Jet Valve Housing assembly
Time Control Dial
Rear View
1. Fuse Holder
2. Power Supply cord
15A
16
15. Jet Valve Port
15A. Jet Valve Port Screw
16. Jet Valve Housing
15
Front View
3. Power (ON/OFF) Switch
4. Socket (For Floating
Power Cord)
