AWA TFTD51 Owner's Manual

20.1" tft lcd tv & monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for AWA TFTD51

Summary of Contents for AWA TFTD51

  • Page 2 20.1" TFT LCD TV & MONITOR English...

  • Page 3: Table Of Contents

    Table of Contents Important Safety Information ........Control and Function ........... Front and Side View ........Rear View ..........Accessories ............Features of the Remote Control Unit ......Loading the Batteries ........Reception Range of Remote Control Unit ....Connection ............

  • Page 4: Important Safety Information

    Important Safety Information WARNING WARNING: To reduce the risk of electric shock do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with The exclamation point within arrow-head within a triangle a triangle is intended to tell is intended to tell the uesr the user that important...
  • Page 5 Important Safety Information Important Safeguards for You and Your New Device Always be careful when using your LCD TV. To reduce the risk of fire, electric shock, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your LCD TV. 1.
  • Page 6 Important Safety Information 17. Avoid overhead power lines. Do not place an outside antenna system in the vicinity of overhead power lines or other electric light or power circuits, or where it could fall into such power lines or circuits. When installing an outside antenna system, be extremely careful not to touch the power lines or circuits.

  • Page 8: Control And Function

    Control and Function *Rear View CAUTION Be sure to turn off the power of your computer before connecting the monitor. *SCART *RCA 1. DC INPUT(12V) Connect the female end of the adapter DC12V out to the DC input receptacle on the LCD TV. Then, adapt plug the male end of the power cord to an AC outlet.

  • Page 9: Accessories

    Accessories *Standard Accessories *Option Accessories...

  • Page 10: Features Of The Remote Control Unit

    Features of the Remote Control Unit *Installing Batteries * Open the battery compartment cover on the back of the remote control and insert the batteries with correct polarity, match "+" with "+",and match "-" with"-" * Install two 1.5V "AAA" batteries. Don't mix used batteries with new batteries.

  • Page 11: Connection

    Connection *Connecting VHF and UHF Antennas Connecting an Outdoor Antenna For the best reception, we recommend you use an outdoor antenna. Severely weathered antennas and antenna cables can reduce the signal quality. Before making any connections, inspect all antenna hardware; any service center can explain the various outdoor antennas available to you.

  • Page 12: Connecting A Vcr(Composite Video)

    Connection *Connecting a VCR(Composite Video) *SCART Back panel of the TV *RCA Back panel of the TV Connect SCART cable (not supplied) to the SCART jack on the LCD TV and the SCART output jack on the external equipments. (DVD/VCR, etc.,) To play DVD/VCR : 1.

  • Page 18: Remote Controller Key Functions

    Remote Controller Key Functions *When using the remote control aim it at the remote control sensor on the TV 16.MTS Button Selects the language durind dual language Broadcast, selects sound output. 17.PREVIEW Button Go back to previous TV channel 18.TTX Button Select Teletext display/Return to TV picture display.

  • Page 19: Osd Menu Structure

    OSD Menu Structure * OSD (On Screen Display) menu allows user to control or adjust various features and settings in accordance with his/her preferences. * Press the Menu button on the Remote Control Unit, you may see the OSD menu. -16-...

  • Page 26: Teletext Operating

    Teletext Operating Teletext button Press the TELETEXT button to turn teletext on and off. With teletext on, change the page by keying in a three-digit page number. If you make a mistake, just complete three digits then key in the correct number. Red, green, yellow and blue buttons The row of red, green, yellow and blue buttons on the remote control corresponds with coloured page numbers at the bottom of the teletext display-see .LIST / FLOP button.
  • Page 27 Teletext Operating Reveal button Use this function on certain pages to reveal the solutions to quizzes and so on. Press the button once to reveal a hidden answer and press the button again to hide it. Sub-pages Some teletext pages contain too much information to fit on the screen at once, so they are split up into sub-pages and shown in order.

  • Page 28: Compatible Display Monitor Specification

    Compatible Diaplay Monitor Specification RGB Input Format Resolution(pixel x line) Horizontal Frequency (KHz) SyncPolar Vertical Frequency (Hz) SyncPolar 640x480 @60Hz 31.47 59.94 @67Hz 35.00 66.67 800x600 @56Hz 56.25 35.16 60.32 @60Hz 37.88 1024x768 @60Hz 48.36 60.00 @70Hz 56.48 70.07 The LCD TV might operate abnormally if a non-standard video format is selected. The best resolution for this LCD TV is 640X480 60Hz.
