Summary of Contents for Grundig IPS01
-
Page 2: Introduction
IPS01 Introduction Thank you for buying this GRUNDIG product, which is designed to give you many years of trouble-free service. You may already be familiar with using a similar unit, but please take the time to read these instructions. Safety is important Your safety is very important. -
Page 3: Table Of Contents
IPS01 CONTENTS Introduction Important Notes Location of Controls (Main Unit) Control Definitions (Main Unit) Location of Controls (Remote) Control Definitions (Remote) Setup iPod and iPhone 3.5mm Audio Input and Composite Video Output Playing and Charging an iPod Warranty What’s in the box Carefully remove your Stereo Speaker System with Dock for iPhone from the box. -
Page 4: Important Notes
IPS01 IMPORTANT NOTES Ensure that you read all of the safety instructions before operating this unit. Safety Considerations Ensure that the power cable and other connected cables are protected and are positioned so that they are not likely to be walked on, pinched or damaged. - Page 5 IPS01 Main Unit...
- Page 6 IPS01 LCD DISPLAY: Allows you to view the current time, which can be set manually or automatically from your iPhone. ROTATING DOCK: Allows you to rotate the view of your iPod/iPhone so you can watch videos via the dock. VOLUME: Press the VOLUME Button to adjust the volume. EQ: Press the EQ Button to switch between the preset equalizer modes Rock, Classic, Jazz, and Pop.
- Page 7 IPS01 Remote Control...
- Page 8 IPS01 POWER/PLAY/PAUSE: Press the POWER/PLAY/PAUSE Button to turn the power on or press and hold to turn the unit off. Once the unit is on, press the POWER/ PLAY/PAUSE Button to play or pause playback on your iPhone/iPod. STOP: Press the Stop Button to stop playback at anytime. CLOCK SET/MENU: When the unit is off, press and hold the CLOCK SET/MENU Button to begin setting the clock.
-
Page 9: Setup
IPS01 Setup Power DC power input: requires an AC/DC power adapter (included) Backup Battery Backup battery: requires 2 AAA batteries (not included) The backup battery will save the set time in case of an unexpected power outage. Remote Requires a CR2025 battery (pre-installed) CR2025 OPEN PUSH... -
Page 10: Ipod And Iphone
IPS01 iPod and iPhone Connecting the Spacers Place the spacer onto the dock and turn clockwise to lock the spacer into place. To remove the spacer, turn counter-clockwise. CLOCKWISE COUNTER-CLOCKWISE LOCKS UNLOCKS Docking an iPod or iPhone Playing a Docked iPod or iPhone Follow the instructions for Connecting Follow the instructions for Docking an the Spacers and use as needed to secure... -
Page 11: 3.5Mm Audio Input And Composite Video Output
IPS01 3.5mm Audio Input and Composite Video Output Using the 3.5mm Audio Input Using the Composite Video Output To connect a MP3 Player or other Audio To watch videos from your iPhone/iPod on Device you will need a 3.5mm Auxiliary your TV you will need a RCA Composite Cable (not included). -
Page 12: Playing And Charging An Ipod
IPS01 Playing and Charging an iPod Connecting your iPhone or iPod Select the iPhone/iPod adaptor that corresponds to your model from the table below. Please note the highlighted adaptor models which are included with this unit. Adjust the iPhone/iPod dock support to t your model. Place the adaptor on the dock at the top of the unit with the two tabs facing forwards. - Page 13 IPS01 Trouble Shooting If a fault occurs, rst check the points listed below before taking the unit for repair. If you are unable to solve a problem by following the below hints we suggest you consult you retailer or contact our Service and Warranty team United Electrical on 1800 509 394. WARNING: Under no circumstances should you try to repair the unit yourself.
-
Page 14: Warranty
In the unlikely event that your product fails to work normally, please contact the Grundig warranty number 1800 509 394 (Australia) or 0800 450 259 (New Zealand) and have your receipt of purchase on hand. - Page 15 IPS01 PO BOX 6287 Silverwater NSW 1811 www.grundig.net.au...
