User Guide X3 Micro Bluetooth Headset
Contact Us and Warranty Process and conditions
1-2
3-5
6-11
12-18
19-23
24-25
26-27
28
29-32
33-35
36
37-48
49-52

Advertisement

Table of Contents
loading

Related Manuals for Blueant X3 Micro

Summary of Contents for Blueant X3 Micro

  • Page 1: Table Of Contents

    User Guide X3 Micro Bluetooth Headset Introduction Bluetooth headset overview Getting started 6-11 Using your headset 12-18 Using your headset with multiple Bluetooth devices 19-23 Function / Button matrix 24-25 LED indicator chart 26-27 Audio indicator chart Additional information 29-32 Declaration of conformity 33-35 Regulatory information...

  • Page 2: Introduction

    Introduction lntroduction Handle incoming and outgoing calls. Adjust the volume. Your Bluetooth headset is a portable headset solution based on Bluetooth wireless technology. Mute the microphone. Please read the "Additional Information” before using your headset. Voice dialing (if your phone supports this function). What is Bluetooth wireless technology? Last call redial (if your phone supports Handsfree profile).

  • Page 3: Bluetooth Headset Overview

    Bluetooth Headset overview Headset overview 1 Indicator LED 2 Multi Function Button (MFB) 3 Volume Control + - 4 Removable Ear Hook 5 Speaker 6 Microphone 7 Charging Port...

  • Page 4: Getting Started

    Getting started Getting started Before you can use your headset, you must do the following two things: 1. Charge your headset battery for 4 hours using only the charger provided. 2. Pair your headset with a Bluetooth enabled device, for example, a mobile phone. IMPORTANT NOTE: Charging It is recommended to charge the battery only when it...
  • Page 5 Getting started Charging the X3 Micro with the USB connecter 1. Plug the USB charging cable into the charging port of your headset. 2. Plug the other end of the USB charging cable into the PC/Mac's USB port or the car charger. 3.
  • Page 6 Getting started Power On / Off Pairing the X3 Micro Headset with a Bluetooth mobile phone or PDA Before using the X3 Micro for the first time, you must pair the headset with your mobile phone. Power on your headset The Bluetooth audio connection between the headset and your phone can be established by first setting up a paired link.

  • Page 7: Using Your Headset

    Using your headset Using your headset Put your headset into pairing mode by long pressing (3 seconds) the Volume up button. You can see the blue indicator and red indicator cross blink every second. After you have paired your headset with your phone, you can make and receive a call using Your headset is now ready to be discovered by your Bluetooth mobile phone.
  • Page 8 Using your headset Note: 3. Short press the MFB on your headset. It may take a while to set up the Bluetooth If your phone rings first, wait until your headset rings, then short press the MFB. Your phone connection if the Bluetooth connection is down. takes time to set up the Bluetooth connection if the Bluetooth connection is down.
  • Page 9 Using your headset To reject an incoming call Note: For safety reasons, do not always adjust the listening volume to the maximum setting. 1. Make sure your phone supports Handsfree profile. For Headset mode Call Reject must be done using the phone. To mute the microphone 2.
  • Page 10 Using your headset To turn the flashing LED lights off (for night time driving) Phone Software Please make sure you have the latest firmware upgrade for your Phone especially if you are 1. Make sure the headset is on but not connected to any phone. using a PDA Phone.

  • Page 11: Using Your Headset With Multiple Bluetooth Devices

    Using your headset with multiple Bluetooth devices Using your headset with multiple Bluetooth devices To answer a call on any of the paired phones Your headset can be used with up to three different Bluetooth V1.1/V1.2 compliant devices that When any of your paired phones rings you can answer by - support Headset or Handsfree profile.
  • Page 12 Using your headset with multiple Bluetooth devices Note: 2. After you hear a beep, say the name of the contact you want to call. Your headset takes time to set up the Bluetooth connection with the required phone. If 3. To cancel the voice dialing or end the call, short press the MFB you hear the ring tone from your headset, short press MFB again to answer this call.

  • Page 13: Function / Button Matrix

    Function / Button matrix Resetting your headset Function / Button matrix Function Button Note: If you have paired the headset with 3 devices you cannot then enter into pairing mode as long press for 3 seconds the memory is full. If you want to pair your headset with another phone you must reset your Power on/off headset to clear the paired devices list.

  • Page 14: Led Indicator Chart

    LED Indicator chart LED indicator chart Function Button Last call redial using the current connected phone when connected Headset State LED Indication long press for 3 seconds Last call redial using the first paired phone when not connected Power on Blue indicator blinks twice Reject a call long press for 3 seconds...

  • Page 15: Audio Indicator Chart

    Audio Indicator chart Audio indicator chart Headset State LED Indication Headset state Audio indication Mute Red indicator blinks once per second Power on Ascending melody Low battery Red indicator rapidly blinks twice every 5 seconds Power off Descending melody Pairing success Fast melodic tone Volume adjustment Short beep.

  • Page 16: Additional Information

    Use of non-Blueant original accessories may result in loss of performance, product damage, If you will not be using your headset for a while, store it in a place that is dry, free from electronic shock or injury, and warranty termination.
  • Page 17 Additional information X3 Micro specification Battery information The rechargeable battery of your headset is not fully charged when it is new. For first Bluetooth compliance Bluetooth version 1.2 with Headset profile and Handsfree profile time, please charge for 4 hours before using. Bluetooth power 2.5mW (0.0025W) When the rechargeable battery of your headset is low, there will be one battery low tone and...

  • Page 18: Declaration Of Conformity

    Declaration of conformity Declaration of conformity pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable FCC statement protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in This device complies with Part 15 of the FCC Rules.

  • Page 19: Regulatory Information

    Any modifications or changes (e.g. antennas) made to this headset that are not expressly This Transmitter must not be co-located or operating in conjunction with any other antenna or approved by Blueant may void the user's authority to operate this headset. Blueant is transmitter.

  • Page 20: Frequently Asked Questions

    Bluetooth FREQUENTLY ASKED QUESTIONS (FAQ) 1. Is it safe to use Bluetooth devices, I have heard they can allow unauthorized connections? General 2. Can somebody else take control of my X3 micro if they are in range? 3. What is the difference between Handsfree and Headset Bluetooth Profiles? 1.
  • Page 21 General 6. My X3 micro worked great but now it won’t connect, what can I do? 7. Why can the talk time and standby time differ from the products specification? 8. Why does my phones battery not last as long as it used to? 1.
  • Page 22 If your phone has Bluetooth it more than likely supports a Handsfree or Headset Bluetooth profile, and so will work with the X3 micro. Check your phones manual or our compatibility list on the Blueant website for up to date information.
  • Page 23 3. What is the difference between Handsfree and Headset Bluetooth Profiles? 13. Can I use my X3 micro with my computer for VOIP applications? Handsfree Profile allows for extra features to be used with a mobile phone. Voice Dial, redial, Yes, you can connect the X3 micro to a PC or Mac that supports the Headset or Handsfree profile.
  • Page 24 3. Is my X3 micro charged? 7. If I cup my hand over a bluetooth device the signal strength and quality suffers. Why does this happen? A red light will blink twice every 5 seconds when the battery is low. Bluetooth signals are radio waves and so do not need line of sight to operate.
  • Page 25 11. My phone says “Bluetooth Module not found” what can I do? 7. Why can the talk time and standby time differ with the products specification description? This means that your phone cannot find its internal Bluetooth chip for some reason. Restarting The talk time and stand by time will differ based on different brands’...
  • Page 26 For Connection Assistance or if you are having difficulties using your X3micro, 3. Call us and speak to one of the Blueant Wireless Customer Service Team We will clarify whether you have a hardware or connection issue. please make an enquiry on our website www.blueantwireless.com...
  • Page 27 Warranty Terms and Conditions 1. Blueant Warrant the original purchaser of this product only. 2. Blueant will replace or repair any faulty product provided it has not been misused or abused in any way. 3. There are no user serviceable parts inside this product. Using a non-authorized repairer will void the warranty.
