- Page 1 Owner’s Manual MOON Series PSX 5.3 Power Supply...
-
Page 2: Important Safety Instructions
MOON PSX 5.3 Power Supply Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 3 European Community Please read all instructions and precautions carefully and completely before operating your Simaudio MOON PSX 5.3 Power Supply. ALWAYS disconnect your entire system from the AC mains before connecting or disconnecting any cables, or when cleaning any component.
-
Page 4: Table Of Contents
Congratulations ... 5 Unpacking and Warnings ... 5 Introduction ... 6 Installation & Placement ... 6 LP5.3 Internal Settings ... 7 Rear Panel Connections ... 8 Operating the PSX 5.3 ... 9 Specifications ...10 www.simaudio.com ____________________________________________________________________________________ Table of Contents Revision no.: 20091110... -
Page 5: Congratulations
Simaudio has made its reputation. We have spared no effort to ensure that it is provides a significant improvement to the sonic performance of your MOON LP5.3 Phono Preamplifier. We have been building high-performance audio equipment for almost 30 years, and the know-how gained through our cumulative experience is an important reason why MOON audio components are so musically satisfying. -
Page 6: Introduction
MOON PSX 5.3 Power Supply Introduction Your MOON PSX 5.3 Power Supply incorporates many significant design features to enhance the “world class”performance of your MOON LP 5.3 Phono Preamplifier. This is an abbreviated list of the more important features: High quality toroidal transformer. -
Page 7: Lp5.3 Internal Settings
Figure 1: MOON LP5.3 Circuit Board layout Prior to connecting your MOON LP 5.3 Phono Preamplifier to the MOON PSX 5.3 Power Supply, you must move two (2) internal jumpers inside your MOON LP 5.3. Please refer to page 8 of your MOON LP5.3 owner’s manual for detailed instructions on how to remove the chassis cover. -
Page 8: Rear Panel Connections
Connect the MOON LP5.3’s AC power cable to the IEC receptacle, located on the PSX5.3’s rear panel. Ensure that the AC wall outlet you use has a functioning ground. For the best sonic performance, it is preferable that you plug your PSX 5.3 directly into a dedicated AC outlet and avoid using an extension cord. -
Page 9: Operating The Psx 5.3
MOON PSX 5.3 Power Supply’s on/off switch, located on the rear panel. We recommend that you leave your MOON PSX 5.3 Power Supply powered up at all times to maintain optimal sonic performance. In the event that you plan to be away from your home for a few days, powering off the MOON PSX 5.3 may not be a bad idea. -
Page 10: Specifications
Signal-to-Noise Ratio (full scale @ 40dB gain) ... 114dBr Signal-to-Noise Ratio (full scale @ 66dB gain) ... 92dBr Note: All other MOON LP5.3 specifications remain unchanged when using it in conjunction with the MOON PSX5.3. Fuse Replacement: ____________________________________________________________________________________ Specifications For the 120V version use a 0.2A slow blow (5 x 20mm size).
