U-CONTROL UMA25S User Manual
SysEx Dump ALL:
By turning the E11 rotary knob, the entire memory contents of the 16 presets
is sent as SysEx dump via MIDI. During the dump, the display flashes "Run".
You can cancel the process by turning the E11 rotary knob until "End" appears on
the display.
In order to receive a SysEx dump, no settings on your equipment have to
be adjusted.
◊
CAUTION: If you send an "All SysEx Dump" to the U-CONTROL, the entire
memory content is directly overwritten! There is no prompt for
confirmation nor a memory safety function!
SysEx Dump SINGLE:
By turning the E12 rotary knob, the current preset is sent as SysEx dump.
During the dump, the display flashes "Run". You can cancel the process by turning
the E12 rotary knob until "End" appears on the display.
In order to receive a SysEx dump, no settings on your equipment have to be
adjusted. If you send a single preset to the UMA25S, the data are first stored
in a temporary memory. In order to be stored permanently, save the data in a
memory slot of your choice (see Chapter 5.1.2).
MMC Frame Rate Select:
The E13 rotary knob lets you adjust the frame rate: 24, 25, 30 (in each case "non-
drop frame") or 30d ("drop frame"). This is an important setting for the MMC
messages, which contain defined song positions (for example, Locate).
Factory Reset (restoring default presets):
Restoring default presets has already been described in Chapter 5.1.3.
1. In Global Mode, turn the E14 rotary knob until "FAC" (which stands for
Factory Reset) appears on the display.
2. Press the ENTER key once to reset to the factory settings. Then, the UMA25S
switches back to normal Play Mode.
◊
Caution! With Factory Reset, all configured data and user presets are
irreversibly deleted! To avoid an accidental deletion, save your presets
by sending a SysEx dump to your computer beforehand.
• Press the EXIT push button to cancel the Factory Reset.
Global Send Channel:
The UMA25S keyboard sends all keyboard information and control element
data, which are assigned to the GLOBAL SEND CHANNEL over the global basis
channel; the assignment takes place by selecting the MIDI channel "c00" for a
control element in Edit Mode (see Chapter 5.4). When individual keys and control
elements are assigned to other channels (1 – 16), the GLOBAL SEND CHANNEL has
no effect on these elements.

6. Specifications

Audio Inputs
MIC IN
Connectors
Input impedance
Max. input level
LINE IN
Connector
Input impedance
Max. input level
Audio Outputs
LINE OUT
Connector
Output impedance
PHONES
Connector
Output impedance
Max. output level
Digital Processing
Converters
Sampling rate
USB Interface
Connector
Type
MIDI Interface
Type
Control Elements
Controls
Buttons
Pedal inputs
1/8" TRS connectors
5 kΩ
+6 dBV
RCA connector
approx. 27 kΩ
0 dBV
RCA connector
approx. 400 Ω
1/8" TRS connector
approx. 50 Ω
-8 dBV, 2 x 1.3 mW @ 100 Ω
16-bit converters
32.0 kHz, 44.1 kHz, 48.0 kHz
Type A
USB 2.0; full-speed 12 Mbit/s
USB MIDI class-compliant
5-pin DIN connector OUT
8 rotary knobs
1 pitch bend wheel
1 modulation wheel
1 volume slider
8 push buttons
1 sustain, 1/4" TS connector with
automatic polarity detection
1 expression, 1/4" TS connector
