Blueant X3 micro Quick Start Manual

Quick Start Guide

Inside the box
One Bluetooth Headset.
One X3 micro User Guide.
One Quick Start Guide.
One USB charging cable.
One car lighter adapter for USB charging cable.
One AC wall charger
One soft gel earbud cover
One foam earbud cover
One removable ear-hook.
Function / Button matrix
Function
Power on/off
Pair
Voice dial using the current connected phone when connected
Voice dial through the first paired phone when not connected
Cancel voice dialing
Cancel last call redial
Answer a call
End a call
Voice dial through the second paired phone when not connected
Voice dial through the third paired phone when not connected
Turn on/off LED lights (disconnect from phone first)
Last call redial using the current connected phone when connected
Last call redial using the first paired phone when not connected
Reject a call
Volume up
Volume down
Mute / Unmute the microphone
Disconnect the Bluetooth connection to the current phone
Audio transfer from the headset to your phone
Reset (deletes all stored pairing information)
Pairing the Headset to a Mobile Phone
1. Charge the X3 micro for at least 4 hours before use. Reboot the mobile phone.
2. Long Press the MFB (Multi-Function Button) to turn the X3 micro ON.
(The X3 may go straight into Pairing mode and not require the next step,
LED flashes Red to Blue)
3. Long press Vol to enter Pairing mode. LED flashes Red to Blue.
4. Turn Bluetooth ON in your phone.
5. Perform a device discovery to search for the X3 micro.
6. When devices are displayed, select the X3 micro. Enter Passkey "1234".
7. Set the X3 micro as a trusted/authorised device, if optional in your phone.
8. Short press the MFB once to connect to your phone.
Voice dialing will be activated if it is enabled in your phone.
To cancel voice dialing, short press the MFB
9. For X3 operations refer to Function / Button Matrix below.
To pair up to 2 more devices; phones, smartphones, pda's or computers –
1. Short press the MFB and Vol
2. Repeat steps 5 – 8 for each device you want to pair.
3. See Multi Connect Call Switching below.
Button
long press for 3 seconds
long press for 3 seconds
short press 1 time
short press 2 times
short press 3 times
short press 5 times
long press for 3 seconds
long press for 3 seconds
short press 1 time
short press 1 time
short press 1 time
short press 1 time
short press 1 time
Quick Start Guide
.
together to disconnect the current phone.
Reconnecting the Headset
Once the Headset has been disconnected (by switching off
or going out of range) you will need to reconnect by:
1. Short pressing the MFB
Once for the first paired phone
Twice for the second paired phone
Three times for the third paired phone.
2. Voice dialing will be activated if enabled in phone
To cancel voice dialing Short press the MFB
Multi Connect Call Switching
To disconnect from the currently connected phone and
switch to another:
1. Short press the MFB and Vol
2. Short press the MFB
Once for the first paired phone
Twice for the second paired phone
Three times for the third paired phone.
together
