- Page 1 Owner’s Manual MOON Series 320 S Power Supply...
-
Page 2: Important Safety Instructions
MOON 320S Power Supply Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or another apparatus that produces heat. - Page 3 European Community Please read all instructions and precautions carefully and completely before operating your Simaudio MOON 320S Power Supply. ALWAYS disconnect your entire system from the AC mains before connecting or disconnecting any cables, or when cleaning any component. To completely disconnect this apparatus from the AC mains, disconnect the power suppy cord plug from the AC receptacle.
-
Page 4: Table Of Contents
Introduction ............ 6 Installation & Placement ........6 310LP Internal Settings ........7 Rear Panel Connections ........8 Operating the 320S .......... 9 Specifications ..........10 www.simaudio.com Simaudio Ltd., 1345 Newton Road Boucherville, Quebec J4B 5H2 CANADA Date Code: 20130306 ____________________________________________________________________________________... -
Page 5: Congratulations
Simaudio has made its reputation. We have spared no effort to ensure that it is provides a significant improvement to the sonic performance of your MOON 310LP Phono Preamplifier. We have been building high-performance audio equipment for almost 30 years, and the know-how gained through our cumulative experience is an important reason why MOON audio components are so musically satisfying. -
Page 6: Introduction
MOON 320S Power Supply Introduction Your MOON 320S Power Supply incorporates many significant design features to enhance the “world class”performance of your MOON 310LP Phono Preamplifier. This is an abbreviated list of the more important features: High quality toroidal transformer. 4 stages of DC voltage regulation. -
Page 7: 310Lp Internal Settings
MOON 320S Power Supply 310LP Internal Settings Figure 1: MOON 310LP Circuit Board layout Prior to connecting your MOON 310LP Phono Preamplifier to the MOON 320S Power Supply, you must move two (2) internal jumpers inside your MOON 310LP. Please refer to page 8 of your MOON 310LP owner’s manual for detailed instructions on how to remove the chassis cover. -
Page 8: Rear Panel Connections
MOON 320S Power Supply Rear Panel Connections Figure 2: MOON 310LP Rear panel Figure 3: MOON 320S Rear panel The rear panel of the MOON 320S will look similar to Figure 3 (above right). There is a 4-pin female XLR connector, labeled “DC output”, located on the left side. -
Page 9: Operating The 320S
MOON 320S Power Supply Operating the 320S Since your MOON 310LP Phono Preamplifier is not equipped with its own on/off power switch, powering it on and off is accomplished via the MOON 320S Power Supply’s on/off switch, located on the rear panel. We recommend that you leave your MOON 320S Power Supply powered up at all times to maintain optimal sonic performance. -
Page 10: Specifications
MOON 320S Power Supply Specifications MOON 320S: Transformer ............25VA Total Capacitance ........... 35,200µF Total Inductance ............. 400mH Power Consumption ..........9 Watts AC Power Requirements ......... 120V or 240V, 60Hz or 50Hz Shipping Weight ............. 8 lbs / 3.5 Kgs Dimensions (W x H x D, inches) ......
