DVD Recorder + VCR
DVD Recorder + VCR
W1090
User Manual
P/N : 97P95600D0-2K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W1090 and is the answer not in the manual?

Questions and answers

Related Manuals for AWA W1090

Summary of Contents for AWA W1090

  • Page 1 DVD Recorder + VCR DVD Recorder + VCR W1090 User Manual P/N : 97P95600D0-2K...

  • Page 2: Safety Instructions

    Safety Instructions Safety Instructions Please keep the DVD Recorder+VCR’s guarantee sheet and receipt in a safe place. Precautions • Read this booklet carefully. • Make sure the rating of your household electricity supply matches that shown on the back of your DVD Recorder+VCR. •...
  • Page 3 Important Safeguards Important Safeguards Important Safeguards This set has been designed and manufactured to ventilation to ensure reliable operation of the unit The lightning flash with arrowhead symbol, CAUTION assure personal safety. Improper use can result in and to protect it from overheating. These within an equilateral triangle, is intended to RISK OF ELECTRIC SHOCK electric shock or fire hazard.

  • Page 4: Table Of Contents

    Important Safeguards Table of Contents Table of Contents personal injury and serious damage to the 23 HEAT Introduction Recording product. The product should be situated away from heat sources such as radiators, heat registers, stoves, 17 DISC Safety Instructions ____________________________1 Basic Recording________________________________42 or other products (including amplifiers) that Recording from TV...

  • Page 5: Important Safeguards

    Important Safeguards Table of Contents Table of Contents personal injury and serious damage to the 23 HEAT Introduction Recording product. The product should be situated away from heat sources such as radiators, heat registers, stoves, 17 DISC Safety Instructions ____________________________1 Basic Recording________________________________42 or other products (including amplifiers) that Recording from TV...

  • Page 6: Overview

    Overview Overview Overview DVD, DVD+R, DVD+RW? Playback only What is a DVD? DVD Video (Digital Versatile Disc) DVD (Digital Versatile Disc) is a storage medium that combines the convenience of the compact disc with the DVD-R (DVD-Recordable): These discs can only be played back if the recording was made in ‘Video mode‘ and latest digital video technology.
  • Page 7 Overview Overview Notes on Discs Video discs and some satellite broadcasts. If copy-protected material is encountered during a recording, recording will pause or stop automatically and an error message will be displayed on-screen. Handling Discs • Video that is ‘copy-once only’ can only be recorded using DVD+RW discs with CPRM. Do not touch the playback side of the disc.

  • Page 8: Identification Of Controls

    Identification of Controls Identification of Controls Identification of Controls Front Panel Front Panel Display & * & STANDBY/ON REC SPEED ! Indicates a VHS tape is inserted in the VCR deck. ) Circle : Indicates a DVD+R(+RW) is recording. SELECT DVD/VCR Turns the DVD Recorder+VCR on and off.
  • Page 9 Identification of Controls Identification of Controls Remote Control Turns the DVD Recorder+VCR on and off. Starts recording. Press repeatedly to set the recording time. For more details, Refer to One Touch Record (OTR) on page 42. - Opens and closes the disc tray in DVD mode. - Ejects the tape in the VCR deck in VCR mode.

  • Page 10: Connecting Antenna/Cable

    Identification of Controls Connections Connections • There are a variety of ways to connect the DVD Recorder+VCR to your TV and other equipment. Use only one of Rear panel the connections described below. Whichever TV connection you use will work with all input sources. •...
  • Page 11 Identification of Controls Connections Connections • There are a variety of ways to connect the DVD Recorder+VCR to your TV and other equipment. Use only one of Rear panel the connections described below. Whichever TV connection you use will work with all input sources. •...

  • Page 12: Connecting A Tv

    Connections Connections Connecting a TV Connecting an Amplifier/Receiver Choose one of the following TV connections, depending on the capabilities of your equipment. Connecting to an amplifier equipped with two channel analog stereo or Dolby Pro Logic ll/Pro Logic Connect the Left and Right AUDIO OUT jacks on the DVD Recorder+VCR to the left and right audio in jacks on All video signals are available from all video outputs.

  • Page 13: Connecting Optional Equipment

    Connections Initial Installation Initial Installation Connecting Optional Equipment Initial Installation To receive audio/video signals from other equipment, connect After successfully connecting your DVD Recorder+VCR to your TV and other Jack Panel of Accessory Component Installation the AVF jacks on the DVD Recorder+VCR to the audio/video out devices, this chapter will show you how to complete the initial installation.

  • Page 14: Initial Installation

    Connections Initial Installation Initial Installation Connecting Optional Equipment Initial Installation To receive audio/video signals from other equipment, connect After successfully connecting your DVD Recorder+VCR to your TV and other Jack Panel of Accessory Component Installation the AVF jacks on the DVD Recorder+VCR to the audio/video out devices, this chapter will show you how to complete the initial installation.

  • Page 15: Initial Setup

    Initial Installation Initial Setup Initial Setup Setup Menu Overview Select the desired disc playback subtitle language using […/†]. Press Installation The DVD Recorder+VCR Setup menu includes six categories, including: Installation, Recording Options, [ENTER] to confirm. Please select disc subtitle language: Languages, Preferences, System Info, and Restore Defaults.
  • Page 16 Initial Installation Initial Setup Initial Setup Setup Menu Overview Select the desired disc playback subtitle language using […/†]. Press Installation The DVD Recorder+VCR Setup menu includes six categories, including: Installation, Recording Options, [ENTER] to confirm. Please select disc subtitle language: Languages, Preferences, System Info, and Restore Defaults.
  • Page 17 Initial Setup Initial Setup Auto Set Use […/†] to select ‘Auto Search‘. Manual Setup Standard PAL-BG The DVD Recorder+VCR has a frequency synthesized tuner capable of receiving Search the real channel number by pressing [œ/√]. Reception Aerial up to 99 channels. These include VHF channels 00-14, UHF channels 27-69 and Auto Search CH02 CATV channels 1-41.
  • Page 18 Initial Setup Initial Setup Adjust Channels VCR Record Quality You can set the default VCR recording quality to SP (Standard Play) or LP Follow steps 1-2 as shown under ‘Manual Set’. Recording Options (Long Play). SP is higher quality, but LP provides 2 times the recording Use […/†] to select ‘Adjust Channels‘.
  • Page 19 Initial Setup Initial Setup PREFERENCES / Video Settings Menu/Subtitle/Audio Language Press [SETUP]. Select your preferred language for Disc Menus, Subtitles, and Audio Language soundtracks. Use [œ/√] to select ‘Preferences‘. Preferences OSD Language English Video Follow the same procedure as the OSD Language. Select Menu While ‘Preferences‘...
  • Page 20 Initial Setup Initial Setup PREFERENCES / Audio Settings PREFERENCES / Parental Controls Follow the same procedure as ‘Video’ Settings to select ‘Audio’ Settings. Set Parental Level The Parental Controls feature allows you to prevent DVDs from being played Preferences Preferences based on their ratings or to have certain discs played with alternative scenes.
  • Page 21 Initial Setup Initial Setup PREFERENCES / VCR Press [ENTER] to confirm your rating selection, then press [SETUP] to exit Parental Control This feature enables you to search for Index marks or specific times on your VHS the menu. Preferences tapes. Set Parental Level ADULT Video...
  • Page 22 Initial Setup On-Screen Display Overview On-Screen Display Overview The On-Screen Display provides feedback on the status of the DVD Recorder+VCR and/or the currently loaded Restore Defaults disc or tape. To access the On-Screen Display (or OSD), press [DISPLAY]. If you wish, you can reset the DVD Recorder+VCR to its original factory settings.
  • Page 23 Initial Setup On-Screen Display Overview On-Screen Display Overview The On-Screen Display provides feedback on the status of the DVD Recorder+VCR and/or the currently loaded Restore Defaults disc or tape. To access the On-Screen Display (or OSD), press [DISPLAY]. If you wish, you can reset the DVD Recorder+VCR to its original factory settings.

  • Page 24: Dvd Playback

    On-Screen Display Overview DVD Playback DVD Playback OSD Menu Options for DVD Playing a DVD Press [DVD] to set the remote control to operate the DVD deck. During DVD playback, press [DISPLAY] to show information about the current disc. While the disc information is displayed, press [DISPLAY] again to show the disc Turn the TV on and select the video input source connected to the DVD Recorder+VCR.
  • Page 25 On-Screen Display Overview DVD Playback DVD Playback OSD Menu Options for DVD Playing a DVD Press [DVD] to set the remote control to operate the DVD deck. During DVD playback, press [DISPLAY] to show information about the current disc. While the disc information is displayed, press [DISPLAY] again to show the disc Turn the TV on and select the video input source connected to the DVD Recorder+VCR.
  • Page 26 DVD Playback DVD Playback Changing the Audio Language Search Press [AUDIO] and then press [AUDIO] repeatedly during playback to hear a different audio language or audio Press [SEARCH] to display the Search menu. track. … T/ C Use [œ √] to move to Title (T) or Chapter (C) and use […†] to set the title or chapter Subtitles †...

  • Page 27: Vcr Playback

    VCR Playback VCR Playback VCR Playback Before You Begin Special Playback Features Press the VCR button to set the remote control to operate the VCR deck. Notes on special playback features Turn the TV on and select the video input source connected to the DVD Recorder+VCR. Horizontal lines (noise bars) will appear on the TV screen.

  • Page 28: Other Disc Playback

    Other Disc Playback Other Disc Playback Other Disc Playback Audio CD/MP3 PLAYBACK The DVD Recorder+VCR can play audio CDs and MP3 files on CD-ROM, Select the thumbnail you want to display using […†œ √] and press CD-R or CD-RW discs. [ENTER].
  • Page 29 Other Disc Playback Other Disc Playback Other Disc Playback Audio CD/MP3 PLAYBACK The DVD Recorder+VCR can play audio CDs and MP3 files on CD-ROM, Select the thumbnail you want to display using […†œ √] and press CD-R or CD-RW discs. [ENTER].

  • Page 30: Basic Recording

    Basic Recording Basic Recording Basic Recording Recording from TV Checking the Recording Time Follow the instructions below to record a TV program. Total time and recorded time are displayed on the TV screen after pressing [DISPLAY]. Recorded time is displayed on the front panel display. Turn on the DVD Recorder+VCR and load a recordable disc or tape.
  • Page 31 Basic Recording Timer Recording Timer Recording Copy Edit (DVD ➝VCR) Timer Recording using Manual Set Record Screen During one touch copy you can search or change REC SPEED and resume copy. The Timer Recording function allows you to record up to 8 programs within a period of one month. During One Touch Copy press [PLAY/PAUSE] to enter COPY EDIT mode.
  • Page 32 Basic Recording Timer Recording Timer Recording Copy Edit (DVD ➝VCR) Timer Recording using Manual Set Record Screen During one touch copy you can search or change REC SPEED and resume copy. The Timer Recording function allows you to record up to 8 programs within a period of one month. During One Touch Copy press [PLAY/PAUSE] to enter COPY EDIT mode.
  • Page 33 Timer Recording Timer Recording Timer Recording using G-Code system Canceling a Timer Recording Thanks to this programming system, you no longer need to tediously enter the date, programme number, start You can clear a Timer Recording any time before the recording actually starts. and end time.

  • Page 34: Recording From An External Input

    Recording from an External Input Recording from an External Input Recording from an External Input Recording from External Components What is DV? You can record from an external component, such as a camcorder or VCR, connected to any of the DVD Using DV, also known as i.LINK, you can connect a DV-equipped camcorder to the DVD Recorder+VCR using a Recorder+VCR’s external inputs.

  • Page 35: Disc Initialize

    Editing Editing Editing DISC Initialize Finalize (Make Compatible) • If you load a blank DVD+R(+RW) disc, it will be initialized (formatted to enable recording). Finalizing a DVD+R ‘locks’ its recordings in place so the disc can be played on most standard DVD players or •...

  • Page 36: Title Menu

    Editing Editing Title Menu Change Disc Name You can manage the titles on your DVD+R/RW discs using the Title menu. You can rename your disc to any name you choose. The default disc name is ‘MY DVD‘. Play a Title Use […] to go to the top menu.

  • Page 37: Editing

    Editing Editing Editing Change Name When you insert a DVD+R or DVD+RW disc already recorded by your DVD Recorder+VCR, you can edit the titles To change the name of a title: and chapters in a variety of ways. Follow steps 1 to 3 under ‘Play Title‘. To edit a recorded title, select the title on the disc menu and press [EDIT].

  • Page 38: Troubleshooting

    Editing Troubleshooting Troubleshooting Check the following guide for the possible cause of a problem before contacting customer support. Hide Chapters Symptom Cause Solution This feature allows you to hide or unhide a chapter. After hiding a chapter, the DVD Edit No power.
  • Page 39 Editing Troubleshooting Troubleshooting Check the following guide for the possible cause of a problem before contacting customer support. Hide Chapters Symptom Cause Solution This feature allows you to hide or unhide a chapter. After hiding a chapter, the DVD Edit No power.

  • Page 40: Technical Specifications

    Troubleshooting Technical Specifications Technical Specifications General Symptom Cause Solution Power requirements 200–240V~, 50/60 Hz Discs recorded with copy-once No solution. Power consumption material cannot be played on other Dimensions (approx.) 16.9 x 3.54 x 14.0 inches (430 x 91 x 354 mm) (w x h x d) players.
  • Page 41 Troubleshooting Technical Specifications Technical Specifications General Symptom Cause Solution Power requirements 200–240V~, 50/60 Hz Discs recorded with copy-once No solution. Power consumption material cannot be played on other Dimensions (approx.) 16.9 x 3.54 x 14.0 inches (430 x 91 x 354 mm) (w x h x d) players.
  • Page 42 Manufactured under license from Dolby Laboratories. ‘Dolby‘, ‘Pro Logic‘ and the double-D symbol are trademarks of Dolby Laboratories. DTS and DTS Digital Out are registered trademarks of Digital Theater Systems, Inc. AWA brand is imported and sold under license by Big W Discount Stores, 3 City View Rd Pennant Hills NSW 2120.
