W992
Region code of DVD/Video player for home is 4 or ALL. In inserting a disc with other region code, it does not
operate. Please only use a disc with region code 4 or ALL.
is a 'Prohibition' mark. If this mark is displayed in operating the product, please wait for a while, then use
it. If "
Prohibition" mark continues to be displayed in pressing a button after that, it means the button
does not function in the currently played disc.
Press a product button on the remote control then use the product.
• DVD operation : [DVD] button
• Video operation : [VCR] button
Instruction Manual
P/N:97P95600D0-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W992 and is the answer not in the manual?

Questions and answers

Related Manuals for AWA W992

Summary of Contents for AWA W992

  • Page 1 W992 Region code of DVD/Video player for home is 4 or ALL. In inserting a disc with other region code, it does not operate. Please only use a disc with region code 4 or ALL. is a ‘Prohibition’ mark. If this mark is displayed in operating the product, please wait for a while, then use it.
  • Page 2 Product Information DVD Operation Important Safeguards ..........2 Playing a desired scene ........... 37 Advantages of This Product ........5 Confirming the current PLAYING TIME ....41 Read Carefully before Using ........6 Selecting an AUDIO language and SUBTITLE language . 43 Identification of Controls ..........
  • Page 3 The lightning flash with arrowhead symbol, within This set has been designed and manufactured to assure surfaces may cause the product and cart combination CAUTION an equilateral triangle, is intended to alert the user personal safety. Improper use can result in electric shock or to overturn.
  • Page 4 points or “short-out” parts that could result in a fire 21 Safety Check • DVD, VCD, CD, CD-R(MP3), CD-RW, VHS • Parental Lock function (DVD) or electric shock. Never spill liquid of any kind on the Upon completion of any service or repairs to this unit, •...
  • Page 5 Main body (front panel) Cautions in use of DVD-Video player are Checking described below. • Video is a high precision device. To obtain a clear screen, we recommend regular inspection Please read carefully before using a DVD-Video and maintenance every 1,000 hours of use by player.
  • Page 6 Main body (Rear Panel) Operation Display Window & - RECORDING MODE - Timer Recording Standby Timer Recording Error Recording in Progress Timer Recording in ! Power Cord % A/V OUTPUT Jack Progress It is a jack for supplying power to the unit. ^ A/V INPUT Jack Connect to outlet in a wall.

  • Page 7: Remote Control Battery Installation

    Open/Close button, Eject button [DVD] [VCR] @ VCR SELECT button Accessories Number button, Tracking -/+ button [DVD, VCR] [VCR] $ System button This button is not available for [VCR] this set Activates Progressive Scan button [DVD] Remote control 2 Batteries RF cable Instruction Manual % SETUP button...
  • Page 8 Before you start, unplug all the equipment from the mains supply. Before you start, unplug all the equipment from the mains supply. (Option 1) - How to connect with RF lead (Option 2) - How to Connect with Audio/Video jack REAR PANEL OF TV REAR PANEL OF DVD-VIDEO INPUT 1...

  • Page 9: Connecting With Other Vcr Or Camcorder

    Connecting with Other VCR or Camcorder Connecting with Other VCR or Camcorder How to Connect with Jack in Front Panel ¡ Connect Audio/Video Out jack in Camcorder(or playback video) to Audio/Video In jack in rear REAR PANEL OF PLAYBACK VCR(CAMCORDER) FRONT PANEL OF DVD-VIDEO panel (or front panel) of DVD-Video with connecting cable.
  • Page 10 How to Connect with Stereo Unit such as Audio Use in COMPONENT In jack attached in TV or amp supporting Dolby Digital. REAR PANEL OF STEREO UNIT REAR PANEL OF DVD-VIDEO How to Connect (L) AUDIO (R) REAR PANEL OF DVD-VIDEO ¡...
  • Page 11 Switch the TV on. You can also start "AUTO SEARCH" in the SETUP "PR PRESET" "AUTO SEARCH". If the clock has not been set, the clock setting screen will appear. CLOCK SET To tune in new stations (manual tuning) and to enter station names see page 27-28. TIME - - : - - Please see “Setting time and date”...
  • Page 12 Setting time and date To Select DVD Press [VCR] button on the remote control to change into VCR Mode and follow the procedure Press [DVD] button. below. If DVD mode is correctly selected, DVD on the operation display window is lit. Then, REMOTE button works as DVD function.
  • Page 13 Press [ ] button to power on. Press [ ] button to power on. Press [DVD] button of REMOTE to change into DVD mode. Press [VCR] button of remote control to change into VCR mode. Insert the desired tape. Press [OPEN/CLOSE] button to open the disc tray. Place a disc firmly on the disc tray, making its label look upward.
  • Page 14 To Record With VCR To Copy From DVD To Videotape Press [ ] button to power on. • Press [VCR] button of remote control to change into VCR mode. Insert the desired DVD disc. When it is a DVD disc with copy protect function, you can’t copy it. Insert a recordable tape.
  • Page 15 The TV and player are switched on. To see the picture from your player, press the input or AV (Audio/Video) button on the TV. One Touch timer Recording (OTR) Tuning When your urgent business happens suddenly in watching TV or you want to record the current TV program for the desired time, follow the procedures below.
  • Page 16 Station names Sorting programme locations If the location numbers used for programmes stored in your TV and player are different, you can change them on the If your player is showing no station name or is showing a station name incorrectly, you can correct player.

  • Page 17: Normal Timer Recording

    For timer recordings, clock, date, and stations must be set correctly. Load a cassette with its safety tab in place and with sufficient free space for the recording. Normal timer recording Timer Review – changing and erasing Press "SETUP", choose "TIMER PROGRAM". Press OK. HOW OFTEN DO YOU WANT Call the player’s "SETUP", TIMER PROGRAM...
  • Page 18 Resetting the counter to zero The counter counts in real time from the point you load the cassette. This does not have to be its beginning! The counter does not count unrecorded parts of the tape. If you rewind beyond the zero position, the counter counts in negative values (e.g. – 0:01:15). COUNTER RESET Reset the counter.

  • Page 19: Choice Of Sound Output

    The player machine records the complete sound signal transmitted by the TV station. If you are using a RCA cable, select the AV input on the TV to see the picture from the player. On the mono VCR, you will hear the normal mono sound. If you are not using a RCA cable, select the button number on the TV reserved for video input to see the picture from the player.
  • Page 20 To skip scenes in a disc Assembling Should you wish to assemble your own film, from camcorder footage for example, use the assembly technique for To move to next chapter (or track), press [√√ NEXT] button. smooth edit points: The current chapter (or track) moves to the next chapter (or track). •...
  • Page 21 Repeating a defined period Searching DVD with a title number, chapter number or a time If you want to search with a title number or chapter Each time you press [REPEAT] button in playback mode, repeat playback starts as below. TT 01/02 CH number, press the [SEARCH] button once.
  • Page 22 Confirming the current playing time of DVD disc Searching VCD with a track number, disc time or track time If you want to search wth a disc time, press While in playing, press [DISPLAY] button. D I S C G O T O : - -: - - [SEARCH] button one time.
  • Page 23 Confirming the current playing time of VCD disc Selecting an audio language While in playing, press [DISPLAY] button. It shows the current playing time. The user may select an audio language and subtitle language if a disc includes Multi-language. Each time you press [DISPLAY] button in playback mode, DISPLAY is change as below. Keep pressing [AUDIO] button till the user’s preferred language appears in playback mode.
  • Page 24 Using a zoom function Playing a disc containing MP3 files The user can enlarge the current screen about 2 , 3 or 4 times. This unit will play MP3 files recorded on CD-R and CD-RW discs. Keep pressing [ZOOM] button till the preferred zoom appears. Turn on your television and select the channel assigned to this DVD player.
  • Page 25 Playing a disc containing JPG (PHOTO) files The ability of this unit to read MP3 discs is dependent on the followings: This unit will play JPG files recorded on CD-R and CD-RW discs. • The Bit Rate must be within 64-256 kbps. •...
  • Page 26 A user can set OSD language, Audio, Subtitle and Disc Menu. To display menus in a disc While STOP or RESUME STOP, press [SETUP] OSD LANGUAGE ENGLISH LANGUAGE button. AUDIO AUTO If a disc includes menus, the user may use them. SUBTITLE VIDEO DISC MENU...
  • Page 27 A user can set up a connected TV condition and screen. While STOP or RESUME STOP, press [SETUP] Selecting Disc Menu language. OSD LANGUAGE ENGLISH TV ASPECT 4:3 LB LANGUAGE LANGUAGE AUDIO FRENCH SCAN MODE INTERLACED button. Set your preferred DISC MENU language with SPANISH SUBTITLE VIDEO...
  • Page 28 A user may select audio menu according to a user’s speaker set. While STOP or RESUME STOP, press [SETUP] LANGUAGE button. SCREEN SAVER RESET While STOP or Resume STOP, press [SETUP] DEFAULTS VIDEO 8 ADULT DIGITAL OUT BITSTREAM LANGUAGE PARENTAL button.

  • Page 29: Playable Disc

    Playable Disc Changing the password. LANGUAGE To change your password, move the cursor to SCREEN SAVER • DVD, Video CD (Version 1.1, 2.0), S-VCD and Audio CD DEFAULTS “PASSWORD” and press [√]. Then press the VIDEO PARENTAL [ENTER] button. CHANGE PASSWORD AUDIO Disc type...

  • Page 30: Terms Related With Dvd

    Terms related with DVD Handling Disc A DVD (abbreviation of Digital Versatile Disc or Digital Video Disc) can include 135 minutes of video • To keep a disc clean condition, please do not touch a side containing information. And for audio, it can hold up to 8 kinds of languages and 32 kinds of subtitle play information.
  • Page 31 Symptom Checks • “Power On” does not work. Please check whether a power plug is inserted in an electric outlet. Terms related with VCR • It does not work even in “Power On”. Please check whether a videotape is inserted in. Try to insert a plug again.
  • Page 32 Symptom Checks Symptom Checks • Recording a TV program is For recording, you should use videotape with a tab. • The recorder does not play. If a DVD is from overseas, it may not be played. Please check a DVD’s impossible.
  • Page 33 Power AC ~ 240V, 50Hz Consumed electricity Weight 4.6kg Dimension (W x H x D) 435mmx93mmx255mm(Without Foot), 435mmx98mmx255mm(With Foot) Operative temperature +5°C~40°C Installation condition Horizontal / Relative humidity under 80% Laser output 5mW (continuous wave max.) Wave length 635nm (DVD), 730nm (CD) Signal type PAL COLOR Antenna Input/output...
