FEB27T5D.eps CGLEB27T9DSC.eps BUFEB27T5DCB.eps BLFEB27T5DSA.eps
DFEB30S5DSA.eps
318046121.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB27T5DBC
37054741E4063 37054741E4013
Series
27" double
Color
black
Market
North America
Wiring Diagram
318046121
Owner's Guide
318200924
Installation Instructions 316201514
Service Data Sheet
318047306
Timer Guide
318200137
Publication No.
5995459301
06/01/23
(EN/SERVICE/ECL)
377
FEB27T5DSC
27" double
white
North America
318046121
318200924
316201514
318047306
318200137
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T5D
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FEB27T5DBC
Summary of Contents for Frigidaire FEB27T5DBC
-
Page 1: Wall Oven
U p p er O ven Self-Cleaning O vens Low er O ven Bake Cl ean Bake Cl ear Bake Cl ean Bake Cl ear ti m e / Off ti m e / Off Control s Control s U PPER O VEN LO W ER O VEN Keep Start... -
Page 2: Control Panel
Publication No: 5995459301 FEB27T5D CONTROL PANEL 01/06... - Page 3 FEB27T5D Publication No: 5995459301 CONTROL PANEL Model Index: A FEB27T5D (FEB27T5DSC) B FEB27T5D (FEB27T5DBC) POS. NO PART NO. DESCRIPTION 318257301 Shield, oven top 318260101 Cover, box 318342808 Control Panel Assembly, glass, white, w/touch pad 318342809 Control Panel Assembly, glass, black, w/touch pad 20 # 316443800 Control, electronic, ES610W1, dual oven...
-
Page 4: Upper Oven
Publication No: 5995459301 FEB27T5D UPPER OVEN 01/06... - Page 5 FEB27T5D Publication No: 5995459301 UPPER OVEN Model Index: A FEB27T5D (FEB27T5DSC) B FEB27T5D (FEB27T5DBC) POS. NO PART NO. DESCRIPTION 318259210 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 5303317977 Pan, broiler 5303317976 Insert, broiler pan 12 # 318089917 Switch, light 318224000 Receptacle, oven light...
-
Page 6: Lower Oven
Publication No: 5995459301 FEB27T5D LOWER OVEN 01/06... - Page 7 FEB27T5D Publication No: 5995459301 LOWER OVEN Model Index: A FEB27T5D (FEB27T5DSC) B FEB27T5D (FEB27T5DBC) POS. NO PART NO. DESCRIPTION 318259210 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light...
- Page 8 Publication No: 5995459301 FEB27T5D DOORS 01/06...
- Page 9 FEB27T5D Publication No: 5995459301 DOORS Model Index: A FEB27T5D (FEB27T5DSC) B FEB27T5D (FEB27T5DBC) POS. NO PART NO. DESCRIPTION 318260211 Trim, oven door, black, upper 318260401 Trim, oven door, side, (2) 318261351 Glass Assy., oven door, white, outer, w/trim 318261350 Glass Assy., oven door, black, outer, w/trim 318260510 Baffle, door 318285057...
-
Page 10: Wiring Diagram
Publication No: 5995459301 FEB27T5D WIRING DIAGRAM OUTSIDE INTSIDE COLOR CODE/CODIGOS DE COLOR/CODE OVEN CIRCUIT // CIRCUITO DE HORNO // CIRCUIT DU FOUR INTERIOR EXTERIOR DE COULEUR INTERIEUR EXTERIEUR BK-7 G.-GREEN/VERDE/VERT OR/O/OU BK-8 CONVECTION FAN/VENTILADOR DE CONVECCION/ W.-WHITE/BLANCO/BLANC (BK-8)* CONVECTION VENTILATEUR R.-RED/ROJO/ROUGE OPTION BR-5...
