming during defrosting reg- ularly. -
Page 7: Installing The Appliance
Installing the appliance Transportation, unpacking It is recommended to deliver the appliance in original packaging, in vertical position considering the protective warning on packaging. After each transportation the appliance must not be switched on for approx. 2 hours. Unpack the appliance and check if there are damages on it. Report possible damages immediately to the place you bought it. -
Page 8: Placement
Placement The ambient temperature has an effect on the energy consumption and proper operation of the appliance. When placing, take into consideration that it is practical to operate the appliance between ambient temperature limits according to the climate class that is given in the chart below and can be found in the data label. Class of climate If the ambient temperature goes below the lower data the temperature of the cooling compartment can go beyond... -
Page 9: Installation Of The Carbon Filter
In case of oil or coal-fired stove the distance must be 30 cms since they give off more heat. The refrigerator is designed to oper- ate when it is totally pushed to the wall. When placing the refrigerator keep minimal distances recommended in figure. -
Page 10: Change Of Door Opening Direction
Do not forget to remove the plastic spacer (b) under the hinge. (fig. 2) 5. Take off the refrigerator door by pulling it slightly downwards. 6. Take off the freezer door by pulling it slightly upwards. - Page 11 19. Fit the freezer door to the lower door hinge pin (f). (fig. 4) 20. Fit the refrigerator door to the upper door hinge pin (d) then slightly tilting both doors fit the pin of the double door hinge (m) into the left drill of the refrigerator door.
-
Page 12: Instructions For The User
Instructions for the User General Information The official designation of the appliance is "frostfree refrigerator-freezer combination with one motor compressor and freezer placed in the lower part". The appliance has - besides the general services - a freezer with its own door and is completely separated from the other unit. -
Page 13: Description Of The Appliance, Main Parts
Description of the appliance, main parts A - Refrigerator B - Freezer 1. Top with indicating switch 2. Air distributing and lighting box 3. Glass shelves 4. Bottle rack 5. Glass shelf 6. Chiller Zone 7. Drawer 8. Data label 9. -
Page 14: Operating And Indicator Panel Fridge
Operating and indicator panel Fridge A. ON/OFF button B. Temperature setting button (for warmer temperatures) C. Temperature display D. Temperature setting button (for colder temperatures) E. COOLMATIC function "on" indicator (yellow) F. COOLMATIC button Temperature setting buttons The temperature is adjusted using the (B) and (D) buttons. These buttons are connected to the temperature display. -
Page 15: Starting Up - Setting The Temperature
Holiday function The holiday function sets the temperature at +15°C. This function allows you to keep the refrigerator shut and empty during a long holiday period (e.g. the summer holidays) without the formation of a bad smell. 1. To turn on the holiday function, press button (B). -
Page 16: How To Use The Refrigerator
(e.g. with tray etc.). Do not put hot food into the refrigerator. Allow it to reach room temper- ature naturally. In this way the unnecessary frost building up can be avoid- Foods can take over odours from each other. -
Page 17: Air Filter
Air Filter Your appliance is equipped with a car- bon filter behind a flap in the rear wall of the air distributing box. The filter purifies the air from unwanted odours in the fridge com- partment meaning that the storage quality will be further improved. -
Page 18: Storing In The Refrigerator
That is why the storage time made known is only informative. If you do not want to use up deep-frozen foods bought immediately they can be stored for about 1 day (until dissolving) in the refrigerator. foods... -
Page 19: Operating And Indicator Panel Freezer
Operating and indicator panel Freezer G. FROSTMATIC function "on" indica- tor (yellow) H. FROSTMATIC button I. Temperature setting button (for warmer temperatures) J. Temperature display K. Temperature setting button (for colder temperatures) L. Alarm reset button M.Alarm reset light Temperature setting buttons The temperature is adjusted using the (I) and (K) buttons. -
Page 20: Starting Up - Setting The Temperature
Starting Up - Setting the Temperature 1. Plug the mains plug into the mains socket. 2. Press (A) button. The alarm light (M) flashes since the temperature is reached. The buzzer sounds. 3. Pressing button (L) the buzzer stops. 4. Press either the (I) or (K) button. The temperature display switches over and the DESIRED temperature currently set flashes on the temperature display. -
Page 21: Switching The Appliance Off
There is a risk of an explosion! Do not store any containers with flamma- ble materials such as, for example, spray cans, fire extinguisher refill car- tridges etc in the refrigerator/freezer. Bottles and cans must not be placed in the freezer. They can burst when the contents freeze, high carbonate content drinks can even explode! Never store lemonade, juices, beer, wine, sparkling wine etc. -
Page 22: Storing In The Freezer
1. To achieve faster freezing of food or to freeze the maximum allowed quanti- ty, depress the ambient switch 12 hours before loading the food without modifying the thermostat setting. 2. Place the food to be frozen in the top drawer. 3. -
Page 23: Some Useful Information And Advice
+/- 1 °C into it. If after 6 hours you measure a value around that seen on the display, the refrigerator works properly. The measuring shall be performed under steady-stated conditions (without changing the load). -
Page 24: Hints And Ideas
Hints and ideas In this chapter practical hints and ideas are given about how to use the appli- ance to reach maximum energy saving and there is environmental informa- tion about the appliance as well. How to save energy 1. Avoid putting the appliance in a sunny place near anything that gives off heat. -
Page 25: Maintenance
Maintenance Defrosting Defrosting is automatic in this model. Regular cleaning Clean the equipment regularly. Don't use detergents, abrasive or strongly odorous cleaners, waxy polish- ing agents or disinfectants or alkoholic products for cleaning the equip- ment. Before cleaning pull out the wall plug of the equipment from the outlet. Internal cleaning Clean the internal parts of the equipment and the accessories with warm water and sodium bicarbonate (5 ml to 0.5 litre of water). -
Page 26: Changing The Carbon Filter
Changing the Carbon Filter To maintain the best performance the carbon filter should be changed every year. New carbon filters can be purchased from your local dealer. 1. Pull the flap outwards. (1) 2. Remove the filter from the plastic bag. 3. -
Page 27: If Something Does Not Work
Possible cause Set the thermostat knob to higher position. Place the products according to the chapter „Storing in the refrigerator”. Check if the door closes well and the gasket is unhurt and clean. Set the thermostat knob to higher position. - Page 28 Problem The compressor oper- The thermostatic control is set wrong- ates continually. Doors are not shut properly or do not close tightly. Products in big quantity to be frozen were put in. Too warm food was put in. The appliance does Plug is not connected to the mains not work at all.
-
Page 29: How To Change The Bulb
Electrical connection This refrigerator is designed to operate on a 230 V AC ( ~ ) 50 Hz supply. The plug must be put into a socket with protective contact. If there is no such, it is recommended to get an electrician to fit an earthed socket in compliance with standards near the refrigerator. -
Page 30: Electrical Requirements
Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. The appliance is supplied with a 13 amp plug fitted. In the event of having to change the fuse in the plug supplied, a 13 amp ASTA approved (BS 1362) fuse must be used. -
Page 31: Time And Method Of Storage Of Fresh Foods In The Refrigerator
Storage time chart (1) Time and method of storage of fresh foods in the refrig- erator Foods Raw meat Cooked meat Roasted meat Raw minced meat Roasted minced meat Cold cuts, Vienna sausage Fresh fish Cooked fish Fried fish Tinned fish, open Fresh chicken Fried chicken Fresh hen... -
Page 32: Storage Time Chart (2)
Storage time chart (2) Storage time of deep-frozen and frozen products Foods Vegetables: green beans, green peas, mixed vegetables, marrow, corn, etc. Ready-cooked foods: vegetable dish, trimmings, with meat, etc. Ready-cooked foods: sirloin steaks, stew from knuckle of ham, meat from pig pudding, etc. Foods from potatoes, pasta: mashed potato, gnocchi, dumpling, pasta filled with jam, chips Soups:... -
Page 33: Service And Spare Parts
Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning: Your telephone call will be automatically routed to the Service Force Centre covering your post code area. -
Page 34: Guarantee Conditions
GUARANTEE CONDITIONS Standard guarantee conditions We, AEG, undertake that if within 12 months of the date of the purchase this AEG appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our discretion repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electrici-... -
Page 35: European Guarantee
European Guarantee If you should move to another country within Europe then your guarantee moves with you to your new home subject to the following qualifications: The guarantee starts from the date you first purchased your product. The guarantee is for the same period and to the same extent for labour and parts as exists in the new country of use for this brand or range of prod- ucts. - Page 36 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
