Product System (PS)
C5-501 Service Manual
Subject:
99.K7001.001
Project Code:
DHR200
Model Name:
Chapter 1 : System disassembly -----------------------------------------------------------------
1.1.1 Battery Pack ------------------------------------------------------------------------------------------------------------------------------------ 3
1.1.2 Keyboard --------------------------------------------------------------------------------------------------------------------------------------- 4
1.1.3 CPU ---------------------------------------------------------------------------------------------------------------------------------------------6
1.1.4 HDD Module ---------------------------------------------------------------------------------------------------------------------------------- 8
1.1.5 DVD-ROM Drive ------------------------------------------------------------------------------------------------------------------------------ 10
1.1.6 Wireless Card -----------------------------------------------------------------------------------------------------------------------------------11
1.1.7 DDR-SDRAM ---------------------------------------------------------------------------------------------------------------------------------- 12
1.1.8 LCD Assembly ---------------------------------------------------------------------------------------------------------------------------------- 13
1.1.9 LCD Panel -------------------------------------------------------------------------------------------------------------------------------------- 16
1.1.10 Inverter Board --------------------------------------------------------------------------------------------------------------------------------- 18
1.1.11 Modem Card ---------------------------------------------------------------------------------------------------------------------------------- 19
1.1.12 System Board ---------------------------------------------------------------------------------------------------------------------------------- 20
1.1.13 Touch Pad ------------------------------------------------------------------------------------------------------------------------------------- 21
Chapter 2 : Fru. list -----------------------------------------------------------------------------------------------------------------------------------22
Chapter 3 : Screw torque list ------------------------------------------------------------------------------------------------------------------------ 31
Form No: BQY0-0B-003-32(031205)
Part No.:
Doc. No.
Component Part. No.:
Marketing Description :
R23 System Disassembly
99.K7001.000
99.K7001.000-C5-501-001
NA
- Table of Contents
----------------------------------------------------------2
Rev.:
0
Page 1 of 32
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DHR200 and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ DHR200

Summary of Contents for BenQ DHR200

  • Page 1 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 1 of 32 DHR200 Model Name: Marketing Description : R23 System Disassembly - Table of Contents ----------------------------------------------------------2 Chapter 1 : System disassembly ----------------------------------------------------------------- 1.1.1 Battery Pack ------------------------------------------------------------------------------------------------------------------------------------ 3 1.1.2 Keyboard --------------------------------------------------------------------------------------------------------------------------------------- 4 1.1.3 CPU ---------------------------------------------------------------------------------------------------------------------------------------------6...

  • Page 2: Chapter 1 : System Disassembly

    Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 2 of 32 DHR200 Model Name: Marketing Description : 1.1 System Disassembly The section discusses at length each major component for disassembly/reassembly and show corresponding illustrations.Use the chart below to determine the disassembly sequence for removing components from the notebook.

  • Page 3: Battery Pack

    Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 3 of 32 DHR200 Model Name: Marketing Description : 1.1.1 Battery Pack Disassembly 1. Carefully put the notebook upside down. 2.

  • Page 4: Keyboard

    Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 4 of 32 DHR200 Model Name: Marketing Description : 1.1.2 Keyboard Disassembly 1. Remove the battery pack. (Refer to section 1.1.1 Disassembly) 2.
  • Page 5 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 5 of 32 DHR200 Model Name: Marketing Description : 4. Slightly lift up the keyboard. (Figure 1-4) 5. Disconnect the cable from the system board, then separate the keyboard. (Figure 1-5) Figure 1-4 Lift the keyboard Figure 1-5 Disconnect the cable Reassembly...
  • Page 6 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 6 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 7 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 7 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 8 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 8 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 9 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 9 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 10 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 10 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 11 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 11 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 12 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 12 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 13 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 13 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 14 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 14 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 15 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 15 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 16 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 16 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 17 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 17 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 18 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 18 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 19 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 19 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 20 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 20 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 21 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 21 of 32 DHR200 Model Name: Marketing Description : Form No: BQY0-0B-003-32(031205)
  • Page 22 Page 22 of 32 DHR200 Model Name: Marketing Description : R23 Spare Parts FRU List Which Model can Use: CATEGORY BenQ PN BenQ Description R31/R22E/5200G /R23 56.91K17.031 LCDM 15" XGA B150XG02 V4 AU RoHs 56.35K49.001 DVD Dual KME UJ-840BMT2-A (G-baze) FW:1.00...
  • Page 23 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 23 of 32 DHR200 Model Name: Marketing Description : 5D.K6614.021 Touch Pad R23 2C.4K700.001 Speaker Module L DH2100 2C.4K700.011 Speaker Module R DH2100 54.K4710.001 Inverter Board DH2100...
  • Page 24 K/B Shieding Plate R23 3C.K7001.001 MECHANICAL R23 6E.K7005.001 Bottom Case R23 PARTS 4A.K7003.001 ODD Bezel COMBO Gbase 4A.K7002.001 ODD Bezel DVD DUAL Gbase 6E.K7006.001 LCD Cover without Logo 4K.7002.001 BenQ Logo 4A.K7001.001 LCD Bezel R23 6E.K7007.001 K/B Cover R23 Form No: BQY0-0B-003-32(031205)
  • Page 25 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 25 of 32 DHR200 Model Name: Marketing Description : 6E.K7008.001 Touch pad R23 6E.K7013.001 Touch pad Botton mudule R23 6E.K7009.001 LCD Cover Latch knob&...
  • Page 26 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 26 of 32 DHR200 Model Name: Marketing Description : 6E.K7011.001 HDD Case R23 4B.K7001.001 CPU Door Cover R23 4B.K7002.001 HDD Door Cover R23 2100/A32/R22/R SCREW...
  • Page 27 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 27 of 32 DHR200 Model Name: Marketing Description : 2100/R22/R31/R PACKING Brown Carton 44.K4702.001 2100/R22/R31/R Accessory Pizza Box without Partition 44.K4703.001 2100/R22/R31/R Partition in Pizza Box...
  • Page 28 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 28 of 32 DHR200 Model Name: Marketing Description : R31/R23 Keyboard UK / English R31 56.24K64.UK1 R31/R23 Keyboard Spain / Spanish R31 56.24K64.SP1 Keyboard International English/ Netherlands / Dutch R31/R23...
  • Page 29 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 29 of 32 DHR200 Model Name: Marketing Description : R23 IT Manual Kit 6E.K7003.Y01 R23 SP/Mexico Manual Kit 6E.K7003.S01 6E.K7003.D01 R23 NL/Pan EuropeManual Kit 6E.K7003.Q01...
  • Page 30 Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 30 of 32 DHR200 Model Name: Marketing Description : 6E.K7002.C01 OS KIT SC XPP SP2 A33 OS KIT HK XPP SP2 A33 6E.K7002.K01 OS KIT TH/AU/NZ/SG/MY/UK/Pan Europe XPP SP2 6E.K7002.E01...

  • Page 31: Lcd Assembly

    Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 31 of 32 DHR200 Model Name: Marketing Description : R23 SCREW TORQUE LIST Torque (Kgf.cm) Quantity Remark Item Screw P/N Spec Color Assembly Location...

  • Page 32: Modem Card

    Product System (PS) C5-501 Service Manual 99.K7001.000 Subject: Part No.: Rev.: 99.K7001.000-C5-501-001 Doc. No. 99.K7001.001 Project Code: Component Part. No.: Page 32 of 32 DHR200 Model Name: Marketing Description : 11 370102030301 M2L3 Zn-Black Top shielding&Top cover 1.0～1.5 12 370102610603 M2.6L6 Zn-Black 鎖附...
