FEB27T7FC.tif CPLEB30T9FCA.eps BUFEB27T6FCA.eps BLFEB27T6FCA.eps
DFEB27S7FCB.eps
318046123.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB27T7FCC
37054783F60S3
Series
27" double
Color
stainless
Market
North America
Wiring Diagram
318046123
Owner's Guide
318205119
Installation Instructions 318201514
Service Data Sheet
318047309
Timer Guide
318200129
Publication No.
5995490819
07/05/15
(EN/SERVICE/BJH)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T7F
©
Copyright
2007 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FEB27T7FCC
Summary of Contents for Frigidaire FEB27T7FCC
-
Page 1: Wall Oven
Product No. FEB27T7FCC 37054783F60S3 Series 27" double Color stainless Market North America Wiring Diagram 318046123 Owner's Guide 318205119 Installation Instructions 318201514 Service Data Sheet 318047309 Timer Guide 318200129 DOUBLE ELECTRIC FEB27T7FC.tif CPLEB30T9FCA.eps BUFEB27T6FCA.eps BLFEB27T6FCA.eps WALL OVEN DFEB27S7FCB.eps 318046123.eps Electrolux Major Appliances Model No. -
Page 2: Control Panel
Publication No: 5995490819 FEB27T7FCC CONTROL PANEL 05/07... - Page 3 FEB27T7FCC Publication No: 5995490819 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257301 Shield, oven top 318260101 Cover, box 318271536 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316443831 Control, electronic, ES610W2, dual oven 316247900 Spacer, power board, (4) 316114100 Spacer, (2) 316443912 Board, relay, dual oven...
-
Page 4: Upper Oven
Publication No: 5995490819 FEB27T7FCC UPPER OVEN 05/07... - Page 5 FEB27T7FCC Publication No: 5995490819 UPPER OVEN POS. NO PART NO. DESCRIPTION 318259212 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 5303317977 Pan, broiler 5303317976 Insert, broiler pan 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light...
- Page 6 Publication No: 5995490819 FEB27T7FCC UPPER OVEN 05/07...
- Page 7 FEB27T7FCC Publication No: 5995490819 UPPER OVEN POS. NO PART NO. DESCRIPTION 318003000 Plate, shield 318123910 Deflector 318172904 Support, wire 318014111 Spacer 318014700 Spacer, oven shield, (4) 316136500 Washer, flat 318257711 Trim, oven, black, front 5304440067 Cabinet Mounting Kit 318246010 Bracket, cabinet mtg, (2) 311* 5304438005 Screw, 6 x 1, black...
-
Page 8: Lower Oven
Publication No: 5995490819 FEB27T7FCC LOWER OVEN 05/07... - Page 9 FEB27T7FCC Publication No: 5995490819 LOWER OVEN POS. NO PART NO. DESCRIPTION 318259212 Back, main 318258910 Shield, insulation, upper 318345209 Rack, oven, (3) 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 08011086 Lens, oven light, glass 5304400195 Retainer, light cover...
- Page 10 Publication No: 5995490819 FEB27T7FCC LOWER OVEN 05/07...
- Page 11 FEB27T7FCC Publication No: 5995490819 LOWER OVEN POS. NO PART NO. DESCRIPTION 125# 316415800 Motor, fan 3016303 Clip, insulator 318317100 Adapter Assembly, vent tube, w/converter 318123910 Deflector 318172904 Support, wire 318014111 Spacer 318014700 Spacer, oven shield, (4) 316136500 Washer, flat 318257811 Trim, oven, black, front 318078543 Box &...
- Page 12 Publication No: 5995490819 FEB27T7FCC DOORS DFEB27S7FCB 05/07...
- Page 13 FEB27T7FCC Publication No: 5995490819 DOORS POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260510 Baffle, door 318372000 Insulation, door, (2) 318372001 Insulation, door, 20.5 x 2.375, (2) 318212200 Glass, oven door, heat barrier 318259615 Liner, upper door 5303325980...
-
Page 14: Wiring Diagram
Publication No: 5995490819 FEB27T7FCC WIRING DIAGRAM 05/07...
